@signalwire/call-widget v3.2.0

SignalWire Call Widget

The Call Widget is a Click-to-Call style JavaScript widget which uses the SignalWire SDK and the SignalWire C2C service to allow you to embed calls in your website.

🌟 New V3 Beta Available!
We've released a new version (V3) of the Call Widget with a completely revamped API, better UI, and support for incoming calls. Skip to V3 Documentation

V2 Documentation

Installation

Import the widget from the CDN:

<script src="https://cdn.jsdelivr.net/npm/@signalwire/call-widget/dist/c2c-widget-full.umd.min.js"></script>

or install the widget using npm:

npm install @signalwire/call-widget

Usage

<style>
  /* This class will be removed from button when the widget fully loads. */
  .demo-button-disabled {
    opacity: 0.7;
    pointer-events: none;
  }
</style>

<!-- Button that triggers the call, wherever in the html -->
<button id="callButton" class="demo-button-disabled">Call</button>

<!-- end of body -->
<c2c-widget
  buttonId="callButton"
  token="<c2c_token or embeds_token>"
  callDetails='{"destination":"/private/demo-1","supportsVideo":false,"supportsAudio":true}'
  collectUserDetails="false"
  survey='{"title":"Please take this survey", "description":"We would love to hear your thoughts. Would you like to take a survey?","href":"https://www.google.com"}'
  userVariables='{"user_type":"guest"}'
></c2c-widget>

<script src="https://cdn.jsdelivr.net/npm/@signalwire/call-widget/dist/c2c-widget-full.umd.min.js"></script>

Parameters

buttonId

The buttonId attribute is used to specify the ID of the HTML button element that will trigger the call.

If the button is not found, the widget will wait for the button to be created. (The button doesn't have to exist in the DOM at the time of widget initialization.)

You can use the class .demo-button-disabled to disable the button while the widget is loading. The widget will remove that particular class once it loads.

<style>
  /* This class will be removed from button when the widget loads.
   */
  .demo-button-disabled {
    opacity: 0.7;
    pointer-events: none;
  }
</style>

token

Authentication token for SignalWire services (either the c2c token from the dashboard, or the embed token).

Using C2C token is getting recommended for most cases. You can get the C2C token from the SignalWire Space dashboard. You can get the embed token using the Embeds Token API.

You can also use any token received from the Call Fabric authentication, assuming it has the necessary permissions to the address.

callDetails

The callDetails object is used to configure the call including destination and media support:

• destination: string - Call destination
• supportsVideo: boolean - Enable/disable video
• supportsAudio: boolean - Enable/disable audio

Strict JSON format is required for this attribute.

collectUserDetails

Whether to show a form collecting user details before starting call.

survey

The survey object is used to configure the post-call survey:

• title: string - Survey modal title (optional, defaults to "Would you like to take a survey?")
• description: string - Survey description text (optional, defaults to "We would love to hear your thoughts. Would you like to take a survey? It only takes 2 minutes.")
• href: string - URL to survey (required)

Don't set this attribute if you don't want a survey to be shown.

Strict JSON format is required for this attribute.

userVariables

Custom variables to attach to the call session. Can be any JSON key:value pair. The following will be overridden by the widget, however:

callOriginHref - the URL of the page where the widget is hosted
userName - the name of the user (if they input it in the form)
userEmail - the email of the user (if they input it in the form)
userPhone - the phone number of the user (if they input it in the form)

Strict JSON format is required for this attribute.

Events

beforecall

This event is triggered when the call is about to start.

const widget = document.querySelector("c2c-widget");
widget.addEventListener("beforecall", () => {
  console.log("beforecall");
});

SignalWire Call Widget V3 (Beta)

A completely revamped version of the Call Widget with a modern API, enhanced UI, and support for incoming calls. V3 offers a more streamlined integration experience and additional features not available in V2.

Key improvements over V2:

• Simpler, more intuitive HTML attribute-based configuration
• Built-in support for incoming calls
• Enhanced UI with multiple window modes
• Better debugging options
• More flexible audio codec configuration

Installation

NPM

npm install @signalwire/call-widget

CDN (jsDelivr)

<script src="https://cdn.jsdelivr.net/npm/@signalwire/call-widget/dist/call-widget-full.min.js"></script>

Quick Start

<button id="myCallButton">Start Call</button>

<call-widget
  button-id="myCallButton"
  token="your_signalwire_token"
  destination="/private/demo"
  support-audio="true"
  support-video="true"
></call-widget>

Attributes Reference

Detailed Attribute Description

Required Attributes

token

Your SignalWire authentication token. This is required for establishing connections.

Example:

<call-widget token="your_signalwire_token"></call-widget>

destination

The destination path for the call. Usually in the format "/private/room-name".

Example:

<call-widget destination="/private/demo-room"></call-widget>

Optional Attributes

window-mode

Controls the layout and features of the call window. Available options:

• video+transcript: Video call with transcript
• video: Video-only interface
• audio+transcript: Audio call with transcript

Example:

<call-widget window-mode="video+transcript"></call-widget>

log-level

Sets the logging verbosity. Available options:

• debug: Most verbose, includes all logs
• info: General information and important events
• warn: Warnings and non-critical issues
• error: Only error messages (default)

Example:

<call-widget log-level="debug"></call-widget>

user-variables

Custom variables passed as a JSON string. All values must be strings.

Example:

<call-widget
  user-variables='{"customerName": "John", "accountId": "123"}'
></call-widget>

audio-codec

Comma-separated list of preferred audio codecs.

Example:

<call-widget audio-codec="opus,PCMU"></call-widget>

Usage Examples

Basic Audio-Only Call Widget

<button id="audioCall">Start Audio Call</button>

<call-widget
  button-id="audioCall"
  token="your_token"
  destination="/private/audio-room"
  support-audio="true"
  support-video="false"
  window-mode="audio+transcript"
></call-widget>

Video Call with Transcription

<button id="videoCall">Start Video Call</button>

<call-widget
  button-id="videoCall"
  token="your_token"
  destination="/private/video-room"
  support-audio="true"
  support-video="true"
  window-mode="video+transcript"
  log-level="info"
></call-widget>

Call Center Agent Setup

<button id="agentConsole">Open Agent Console</button>

<call-widget
  button-id="agentConsole"
  token="your_token"
  destination="/private/agent-room"
  support-audio="true"
  support-video="true"
  receive-calls="true"
  auto-answer="false"
  window-mode="video+transcript"
  user-variables='{"agentId": "agent123", "department": "support"}'
></call-widget>

Notes and best practices

1. Token Security: Never hardcode your SignalWire token in the HTML. Instead, fetch it dynamically from your server. However, you're free to use click2call tokens (c2c_...) statically in HTML.

2. Button Placement: The trigger button can be styled and positioned anywhere in your layout. Just ensure the button-id matches.

3. window-mode vs support-audio and support-video:

• window-mode controls the layout UI of the widget. This is purely cosmetic.
• support-audio and support-video controls the features of the widget. This decides if webcam and/or microphone is used.

Handling Incoming Calls

V3 introduces robust support for incoming calls, making it suitable for call center and customer service applications.

Setting Up Incoming Calls

To enable incoming calls, set the receive-calls attribute to "true". You can also configure automatic answer behavior using auto-answer.

<call-widget
  button-id="agentConsole"
  token="your_token"
  destination="/private/agent-room"
  receive-calls="true"
  auto-answer="false"
  window-mode="video+transcript"
></call-widget>

Incoming Call Behavior

When receive-calls is enabled:

1. The widget listens for incoming calls to the specified destination
2. When a call arrives:
   • If auto-answer="true": The call is automatically answered
   • If auto-answer="false": A notification appears allowing the user to accept or decline
3. The call window opens in the specified window-mode once the call is accepted

Best Practices for Incoming Calls

1. User Experience:
   • Use auto-answer="false" for agent interfaces where call screening is needed
   • Use auto-answer="true" for automated services or IVR systems
2. Window Mode: For agent interfaces, video+transcript mode provides the most comprehensive call handling experience
3. Audio/Video Support: Configure support-audio and support-video based on your use case:

   <call-widget
     receive-calls="true"
     support-audio="true"
     support-video="true"
     window-mode="video+transcript"
   ></call-widget>
