Learn more at pdf-lib.js.org

Table of Contents

Features

  • Create new PDFs
  • Modify existing PDFs
  • Add Pages
  • Insert Pages
  • Remove Pages
  • Copy pages between PDFs
  • Draw Text
  • Draw Images
  • Draw PDF Pages
  • Draw Vector Graphics
  • Draw SVG Paths
  • Measure width and height of text
  • Embed Fonts (supports UTF-8 and UTF-16 character sets)
  • Set document metadata
  • Read document metadata
  • Add attachments

Motivation

pdf-lib was created to address the JavaScript ecosystem's lack of robust support for PDF manipulation (especially for PDF modification).

Two of pdf-lib's distinguishing features are:

  1. Supporting modification (editing) of existing documents.
  2. Working in all JavaScript environments - not just in Node or the Browser.

There are other good open source JavaScript PDF libraries available. However, most of them can only create documents, they cannot modify existing ones. And many of them only work in particular environments.

Usage Examples

Create Document

This example produces this PDF.

Try the JSFiddle demo

import { PDFDocument, StandardFonts, rgb } from 'pdf-lib'

// Create a new PDFDocument
const pdfDoc = await PDFDocument.create()

// Embed the Times Roman font
const timesRomanFont = await pdfDoc.embedFont(StandardFonts.TimesRoman)

// Add a blank page to the document
const page = pdfDoc.addPage()

// Get the width and height of the page
const { width, height } = page.getSize()

// Draw a string of text toward the top of the page
const fontSize = 30
page.drawText('Creating PDFs in JavaScript is awesome!', {
  x: 50,
  y: height - 4 * fontSize,
  size: fontSize,
  font: timesRomanFont,
  color: rgb(0, 0.53, 0.71),
})

// Serialize the PDFDocument to bytes (a Uint8Array)
const pdfBytes = await pdfDoc.save()

// For example, `pdfBytes` can be:
//   • Written to a file in Node
//   • Downloaded from the browser
//   • Rendered in an <iframe>

Modify Document

This example produces this PDF (when this PDF is used for the existingPdfBytes variable).

Try the JSFiddle demo

import { degrees, PDFDocument, rgb, StandardFonts } from 'pdf-lib';

// This should be a Uint8Array or ArrayBuffer
// This data can be obtained in a number of different ways
// If your running in a Node environment, you could use fs.readFile()
// In the browser, you could make a fetch() call and use res.arrayBuffer()
const existingPdfBytes = ...

// Load a PDFDocument from the existing PDF bytes
const pdfDoc = await PDFDocument.load(existingPdfBytes)

// Embed the Helvetica font
const helveticaFont = await pdfDoc.embedFont(StandardFonts.Helvetica)

// Get the first page of the document
const pages = pdfDoc.getPages()
const firstPage = pages[0]

// Get the width and height of the first page
const { width, height } = firstPage.getSize()

// Draw a string of text diagonally across the first page
firstPage.drawText('This text was added with JavaScript!', {
  x: 5,
  y: height / 2 + 300,
  size: 50,
  font: helveticaFont,
  color: rgb(0.95, 0.1, 0.1),
  rotate: degrees(-45),
})


// Serialize the PDFDocument to bytes (a Uint8Array)
const pdfBytes = await pdfDoc.save()

// For example, `pdfBytes` can be:
//   • Written to a file in Node
//   • Downloaded from the browser
//   • Rendered in an <iframe>

Copy Pages

This example produces this PDF (when this PDF is used for the firstDonorPdfBytes variable and this PDF is used for the secondDonorPdfBytes variable).

Try the JSFiddle demo

import { PDFDocument } from 'pdf-lib'

// Create a new PDFDocument
const pdfDoc = await PDFDocument.create()

// These should be Uint8Arrays or ArrayBuffers
// This data can be obtained in a number of different ways
// If your running in a Node environment, you could use fs.readFile()
// In the browser, you could make a fetch() call and use res.arrayBuffer()
const firstDonorPdfBytes = ...
const secondDonorPdfBytes = ...

// Load a PDFDocument from each of the existing PDFs
const firstDonorPdfDoc = await PDFDocument.load(firstDonorPdfBytes)
const secondDonorPdfDoc = await PDFDocument.load(secondDonorPdfBytes)

// Copy the 1st page from the first donor document, and
// the 743rd page from the second donor document
const [firstDonorPage] = await pdfDoc.copyPages(firstDonorPdfDoc, [0])
const [secondDonorPage] = await pdfDoc.copyPages(secondDonorPdfDoc, [742])

// Add the first copied page
pdfDoc.addPage(firstDonorPage)

// Insert the second copied page to index 0, so it will be the
// first page in `pdfDoc`
pdfDoc.insertPage(0, secondDonorPage)

// Serialize the PDFDocument to bytes (a Uint8Array)
const pdfBytes = await pdfDoc.save()

// For example, `pdfBytes` can be:
//   • Written to a file in Node
//   • Downloaded from the browser
//   • Rendered in an <iframe>

Embed PNG and JPEG Images

This example produces this PDF (when this image is used for the jpgImageBytes variable and this image is used for the pngImageBytes variable).

Try the JSFiddle demo

import { PDFDocument } from 'pdf-lib'

// These should be Uint8Arrays or ArrayBuffers
// This data can be obtained in a number of different ways
// If your running in a Node environment, you could use fs.readFile()
// In the browser, you could make a fetch() call and use res.arrayBuffer()
const jpgImageBytes = ...
const pngImageBytes = ...

// Create a new PDFDocument
const pdfDoc = await PDFDocument.create()

// Embed the JPG image bytes and PNG image bytes
const jpgImage = await pdfDoc.embedJpg(jpgImageBytes)
const pngImage = await pdfDoc.embedPng(pngImageBytes)

// Get the width/height of the JPG image scaled down to 25% of its original size
const jpgDims = jpgImage.scale(0.25)

// Get the width/height of the PNG image scaled down to 50% of its original size
const pngDims = pngImage.scale(0.5)

// Add a blank page to the document
const page = pdfDoc.addPage()

// Draw the JPG image in the center of the page
page.drawImage(jpgImage, {
  x: page.getWidth() / 2 - jpgDims.width / 2,
  y: page.getHeight() / 2 - jpgDims.height / 2,
  width: jpgDims.width,
  height: jpgDims.height,
})

// Draw the PNG image near the lower right corner of the JPG image
page.drawImage(pngImage, {
  x: page.getWidth() / 2 - pngDims.width / 2 + 75,
  y: page.getHeight() / 2 - pngDims.height,
  width: pngDims.width,
  height: pngDims.height,
})

// Serialize the PDFDocument to bytes (a Uint8Array)
const pdfBytes = await pdfDoc.save()

// For example, `pdfBytes` can be:
//   • Written to a file in Node
//   • Downloaded from the browser
//   • Rendered in an <iframe>

Embed PDF Pages

This example produces this PDF (when this PDF is used for the americanFlagPdfBytes variable and this PDF is used for the usConstitutionPdfBytes variable).

Try the JSFiddle demo

import { PDFDocument } from 'pdf-lib'

// These should be Uint8Arrays or ArrayBuffers
// This data can be obtained in a number of different ways
// If your running in a Node environment, you could use fs.readFile()
// In the browser, you could make a fetch() call and use res.arrayBuffer()
const americanFlagPdfBytes = ...
const usConstitutionPdfBytes = ...

// Create a new PDFDocument
const pdfDoc = await PDFDocument.create()

// Embed the American flag PDF bytes
const [americanFlag] = await pdfDoc.embedPdf(americanFlagPdfBytes)

// Load the U.S. constitution PDF bytes
const usConstitutionPdf = await PDFDocument.load(usConstitutionPdfBytes)

// Embed the second page of the constitution and clip the preamble
const preamble = await pdfDoc.embedPage(usConstitutionPdf.getPages()[1], {
  left: 55,
  bottom: 485,
  right: 300,
  top: 575,
})

// Get the width/height of the American flag PDF scaled down to 30% of
// its original size
const americanFlagDims = americanFlag.scale(0.3)

// Get the width/height of the preamble clipping scaled up to 225% of
// its original size
const preambleDims = preamble.scale(2.25)

// Add a blank page to the document
const page = pdfDoc.addPage()

// Draw the American flag image in the center top of the page
page.drawPage(americanFlag, {
  ...americanFlagDims,
  x: page.getWidth() / 2 - americanFlagDims.width / 2,
  y: page.getHeight() - americanFlagDims.height - 150,
})

// Draw the preamble clipping in the center bottom of the page
page.drawPage(preamble, {
  ...preambleDims,
  x: page.getWidth() / 2 - preambleDims.width / 2,
  y: page.getHeight() / 2 - preambleDims.height / 2 - 50,
})

// Serialize the PDFDocument to bytes (a Uint8Array)
const pdfBytes = await pdfDoc.save()

// For example, `pdfBytes` can be:
//   • Written to a file in Node
//   • Downloaded from the browser
//   • Rendered in an <iframe>

Embed Font and Measure Text

pdf-lib relies on a sister module to support embedding custom fonts: @pdf-lib/fontkit. You must add the @pdf-lib/fontkit module to your project and register it using pdfDoc.registerFontkit(...) before embedding custom fonts.

See below for detailed installation instructions on installing @pdf-lib/fontkit as a UMD or NPM module.

This example produces this PDF (when this font is used for the fontBytes variable).

Try the JSFiddle demo

import { PDFDocument, rgb } from 'pdf-lib'
import fontkit from '@pdf-lib/fontkit'

// This should be a Uint8Array or ArrayBuffer
// This data can be obtained in a number of different ways
// If you're running in a Node environment, you could use fs.readFile()
// In the browser, you could make a fetch() call and use res.arrayBuffer()
const fontBytes = ...

// Create a new PDFDocument
const pdfDoc = await PDFDocument.create()

// Register the `fontkit` instance
pdfDoc.registerFontkit(fontkit)

// Embed our custom font in the document
const customFont = await pdfDoc.embedFont(fontBytes)

// Add a blank page to the document
const page = pdfDoc.addPage()

// Create a string of text and measure its width and height in our custom font
const text = 'This is text in an embedded font!'
const textSize = 35
const textWidth = customFont.widthOfTextAtSize(text, textSize)
const textHeight = customFont.heightAtSize(textSize)

// Draw the string of text on the page
page.drawText(text, {
  x: 40,
  y: 450,
  size: textSize,
  font: customFont,
  color: rgb(0, 0.53, 0.71),
})

// Draw a box around the string of text
page.drawRectangle({
  x: 40,
  y: 450,
  width: textWidth,
  height: textHeight,
  borderColor: rgb(1, 0, 0),
  borderWidth: 1.5,
})

// Serialize the PDFDocument to bytes (a Uint8Array)
const pdfBytes = await pdfDoc.save()

// For example, `pdfBytes` can be:
//   • Written to a file in Node
//   • Downloaded from the browser
//   • Rendered in an <iframe>

Add Attachments

This example produces this PDF (when this image is used for the jpgAttachmentBytes variable and this PDF is used for the pdfAttachmentBytes variable).

Try the JSFiddle demo

import { PDFDocument } from 'pdf-lib'

// These should be Uint8Arrays or ArrayBuffers
// This data can be obtained in a number of different ways
// If your running in a Node environment, you could use fs.readFile()
// In the browser, you could make a fetch() call and use res.arrayBuffer()
const jpgAttachmentBytes = ...
const pdfAttachmentBytes = ...

// Create a new PDFDocument
const pdfDoc = await PDFDocument.create()

// Add the JPG attachment
await pdfDoc.attach(jpgAttachmentBytes, 'cat_riding_unicorn.jpg', {
  mimeType: 'image/jpeg',
  description: 'Cool cat riding a unicorn! 🦄🐈🕶️',
  creationDate: new Date('2019/12/01'),
  modificationDate: new Date('2020/04/19'),
})

// Add the PDF attachment
await pdfDoc.attach(pdfAttachmentBytes, 'us_constitution.pdf', {
  mimeType: 'application/pdf',
  description: 'Constitution of the United States 🇺🇸🦅',
  creationDate: new Date('1787/09/17'),
  modificationDate: new Date('1992/05/07'),
})

// Add a page with some text
const page = pdfDoc.addPage();
page.drawText('This PDF has two attachments', { x: 135, y: 415 })

// Serialize the PDFDocument to bytes (a Uint8Array)
const pdfBytes = await pdfDoc.save()

// For example, `pdfBytes` can be:
//   • Written to a file in Node
//   • Downloaded from the browser
//   • Rendered in an <iframe>

Set Document Metadata

This example produces this PDF.

Try the JSFiddle demo

import { PDFDocument, StandardFonts } from 'pdf-lib'

// Create a new PDFDocument
const pdfDoc = await PDFDocument.create()

// Embed the Times Roman font
const timesRomanFont = await pdfDoc.embedFont(StandardFonts.TimesRoman)

// Add a page and draw some text on it
const page = pdfDoc.addPage([500, 600])
page.setFont(timesRomanFont)
page.drawText('The Life of an Egg', { x: 60, y: 500, size: 50 })
page.drawText('An Epic Tale of Woe', { x: 125, y: 460, size: 25 })

// Set all available metadata fields on the PDFDocument. Note that these fields
// are visible in the "Document Properties" section of most PDF readers.
pdfDoc.setTitle('🥚 The Life of an Egg 🍳')
pdfDoc.setAuthor('Humpty Dumpty')
pdfDoc.setSubject('📘 An Epic Tale of Woe 📖')
pdfDoc.setKeywords(['eggs', 'wall', 'fall', 'king', 'horses', 'men'])
pdfDoc.setProducer('PDF App 9000 🤖')
pdfDoc.setCreator('pdf-lib (https://github.com/Hopding/pdf-lib)')
pdfDoc.setCreationDate(new Date('2018-06-24T01:58:37.228Z'))
pdfDoc.setModificationDate(new Date('2019-12-21T07:00:11.000Z'))

// Serialize the PDFDocument to bytes (a Uint8Array)
const pdfBytes = await pdfDoc.save()

// For example, `pdfBytes` can be:
//   • Written to a file in Node
//   • Downloaded from the browser
//   • Rendered in an <iframe>

Read Document Metadata

Try the JSFiddle demo

import { PDFDocument } from 'pdf-lib'

// This should be a Uint8Array or ArrayBuffer
// This data can be obtained in a number of different ways
// If your running in a Node environment, you could use fs.readFile()
// In the browser, you could make a fetch() call and use res.arrayBuffer()
const existingPdfBytes = ...

// Load a PDFDocument without updating its existing metadata
const pdfDoc = await PDFDocument.load(existingPdfBytes, {
  updateMetadata: false
})

// Print all available metadata fields
console.log('Title:', pdfDoc.getTitle())
console.log('Author:', pdfDoc.getAuthor())
console.log('Subject:', pdfDoc.getSubject())
console.log('Creator:', pdfDoc.getCreator())
console.log('Keywords:', pdfDoc.getKeywords())
console.log('Producer:', pdfDoc.getProducer())
console.log('Creation Date:', pdfDoc.getCreationDate())
console.log('Modification Date:', pdfDoc.getModificationDate())

This script outputs the following (when this PDF is used for the existingPdfBytes variable):

Title: Microsoft Word - Basic Curriculum Vitae example.doc
Author: Administrator
Subject: undefined
Creator: PScript5.dll Version 5.2
Keywords: undefined
Producer: Acrobat Distiller 8.1.0 (Windows)
Creation Date: 2010-07-29T14:26:00.000Z
Modification Date: 2010-07-29T14:26:00.000Z

Draw SVG Paths

This example produces this PDF.

Try the JSFiddle demo

import { PDFDocument, rgb } from 'pdf-lib'

// SVG path for a wavy line
const svgPath =
  'M 0,20 L 100,160 Q 130,200 150,120 C 190,-40 200,200 300,150 L 400,90'

// Create a new PDFDocument
const pdfDoc = await PDFDocument.create()

// Add a blank page to the document
const page = pdfDoc.addPage()
page.moveTo(100, page.getHeight() - 5)

// Draw the SVG path as a black line
page.moveDown(25)
page.drawSvgPath(svgPath)

// Draw the SVG path as a thick green line
page.moveDown(200)
page.drawSvgPath(svgPath, { borderColor: rgb(0, 1, 0), borderWidth: 5 })

// Draw the SVG path and fill it with red
page.moveDown(200)
page.drawSvgPath(svgPath, { color: rgb(1, 0, 0) })

// Draw the SVG path at 50% of its original size
page.moveDown(200)
page.drawSvgPath(svgPath, { scale: 0.5 })

// Serialize the PDFDocument to bytes (a Uint8Array)
const pdfBytes = await pdfDoc.save()

// For example, `pdfBytes` can be:
//   • Written to a file in Node
//   • Downloaded from the browser
//   • Rendered in an <iframe>

Deno Usage

pdf-lib fully supports the exciting new Deno runtime! All of the usage examples work in Deno. The only thing you need to do is change the imports for pdf-lib and @pdf-lib/fontkit to use the Pika CDN, because Deno requires all modules to be referenced via URLs.

See also How to Create and Modify PDF Files in Deno With pdf-lib

Creating a Document with Deno

Below is the create document example modified for Deno:

import {
  PDFDocument,
  StandardFonts,
  rgb,
} from 'https://cdn.pika.dev/pdf-lib@^1.6.0';

const pdfDoc = await PDFDocument.create();
const timesRomanFont = await pdfDoc.embedFont(StandardFonts.TimesRoman);

const page = pdfDoc.addPage();
const { width, height } = page.getSize();
const fontSize = 30;
page.drawText('Creating PDFs in JavaScript is awesome!', {
  x: 50,
  y: height - 4 * fontSize,
  size: fontSize,
  font: timesRomanFont,
  color: rgb(0, 0.53, 0.71),
});

const pdfBytes = await pdfDoc.save();

await Deno.writeFile('out.pdf', pdfBytes);

If you save this script as create-document.ts, you can execute it using Deno with the following command:

deno run --allow-write create-document.ts

The resulting out.pdf file will look like this PDF.

Embedding a Font with Deno

Here's a slightly more complicated example demonstrating how to embed a font and measure text in Deno:

import {
  degrees,
  PDFDocument,
  rgb,
  StandardFonts,
} from 'https://cdn.pika.dev/pdf-lib@^1.6.0';
import fontkit from 'https://cdn.pika.dev/@pdf-lib/fontkit@^1.0.0';

const url = 'https://pdf-lib.js.org/assets/ubuntu/Ubuntu-R.ttf';
const fontBytes = await fetch(url).then((res) => res.arrayBuffer());

const pdfDoc = await PDFDocument.create();

pdfDoc.registerFontkit(fontkit);
const customFont = await pdfDoc.embedFont(fontBytes);

const page = pdfDoc.addPage();

const text = 'This is text in an embedded font!';
const textSize = 35;
const textWidth = customFont.widthOfTextAtSize(text, textSize);
const textHeight = customFont.heightAtSize(textSize);

page.drawText(text, {
  x: 40,
  y: 450,
  size: textSize,
  font: customFont,
  color: rgb(0, 0.53, 0.71),
});
page.drawRectangle({
  x: 40,
  y: 450,
  width: textWidth,
  height: textHeight,
  borderColor: rgb(1, 0, 0),
  borderWidth: 1.5,
});

const pdfBytes = await pdfDoc.save();

await Deno.writeFile('out.pdf', pdfBytes);

If you save this script as custom-font.ts, you can execute it with the following command:

deno run --allow-write --allow-net custom-font.ts

The resulting out.pdf file will look like this PDF.

Complete Examples

The usage examples provide code that is brief and to the point, demonstrating the different features of pdf-lib. You can find complete working examples in the apps/ directory. These apps are used to do manual testing of pdf-lib before every release (in addition to the automated tests).

There are currently four apps:

  • node - contains tests for pdf-lib in Node environments. These tests are a handy reference when trying to save/load PDFs, fonts, or images with pdf-lib from the filesystem. They also allow you to quickly open your PDFs in different viewers (Acrobat, Preview, Foxit, Chrome, Firefox, etc...) to ensure compatibility.
  • web - contains tests for pdf-lib in browser environments. These tests are a handy reference when trying to save/load PDFs, fonts, or images with pdf-lib in a browser environment.
  • rn - contains tests for pdf-lib in React Native environments. These tests are a handy reference when trying to save/load PDFs, fonts, or images with pdf-lib in a React Native environment.
  • deno - contains tests for pdf-lib in Deno environments. These tests are a handy reference when trying to save/load PDFs, fonts, or images with pdf-lib from the filesystem.

Installation

NPM Module

To install the latest stable version:

# With npm
npm install --save pdf-lib

# With yarn
yarn add pdf-lib

This assumes you're using npm or yarn as your package manager.

UMD Module

You can also download pdf-lib as a UMD module from unpkg or jsDelivr. The UMD builds have been compiled to ES5, so they should work in any modern browser. UMD builds are useful if you aren't using a package manager or module bundler. For example, you can use them directly in the <script> tag of an HTML page.

The following builds are available:

NOTE: if you are using the CDN scripts in production, you should include a specific version number in the URL, for example:

When using a UMD build, you will have access to a global window.PDFLib variable. This variable contains all of the classes and functions exported by pdf-lib. For example:

// NPM module
import { PDFDocument, rgb } from 'pdf-lib';

// UMD module
var PDFDocument = PDFLib.PDFDocument;
var rgb = PDFLib.rgb;

Fontkit Installation

pdf-lib relies upon a sister module to support embedding custom fonts: @pdf-lib/fontkit. You must add the @pdf-lib/fontkit module to your project and register it using pdfDoc.registerFontkit(...) before embedding custom fonts (see the font embedding example). This module is not included by default because not all users need it, and it increases bundle size.

Installing this module is easy. Just like pdf-lib itself, @pdf-lib/fontkit can be installed with npm/yarn or as a UMD module.

Fontkit NPM Module

# With npm
npm install --save @pdf-lib/fontkit

# With yarn
yarn add @pdf-lib/fontkit

To register the fontkit instance:

import { PDFDocument } from 'pdf-lib'
import fontkit from '@pdf-lib/fontkit'

const pdfDoc = await PDFDocument.create()
pdfDoc.registerFontkit(fontkit)

Fontkit UMD Module

The following builds are available:

NOTE: if you are using the CDN scripts in production, you should include a specific version number in the URL, for example:

When using a UMD build, you will have access to a global window.fontkit variable. To register the fontkit instance:

var pdfDoc = await PDFLib.PDFDocument.create()
pdfDoc.registerFontkit(fontkit)

Documentation

API documentation is available on the project site at https://pdf-lib.js.org/docs/api/.

The repo for the project site (and generated documentation files) is located here: https://github.com/Hopding/pdf-lib-docs.

Encryption Handling

pdf-lib does not currently support modification of encrypted documents. In general, it is not advised to use pdf-lib with encrypted documents. However, this is a feature that could be added to pdf-lib. Please create an issue if you would find this feature helpful!

When an encrypted document is passed to PDFDocument.load(...), an error will be thrown:

import { PDFDocument, EncryptedPDFError } from 'pdf-lib'

const encryptedPdfBytes = ...

// Assignment fails. Throws an `EncryptedPDFError`.
const pdfDoc = PDFDocument.load(encryptedPdfBytes)

This default behavior is usually what you want. It allows you to easily detect if a given document is encrypted, and it prevents you from trying to modify it. However, if you really want to load the document, you can use the { ignoreEncryption: true } option:

import { PDFDocument } from 'pdf-lib'

const encryptedPdfBytes = ...

// Assignment succeeds. Does not throw an error.
const pdfDoc = PDFDocument.load(encryptedPdfBytes, { ignoreEncryption: true })

Note that using this option does not decrypt the document. This means that any modifications you attempt to make on the returned PDFDocument may fail, or have unexpected results.

The latest release of pdf-lib (v1.0.0) includes several breaking API changes. If you have code written for older versions of pdf-lib (v0.x.x), you can use the following instructions to help migrate your code to v1.0.0.

Note that many of the API methods are now asynchronous and return promises, so you'll need to await on them (or use promise chaining: .then(res => ...)).

  • Rename PDFDocumentFactory to PDFDocument. PDFDocument.create and PDFDocument.load are now async (they return promises), so you'll need to await on them.
  • To create a new PDF document:

    const pdfDoc = await PDFDocument.create();
  • To retrieve and load a PDF where pdfUrl points to the PDF to be loaded:

    const pdfBuffer = await fetch(pdfUrl).then((res) => res.arrayBuffer());
    const pdfDoc = await PDFDocument.load(pdfBuffer);
  • The purpose of making these methods asynchronous is to avoid blocking the event loop (especially for browser-based usage). If you aren't running this code client-side and are not concerned about blocking the event loop, you can speed up parsing times with:

    PDFDocument.load(..., { parseSpeed: ParseSpeeds.Fastest })

    You can do a similar thing for save:

    PDFDocument.save({ objectsPerTick: Infinity });
  • To draw content on a page in old versions of pdf-lib, you needed to create a content stream, invoke some operators, register the content stream, and add it to the document. Something like the following:

    const contentStream = pdfDoc.createContentStream(
      drawText(
        timesRomanFont.encodeText('Creating PDFs in JavaScript is awesome!'),
        {
          x: 50,
          y: 450,
          size: 15,
          font: 'TimesRoman',
          colorRgb: [0, 0.53, 0.71],
        },
      ),
    );
    page.addContentStreams(pdfDoc.register(contentStream));

    However, in new versions of pdf-lib, this is much simpler. You simply invoke drawing methods on the page, such as PDFPage.drawText, PDFPage.drawImage, PDFPage.drawRectangle, or PDFPage.drawSvgPath. So the above example becomes:

    page.drawText('Creating PDFs in JavaScript is awesome!', {
      x: 50,
      y: 450,
      size: 15,
      font: timesRomanFont,
      color: rgb(0, 0.53, 0.71),
    });

    Please see the Usage Examples for more in depth examples of drawing content on a page in the new versions of pdf-lib. You may also find the Complete Examples to be a useful reference.

  • Change getMaybe function calls to get calls. If a property doesn't exist, then undefined will be returned. Note, however, that PDF name strings with need to be wrapped in PDFName.of(...). For example, to look up the AcroForm object you'll need to change pdfDoc.catalog.getMaybe('AcroForm') to pdfDoc.catalog.get(PDFName.of('AcroForm')).

    const acroForm = await pdfDoc.context.lookup(
      pdfDoc.catalog.get(PDFName.of('AcroForm')),
    );

    v0.x.x converted the strings passed to get and getMaybe to PDFName objects, but v1.0.0 does not do this conversion for you. So you must always pass actual PDFName objects instead of strings.

  • To find the AcroForm field references now becomes:

    const acroFieldRefs = await pdfDoc.context.lookup(
      acroForm.get(PDFName.of('Fields')),
    );
  • To add a new page replace pdfDoc.createPage([width, height]) with pdfDoc.addPage([width, height])
    const page = pdfDoc.addPage([500, 750]);
    or simply:
    const page = pdfDoc.addPage();
  • To get the size of the page:

    const { width, height } = page.getSize();
    page.getWidth();
    page.getHeight();
  • To add images replace pdfDoc.embedPNG with pdfDoc.embedPng and pdfDoc.embedJPG with pdfDoc.embedJpg

  • The pdfDoc.embedPng and pdfDoc.embedJpg methods now return PDFImage objects which have the width and height of the image as properties. You can also scale down the width and height by a constant factor using the PDFImage.scale method:

    const aBigImage = await pdfDoc.embedPng(aBigImageBytes);
    const { width, height } = aBigImage.scale(0.25);

    So, const [image, dims] = pdfDoc.embedJPG(mediaBuffer) becomes:

    const image = await pdfDoc.embedJpg(mediaBuffer);
    // image.width, image.height can be used instead of the dims object.
  • To save the PDF replace PDFDocumentWriter.saveToBytes(pdfDoc) with pdfDoc.save()

    const pdfDocBytes = await pdfDoc.save();
  • To display the saved PDF now becomes:

    const pdfUrl = URL.createObjectURL(
      new Blob([await pdfDoc.save()], { type: 'application/pdf' }),
    );
    window.open(pdfUrl, '_blank');

    (note: URL.revokeObjectURL should be called later to free up memory)

  • To get the PDF page count:

    pdfDoc.getPages().length;
  • To copy pages from one document to another you must now call destPdf.copyPages(srcPdf, srcPageIndexesArray) to copy pages. You can see an example of this in the Copy Pages usage example. Admittedly, this API is slightly less ergonomic than what exists in v0.x.x, but it has two key benefits:

    1. It avoids making PDFDocument.addPage and PDFDocument.insertPage async. When copying multiple pages from the source document, the resulting merged document should have a smaller file size. This is because the page copying API that exists in v0.x.x was intended for copying just one or two pages.

    2. When copying large numbers of pages, it could result in redundant objects being created. This new page copying API should eliminate that.

    async function mergePdfs(pdfsToMerge: string[]) {
      const mergedPdf = await PDFDocument.create();
      for (const pdfCopyDoc of pdfsToMerge) {
        const pdfBytes = fs.readFileSync(pdfCopyDoc);
        const pdf = await PDFDocument.load(pdfBytes);
        const copiedPages = await mergedPdf.copyPages(pdf, pdf.getPageIndices());
        copiedPages.forEach((page) => {
          mergedPdf.addPage(page);
        });
      }
      const mergedPdfFile = await mergedPdf.save();
      return mergedPdfFile;
    }
  • If required, you can retrieve the CropBox or MediaBox of a page like so:

    const cropBox = page.node.CropBox() || page.node.MediaBox();

Contributing

We welcome contributions from the open source community! If you are interested in contributing to pdf-lib, please take a look at the CONTRIBUTING.md file. It contains information to help you get pdf-lib setup and running on your machine. (We try to make this as simple and fast as possible! :rocket:)

Tutorials and Cool Stuff

Prior Art

  • pdfkit is a PDF generation library for Node and the Browser. This library was immensely helpful as a reference and existence proof when creating pdf-lib. pdfkit's code for font embedding, PNG embedding, and JPG embedding was especially useful.
  • pdf.js is a PDF rendering library for the Browser. This library was helpful as a reference when writing pdf-lib's parser. Some of the code for stream decoding was ported directly to TypeScript for use in pdf-lib.
  • jspdf is a PDF generation library for the browser.
  • pdfmake is a PDF generation library for the browser.
  • hummus is a PDF generation and modification library for Node environments. hummus is a Node wrapper around a C++ library, so it doesn't work in many JavaScript environments - like the Browser or React Native.
  • react-native-pdf-lib is a PDF generation and modification library for React Native environments. react-native-pdf-lib is a wrapper around C++ and Java libraries.
  • pdfassembler is a PDF generation and modification library for Node and the browser. It requires some knowledge about the logical structure of PDF documents to use.

License

MIT
