gatsby-mdx-remote v1.0.20

Description

This is a minimal transformation plugin that takes sourced nodes and builds MDX File nodes out of them, with configurable node locations for the mdx field to use, and where to source the frontmatter.

Multiple source node type are supported with individual configurations. Each source node type can be configured independently to preprocess images with sharp, which is the default behaviour.

This plugin extends the functionality of gatsby-plugin-mdx by creating mdx nodes from other nodes programatically.

Developed to be used for building MDX-based static websites out of TerminusDB data products hosted at DFRNT.com, accessed via GraphQL. But it should be applicable for most remote MDX/Markdown with images and any GraphQL capable TerminusDB open source or hosted instance.

The frontmatter is expected to be part of the sourced node, and not the MDX contents. PRs and issues are welcome to add additional capabilities to the plugin!

Dependencies

For this plugin to work, the following dependencies are recommended:

• gatsby-source-filesystem
• gatsby-plugin-mdx
• use at least one .mdx file from the local filesystem (to populate the GraphQL types properly)

If preprocessing images (the default behaviour):

• gatsby-plugin-image
• gatsby-plugin-sharp
• gatsby-transformer-sharp

Learning Resources

Review the MDX documentation first, and make local MDX files work before starting to work with remote nodes.

In essence, this is how remote MDX processing works:

1. In the sourceNodes API or through a plugin that does this step automatically, Gatsby content nodes are created. They will contain data as objects in the Gatsby Node structure.
2. MDX nodes are usually created from files, using the gatsby-source-filesystem plugin. When creating nodes from remote content, MDX File nodes needs to be created programmatically.
3. This plugin picks up specific node types through the onCreateNode API and extracts a frontmatter object to be converted into yaml frontmatter, and also extracts an mdx string from selected node types.
4. Once an mdx string with yaml frontmatter have been concatenated together, it is written as a File node with the .mdx extension into the Gatsby cache
5. The gatsby-plugin-mdx plugin picks up the MDX File object as usual and transforms it into an Mdx node that can be rendered as any other MDX content.

How to install

🚀 Quick start, step 1: prerequisites

To get started with this plugin, you need to have a working MDX support. To support querying for frontmatter and body, at least one local MDX file must exist.

1. Configure MDX according to the MDX documentation
   1. Get a first MDX file working, sourced from the filesystem, and example at ./src/pages/mypage.mdx.
   2. Once you have a working MDX configuration and you can see your mypage.mdx rendered properly (converted to html), you can add support for programmatic creation of MDX File nodes below (such as sourced from a remote location)
2. Install this plugin and prerequisites
3. Configure the nodes to pick up and their fields
4. Restart gatsby and if necessary, make a gatsby clean

2. Install plugin and prerequisites

npm install gatsby-mdx-remote @mdx-js/react

3. Configure the plugins in gatsby-config.js

module.exports = {
  plugins: [
    {
      resolve: "gatsby-source-filesystem",
      options: {
        name: "pages",
        path: "./src/pages/",
      },
      __key: "pages",
    },
    {
      resolve: `gatsby-mdx-remote`,
      options: {
        mdxNodeTypes: {
          "MyNodeType": {
            // If a hierarchy of objects is to be traversed, use a dot (.) for each level
            mdxField: "statement.markdown",
            mdxFrontmatterField: "frontmatter",
            preprocessImages: true,
            gatsbyImageClassName: "rounded-md",
          }
        },
        frontmatterSharpRemoteImageUrlArrayField: "imageList",
      }
    },
    `gatsby-plugin-image`,
    `gatsby-plugin-sharp`,
    `gatsby-transformer-sharp`,
    {
      resolve: `gatsby-plugin-mdx`,
      options: {
        gatsbyRemarkPlugins: [
          {
            // The regular gatsby-remark-images does not support remote images.
            // A different plugin may be required
            resolve: `gatsby-remark-images`,
            options: {
              maxWidth: 1200,
            },
          },
        ],
      },
    },

  ],
}

4. Start gatsby

gatsby develop

Options

The plugin supports options to ignore files and to pass options to the slugify instance that is used in the File System Route API to create slugs.

Top level options object

mdxNodeTypes object

The object field separator is ., for traversing the object hierarchy applies for mdxField and mdxFrontmatterField fields. Normal local MDX files are not affected by the plugin, but there needs to be at least one MDX file for the frontmatter fields to be loaded correctly. frontmatterSharpRemoteImageUrlArrayField is not traversed with . dot notation.

Check the troubleshooting section for more information about the required local MDX files for proper MDX typings.

Example configuration options below:

module.exports = {
  plugins: [
    {
      resolve: `gatsby-mdx-remote`,
      options: {
        mdxNodeTypes: {
          "MyNodeType": {
            // If a hierarchy of objects is to be traversed, use a dot (.) for each level
            mdxField: "statement.markdown",
            mdxFrontmatterField: "frontmatter",
            preprocessImages: true // defaults to true, set to false for <img/> tags for images
          }
        },
        frontmatterSharpRemoteImageUrlArrayField: "imageList",
      }
    }
  ]
}

Example source node for the above configuration.

const myData = {
  frontmatter: {
    author: "John Doe",
    slug: `blog/blogpost`,
    title: `John Does first blogpost`
  },
  statement: { markdown: `# Hello world\n\nHello world text` }
};

Do note that all markdown image nodes ![]() will be represented as an array in the frontmatter as imageList. The produced Mdx nodes have a resolver attached as images that resolve each downloaded file that get used with the image replacement.

When do I use this plugin?

When you are sourcing remote MDX data, you need to get it into the Gatsby cache first. This plugin helps you accomplish creating locally cached MDX data. It replaced the previous functionality offered through createMDXNode previously available in gatsby-plugin-mdx/utils/create-mdx-node, and other similar solutions before Gatsby 5.

This plugin does not, and should probably not, handle any other tasks such as bringing sharp images and similar functionality. Such things should be handled through plugins in the regular MDX ecosystem.

It could be that frontmatter should optionally be part of the MDX string itself, but is left as an option for the future (or a pull request).

Example sourceNodes as a reference

Using this example, to be used in gatsby-node.js, an MDX File node is created from an arbitrary string. Once created in sourceNodes, it uses the example configuration above, and becomes rendered through the created paged section next.

gatsby-node.js sourceNodes section

If you're not using @dfrnt/gatsby-source-graphql-nodes to source nodes from a GraphQL endpoint, you can create them programmatically and manually from almost any source that you can get MDX data into your sourceNodes section, using a section like below:

Note that the frontmatter data must be located in data/frontmatter in the produced node.

If you need to create nodes from other content nodes, you should be able to create onwards nodes using the Gatsby onCreateNode API. A documentation PR for this could probably be helful for the community.

For the example below, don't forget to add GatsbyImage to your trusted MDX components!

exports.sourceNodes = ({ actions, createNodeId, createContentDigest }) => {
  const { createNode } = actions
    // Data can come from anywhere, and let's create an MDX node programmatically from some data
  const frontmatter = {
    author: "John Doe",
    slug: `blog/blogpost`,
    title: `John Doe's first blogpost`,
    imageList: ["https://images.unsplash.com/photo-1522262139463-236991a708cb?ixlib=rb-4.0.3&ixid=MnwxMjA3fDB8MHxwaG90by1wYWdlfHx8fGVufDB8fHx8&auto=format&fit=crop&w=1920&q=80"]
  }

  const content = {
    mdx: `# Hello world\n\nHello world text\n\n<GatsbyImage alt="test 0" image={getImage(props.pageContext.imageList[0]?.childImageSharp?.gatsbyImageData)}/>\n\n![Sign you've been looking for](https://images.unsplash.com/photo-1496449903678-68ddcb189a24?ixlib=rb-4.0.3&ixid=MnwxMjA3fDB8MHxwaG90by1wYWdlfHx8fGVufDB8fHx8&auto=format&fit=crop&w=1920&q=80)`,
    id: `my-data-${12345}`,
  }
  const gatsbyMdxContent = {
    frontmatter,
    statement: { markdown: content.mdx }
  };
  const nodeContent = JSON.stringify(gatsbyMdxContent)

  const gatsbyNodeMeta = {
    id: createNodeId(content.id),
    parent: null,
    children: [],
    internal: {
      type: `MyNodeType`,
      mediaType: `text/markdown`,
      content: nodeContent,
      contentDigest: createContentDigest(gatsbyMdxContent)
    }
  }

  const node = Object.assign({}, { data: gatsbyMdxContent }, gatsbyNodeMeta)

  createNode(node)
}

gatsby-node.js createPages section

In below createPages example we use getNode() to resolve the node. The reason is that there is some interoperability issue, where at least one local mdx node is required for the GraphQL types to be properly created. Using createPages like below is a workaround for that issue.

Therefore the suggestion to create at least one real local MDX file, any page really, so that the GraphQL configuration is updated for Mdx nodes. If so, a regular GraphQL query can be used.

Out of your original node, "MyNodeType", an "mdxMyNodeType" will be created that contains the childMdx node pointing to the Mdx node.

exports.createPages = async ({ graphql, actions, reporter, getNode }) => {
  const { createPage, createNode } = actions;
  const result= await graphql(`
    query {
      allMyNodeType {
        nodes {
          childMdx {
            id
            markdownImageList {
              childImageSharp {
                gatsbyImageData
              }
            }
            imageList {
              childImageSharp {
                gatsbyImageData
              }
            }
            internal {
              contentFilePath
            }
          }
        }
      }
    }
  `);

  result.data.allMyNodeType.nodes.map(node => node.childMdx).forEach(node => {
    // If for some reason, the fields are not showing up in GraphQL, this is a workaround...
    // happened initially, seems to work normally now though, but could help someone maybe.
    const mdxNode = getNode(node.id);
    createPage({
      path: `/${(mdxNode?.frontmatter).slug}`,
      // When querying for MDX nodes directly and using a template
      //   component: path.resolve(`./src/layouts/page.jsx?__contentFilePath=${mdxNode?.internal.contentFilePath}`),
      // If using the original rich content node, iterate the childMdx instead in the forEach above
      // Using the MDX node directly
      component: mdxNode?.internal.contentFilePath,
      ownerNodeId: `dfrnt-graphql`,
      // The context is passed as props to the component as well
      // as into the component's GraphQL query.
      context: {
        ...mdxNode,
      },
    });
  });
};

Troubleshooting

Must have at least one local MDX file for the plugin to work

There is likely some kind of bug if there are no .MDX files in the local filesystem. What happens is that MDX definitions will not be created if a local .mdx file is not present.

How to reference remote frontmatter imageList images

Example GatsbyImage MDX component for referencing an imageList image when frontmatterSharpRemoteImageUrlArrayField has been set to imageList:

<GatsbyImage alt="test 0" image={getImage(props.pageContext.imageList[0]?.childImageSharp?.gatsbyImageData)}/>

Note that the original URL stays in the frontmatter verbatim, and a section is added onto the MDX node with the transformed field name (under the same name as in the frontmatter field).

The transformed markdown images will instead be available in the markdownImageList frontmatter and node fields respectively.

Add the relevant fields to you page query so they can be used in the MDX

The fields that are referenced to render the images (if preprocessing with sharp) must be available in the pageContext (props.pageContext.images.childImageSharp.gatsbyImageData), you will likely also need the frontmatter.imageList.

  query {
    allMdx {
      nodes {
        id
        imageList {
          childImageSharp {
            gatsbyImageData
          }
        }
        markdownImageList {
          childImageSharp {
            gatsbyImageData
          }
        }
        internal {
          contentFilePath
        }
        frontmatter {
          slug
          imageList
          title
        }
      }
    }
  }

Can't find imageList (and markdownImageList) in frontmatter

There seems to be a bug in remote MDX processing in that a local MDX file must exist with the target MDX frontmatter type configuration. Otherwise the schema will not be created correctly.

Create an MDX file that looks like this in a location where MDX files are loaded:

---
slug: no/content
title: Empty file
imageList:
- https://upload.wikimedia.org/wikipedia/en/a/a9/Example.jpg
---

No content

This will ensure that MDX files have slug, title and imageList properties. If the imageList array does not exist for the frontmatter, the remote image preprocessing will not work.

Make sure to always query for markdownImageList if you have images in your MDX file and preprocess images!

In general

The MDX relies on a correct cache. Many things are helped by starting over with the cache, using gatsby clean. Depending on your situation, it can be helpful to try!

How to develop locally

git clone https://github.com/dfrnt-com/gatsby-mdx-remote
npm install

It is suggested to run npm link in the directory, and then run npm link gatsby-mdx-remote in the example-site used for development.

Opportunities to contribute (suggestions for PRs)

• Make frontmatterSharpRemoteImageUrlArrayField applicable per type
• Make frontmatterSharpRemoteImageUrlArrayField traversable maybe?
• Add onCreateNode documentation for producing one node from another for ingestion.

How to contribute

If you have unanswered questions, would like help with enhancing or debugging the plugin, add issues and pull requests to dfrnt-com/gatsby-mdx-remote.

This is a project offered as-is to the community under the MIT license. Contributions are more than welcome! Please visit the DFRNT data product builder to learn more about building websites from knowledge graphs using data products with strong data models in TerminusDB data products.
