About The Project
NOTE: The package is still under testing and isn't really ready yet for production use. Please feel free to log any issues you face and I will try to fix them ASAP.
There are many great libraries out there to build a tree structure in Javascript. But none of them were simple use or in my case let you build a family tree specifically with multiple scenarios; such as supporting more than one partners or step/foster/adopted children.
This simple tree generator takes your JSON data and builds a family tree using fabricjs on a HTML canvas.
Built With
Vanilla Typescript with fabricjs and packaged using Vite.
Getting Started
Installation
npm install family-tree-generatorUsage
The FamilyTree constructor requires you to pass the root node along with following canvas options:
- id: ID of the HTML canvas element in the DOM on which the fabric canvas must be initialized.
- width: The canvas's width.
- height: The canvas's height.
- boundToParentSize: Sets the height and with to the parent elements clientHeight and clientWidth respectively.
import FamilyTree, { Node } from './FamilyTree';
const root = {
id: 1,
name: 'Test1',
image:
'https://png.pngtree.com/png-vector/20220709/ourmid/pngtree-businessman-user-avatar-wearing-suit-with-red-tie-png-image_5809521.png',
generation: 0,
onClick: (node) => {
console.log(node);
},
relationships: [
{
partner: {
id: 2,
name: 'Test2',
onClick(node) {
console.log(node);
},
},
isMarried: true,
children: [
{
id: 3,
name: 'Test3',
generation: 1,
relationships: [
{
partner: {
id: 4,
name: 'Test4',
},
isMarried: true,
children: [
{
id: 5,
name: 'Test5',
generation: 2,
},
],
},
{
partner: {
id: 25,
name: 'Test25',
},
isMarried: true,
children: [
{
id: 26,
name: 'Test26',
generation: 2,
},
],
},
{
partner: {
id: 27,
name: 'Test27',
},
isMarried: false,
children: [
{
id: 28,
name: 'Test28',
generation: 2,
},
],
},
],
},
{
id: 6,
name: 'Test6',
generation: 1,
relationships: [
{
partner: {
id: 7,
image:
'https://png.pngtree.com/png-vector/20220709/ourmid/pngtree-businessman-user-avatar-wearing-suit-with-red-tie-png-image_5809521.png',
name: 'Test7',
},
isMarried: true,
children: [
{
id: 8,
name: 'Test8',
generation: 2,
relationships: [
{
partner: {
id: 9,
name: 'Test9',
},
isMarried: true,
},
],
},
],
},
],
},
{
id: 10,
name: 'Test10',
generation: 1,
relationships: [
{
partner: {
id: 11,
name: 'Test11',
},
isMarried: true,
children: [
{
id: 12,
name: 'Test12',
generation: 2,
relationships: [
{
partner: {
id: 13,
name: 'Test13',
},
isMarried: true,
children: [
{
id: 14,
name: 'Test14',
generation: 3,
},
],
},
],
},
],
},
],
},
{
id: 15,
name: 'Test15',
generation: 1,
relationships: [
{
partner: {
id: 16,
name: 'Test16',
},
isMarried: true,
children: [
{
id: 17,
name: 'Test17',
image:
'https://png.pngtree.com/png-vector/20220709/ourmid/pngtree-businessman-user-avatar-wearing-suit-with-red-tie-png-image_5809521.png',
generation: 2,
relationships: [
{
partner: {
id: 18,
name: 'Test18',
},
isMarried: true,
},
],
},
{
id: 19,
name: 'Test19',
generation: 2,
relationships: [
{
partner: {
id: 20,
name: 'Test20',
},
isMarried: true,
children: [
{
id: 21,
name: 'Test21',
generation: 3,
},
],
},
],
},
],
},
],
},
{
id: 22,
name: 'Test22',
generation: 1,
relationships: [
{
children: [
{
id: 24,
name: 'Test24',
generation: 2,
},
],
},
],
},
],
},
],
} as Node;
const familyTree = new FamilyTree(root, {
id: 'canvas',
width: 1920,
height: 1080,
});
familyTree.drawTree();There are two types exposed by the module
export interface Relation {
partner: Node | undefined;
isMarried: boolean | undefined;
children: Node[];
_relation?: fabric.Line;
_parentLine?: fabric.Line;
}
export interface Node {
id: string | number;
name: string;
image?: string;
generation?: number;
relationships: Relation[];
onClick?: (node: Node) => void;
_object?: fabric.Group;
_childLine: fabric.Group;
}Node
- id: A unique identifier for each node.
- name: Name of the node that is displayed in the tree.
- image: URL for the node image. If none is provided, the default one is used.
- generation: The family generation to which the node belongs to.
- relationships: A list of all the relationships of the current node.
- onClick: An
onclickcallback can be provided for the node which gives you back the corresponding node that was clicked as a parameter.
Relation
- partner: The partner node. If skipped, the child relation is draw from the current node.
- isMarried: If true, the partner relation line is drawn as a solid line. Otherwise, a dashed line is drawn.
- children: A list of child nodes.
Canvas
The fabric canvas object can be accessed as follows
const familyTree = new FamilyTree(root, {
id: 'canvas',
width: 1920,
height: 1080,
});
familyTree.canvas.renderAll();Zoom and pan
- Use the mouse wheel to zoom in and out when hovering over the canvas.
- To pan, just hold down the left mouse button and move the mouse around on the canvas or on touch screen, use pinch zoom.
- To reset the zoom and pan back to center, double click the left mouse button or long press on touch screen on the canvas.
License
Distributed under the MIT License. See LICENSE for more information.
Authors
- Ranjith R Shenoy - An enthusiastic software developer - Ranjith R Shenoy
