iobroker.cmicoe v0.3.1

ioBroker.cmicoe

Tests:

cmicoe adapter for ioBroker

Adapter to communicate with the CMI by Technische Alternative via CoE

DISCLAIMER

This application is an independent product and is not affiliated with, endorsed by, or sponsored by Technische Alternative. All trademarks, logos, and brand names are the property of their respective owners. This application is designed to work with the C.M.I. but is not an official product of Technische Alternative. Compatibility with all versions of the device cannot be guaranteed.

Installation

After installing the adapter open the configuration and put in the ip address of the C.M.I. and you should already receive data from the C.M.I. Note: you cannot create two instances of this adapter, because it has to bind to the local port 5442! To receive data you have to create a CoE output on the CMI webpage and then the data is displayed in the iobroker state in.node<node>.<analog|digital><output>, e.g. in.node25.analog3. To send data the outputs have to be specified in the configuration. Enter all the nodes comma-seperated like this: <node>/<a|d><out>, e.g. 25/d1,25/a2 Additionally the interval in which the values are sent can be specified and if the data should also be sent if it has changed.

Changelog

0.3.1 (2025-02-18)

• fix: negative values crashed adapter

0.3.0 (2025-02-17)

• added support for multiple messages in one packet (receiving and sending)
• added error handling

0.2.0 (2025-02-17)

• created bind and port options

0.1.2 (2025-02-17)

• downgrade to node 18
• create channel/devices before states
• performance improvements

0.1.1 (2025-02-16)

• improved log messages
• added log message if address/ip are already in use (probably two instances started)

0.1.0 (2025-02-16)

• (FreDeko) initial release
