@miyax/ganttjs v1.1.3

Miyax Gantt Chart

An open source gantt chart for the web

Installation

npm i @miyax/ganttjs

or

yarn add @miyax/ganttjs

Usage

Create a html element

<div id="gantt-chart"></div>

import { GanttChart, ES } from '@miyax/ganttjs'
import '@miyax/ganttjs/src/theme/default.css'

// Define the tasks
const tasks = [
    {
    id: "1",
    name: "Hello world!!",
    start: new Date("2023/08/09"),
    end: new Date("2023/08/15"),
    color: "#CC8888",
    description: "Lorem ipsum dolor sit amet consectetur adipisicing elit.",
  }
]

// Define the element
const ganttChartHtmlElement = document.getElementById("gantt-chart")

// Define the period
const startGanttChart = new Date("2023/08/01")
const endGanttChart = new Date("2023/08/10")

// Create a new gantt chart
const gantt = new GanttChart() // or new GanttChart(ganttChartHtmlElement)

// Basic
gantt
  .element(ganttChartHtmlElement) // set the element
  .period(startGanttChart, endGanttChart) // show the period from 2023/08/01 to 2023/08/31
  .tasks(tasks) // add the tasks
  .render() // render the gantt chart



// All options
gantt
  .element(ganttChartHtmlElement) // set the element
  .period(startGanttChart, endGanttChart) // show the period from 2023/08/01 to 2023/08/31
  // .todayTo(2) // show the period from today to 2 days after
  .tasks(tasks) // add the tasks
  .widthHeader('350px') // set the width of the header, default is 150px
  .withWeekDays() // show the week days
  .withMonthDay() // show the month day
  .withYearMonths() // show the year months
  .withTime() // show the duration of the tasks
  .showHeaders(false) // disable or enable the headers, default is true
  .i18n(ES) // set the language, default is EN
  .render() // render the gantt chart


// Update the gantt chart
const newTask = {
  id: "2",
  name: "¡¡Hola mundo!!",
  start: new Date("2023/08/09"),
  end: new Date("2023/08/15"),
  color: "#88CC88",
}
tasks.push(newTask)

gantt
  .task(tasks) // add the tasks
  .period(new Date("2023/08/01"), new Date("2023/08/31")) // show the period from 2023/08/01 to 2023/08/31
  .render() // update the gantt chart

Events

// Selected task event
ganttChartId.addEventListener("selected", (e) => console.log('Task selected', e.detail))

Example VUE

<template>
  <main>
    <form @submit.prevent="update" class="form">
      <input type="date" v-model="start" />
      <input type="date" v-model="end" />
      <button type="submit">Update</button>
      <button type="button" @click="toggleHeaders">Toggle headers</button>
    </form>

    <div ref="gantt" @selected="selectedTask"></div>

    <div>{{ lastSelectedTask }}</div>
  </main>
</template>
<script>
import { GanttChart, ES } from '@miyax/ganttjs'
import '@miyax/ganttjs/src/themes/default.css'

const tasks = [
  {
    id: "1",
    name: "Hello world!!",
    start: new Date("2023/08/1"),
    end: new Date("2023/08/10"),
    color: "#a3d8a3",
  },
  {
    id: "2",
    name: "¡¡Hola mundo!!",
    start: new Date("2023/08/9"),
    end: new Date("2023/08/21"),
    color: "#2ade3c",
    description: "Lorem ipsum dolor sit amet consectetur adipisicing elit. Quisquam, voluptatum.",
  },
]
const gantt = new GanttChart()

export default {
  name: 'App',
  data() {
    return {
      toggleHeader: true,
      lastSelectedTask: {},
      start: '2023-08-01',
      end: '2023-08-31'
    }
  },
  mounted() {
    gantt
      .element(this.$refs.gantt)
      .tasks(tasks)
      .period(new Date("2023/08/01"), new Date("2023/08/31"))
      .widthHeader('350px')
      .withWeekDays()
      .withMonthDay()
      .i18n(ES)
      .render()
  },
  methods: {
    update() {
      const start = new Date(this.start)
      const end = new Date(this.end)
      gantt
        .period(start, end)
        .render()
    },
    toggleHeaders() {
      this.toggleHeader = !this.toggleHeader
      gantt
        .showHeaders(this.toggleHeader)
        .render()
    },
    selectedTask(task) {
      this.lastSelectedTask = task.detail
      console.log(task.detail)
    },
  }
}
</script>
<style scoped>
.form {
  display: flex;
  justify-content: center;
  align-items: center;
  padding: 1rem;
  gap: 1rem;
}
</style>

I18n example

Createa new object with the translations

const ES = {
  daysOfWeek: {
    monday: 'Lunes',
    tuesday: 'Martes',
    wednesday: 'Miércoles',
    thursday: 'Jueves',
    friday: 'Viernes',
    saturday: 'Sábado',
    sunday: 'Domingo',
  },
  monthsOfYear: {
    january: 'Enero',
    february: 'Febrero',
    march: 'Marzo',
    april: 'Abril',
    may: 'Mayo',
    june: 'Junio',
    july: 'Julio',
    august: 'Agosto',
    september: 'Septiembre',
    october: 'Octubre',
    november: 'Noviembre',
    december: 'Diciembre',
  },
  monthsTitle: 'Meses',
  daysTitle: 'Días',
  dayOfweekTitle: 'Días de la semana',
}
