dmn-vscode-extension v0.32.0
DMN Editor
Create and edit DMN and SceSim files.
Features
- Create and edit DMN 1.1 and DMN 1.2 (
.dmn) files. - Create and edit SceSim (
.scesim) files with the Test Scenario Editor. - Native keyboard shortcuts (Press
shift+/to display available combinations). - Export diagram to SVG (use the SVG icon on the top-right corner).
Editing a new DMN file
Editing a SceSim file
DMN files must be inside a src/ folder on your Workspace to be visible on the Test Scenario Editor.
Settings
| Setting | Description | Default value |
|---|---|---|
kogito.dmn.runOnSave | Execute a command on each save operation of the DMN file | empty |
kogito.dmn.svgFilenameTemplate | Filename template to be used when generating SVG files | ${fileBasenameNoExtension}-svg.svg |
kogito.dmn.svgFilePath | Where to save generated SVG files | ${fileDirname} |
The kogito.dmn.svgFilenameTemplate and kogito.dmn.svgFilePath settings accept the following variables as tokens:
| Variable | Example |
|---|---|
| ${workspaceFolder} | /home/your-username/your-project |
| ${fileDirname} | /home/your-username/your-project/folder |
| ${fileExtname} | .ext |
| ${fileBasename} | file.ext |
| ${fileBasenameNoExtension} | file |
