trpc-browser

🌐 tRPC for everything in the browser

Easy communication for web extensions.
Typesafe messaging between content & background scripts.
between window, any other window (eg iframe) or popups
Ready for Manifest V3.
forked because of lack of maintenance on the original repo

📖 Table of contents

📦 Installation

Install trpc-browser.

# pnpm
pnpm add @capaj/trpc-browser
# npm
npm install @capaj/trpc-browser
# yarn
yarn add @capaj/trpc-browser

🧩 Example usage for extensions

1. Add createChromeHandler in your background script.

// background.ts
import { initTRPC } from '@trpc/server';
import { createChromeHandler } from 'trpc-browser/adapter';

const t = initTRPC.create({
  isServer: false,
  allowOutsideOfServer: true,
});

const appRouter = t.router({
  // ...procedures
});

export type AppRouter = typeof appRouter;

createChromeHandler({
  router: appRouter /* 👈 */,
});

2. Add a chromeLink to the client in your content script.

// content.ts
import { createTRPCClient } from '@trpc/client';
import { chromeLink } from 'trpc-browser/link';

import type { AppRouter } from './background';

const port = chrome.runtime.connect();
export const chromeClient = createTRPCProxyClient<AppRouter>({
  links: [/* 👉 */ chromeLink({ port })],
});

3. (extra) If you have an injected window script, hook it up too!.

// inpage.ts
import { createTRPCProxyClient } from '@trpc/client';
import { windowLink } from 'trpc-browser/link';

import type { AppRouter } from './background';

export const windowClient = createTRPCProxyClient<AppRouter>({
  links: [/* 👉 */ windowLink({ window })],
});

// content.ts
import { relay } from 'trpc-browser/relay';

const port = chrome.runtime.connect();
relay(window, port);

🕸️ Example usage for windows

1. Add createWindowHandler in your main window.

// main.ts
import { initTRPC } from '@trpc/server';
import { createWindowHandler } from 'trpc-browser/adapter';

const t = initTRPC.create({
  isServer: false,
  allowOutsideOfServer: true,
});

const appRouter = t.router({
  // ...procedures
});

export type AppRouter = typeof appRouter;

createWindowHandler({
  router: appRouter /* 👈 */,
  window: window /* 👈 */,
});

2. Add a windowLink or popupLink to the client

import { createTRPCProxyClient } from '@trpc/client';
import { popupLink, windowLink } from 'trpc-browser/link';

import type { AppRouter } from './main';

/** iframe */
const iframeEl = document.querySelector('iframe');
export const iframeClient = createTRPCProxyClient<AppRouter>({
  links: [/* 👉 */ windowLink({ window: iframeEl.contentWindow })],
});

/** popup */
export const popupClient = createTRPCProxyClient<AppRouter>({
  links: [
    /* 👉 */ popupLink({
      listenWindow: window,
      createPopup: () => {
        const w = window.open('/example/popup', 'popup', 'width=680,height=520');
        if (!w) {
          throw new Error('Could not open popup');
        }
        return w;
      },
    }),
  ],
});

📔 Requirements

Peer dependencies:

tRPC Server v10 (@trpc/server) must be installed.
tRPC Client v10 (@trpc/client) must be installed.

📝 Example

Please see an extension example here. You can also find a window example here.

For advanced use-cases, please find examples in our complete test suite.

🆎 Types

ChromeLinkOptions

Please see full typings here.

Property	Type	Description	Required
`port`	`chrome.runtime.Port`	An open web extension port between content & background scripts.	`true`

WindowLinkOptions

Please see full typings here.

Property	Type	Description	Required
`window`	`Window`	A window object which is listened to	`true`
`postWindow`	`Window`	A window object which is posted to (defaults to `window`)	`false`
`postOrigin`	`string`	The targetOrigin passed to `opts.postWindow.postMessage`	`false`

PopupLinkOptions

Please see full typings here.

Property	Type	Description	Required
`listenWindow`	`Window`	A window object which is listened to	`true`
`createPopup`	`Function`	A function that returns a window object.	`true`
`postOrigin`	`string`	The targetOrigin passed to `popup.postMessage`	`false`

CreateChromeHandlerOptions

Please see full typings here.

Property	Type	Description	Required
`router`	`Router`	Your application tRPC router.	`true`
`createContext`	`Function`	Passes contextual (`ctx`) data to procedure resolvers.	`false`
`onError`	`Function`	Called if error occurs inside handler.	`false`
`chrome`	`Object`	Chrome API object. (default: `global.chrome`)	`false`

CreateWindowHandlerOptions

Please see full typings here.

Property	Type	Description	Required
`router`	`Router`	Your application tRPC router.	`true`
`createContext`	`Function`	Passes contextual (`ctx`) data to procedure resolvers.	`false`
`onError`	`Function`	Called if error occurs inside handler.	`false`
`window`	`Window`	Window object to subscribe to	`true`
`postWindow`	`Window`	Window object to post messages to. (default: `MessageEvent.source` with fallback to `opts.window`)	`false`
`postOrigin`	`string`	The targetOrigin passed to `opts.postWindow.postMessage`. If you want to answer to all messages from all origins you should pass `'*'`, by default it will only work on same origin	`false`

Cross-origin support

When posting from a link you can specify the postOrigin option. This will be passed to postMessage as the targetOrigin argument. If you want to answer to all messages from all origins you should pass '*', by default it will only work on same origin.

©️ License

Distributed under the MIT License. See LICENSE for more information.
