@worker-manager/nestjs

@worker-manager/nestjs

NestJS module for Worker Manager.

Installation

Install both @worker-manager/api and this module.

$ npm install --save @worker-manager/nestjs @worker-manager/api

Install the Express or Fastify adapter depending on what you use in NestJS (default is Express)

$ npm install --save @worker-manager/express
//or
$ npm install --save @worker-manager/fastify

Register the root module

Once the installation is completed, we can import the WorkerManagerModule into your rootmodule e.g. AppModule.

import { Module } from '@nestjs/common';
import { WorkerManagerModule } from "@worker-manager/nestjs";

@Module({
  imports: [
    BullModule.forRoot({
      // your bull module config here.
    }),

    // Served at /queues, with the adapter matching your Nest platform (Express or Fastify).
    WorkerManagerModule.forRoot(),
  ],
})
export class AppModule {
}

The forRoot() method registers the Worker Manager instance and allows you to pass several options to both the instance and module. The following options are available, all optional.

Option	Default
route	'/queues'	Base route of the board, relative to the Nest global prefix.
adapter	auto-detected	ExpressAdapter (@worker-manager/express) or FastifyAdapter (@worker-manager/fastify). When omitted, the module reads the platform from HttpAdapterHost and loads the matching package.
auth	none	Built-in authentication, see Authentication.
enabled	true	false registers nothing: no routes, no middleware, forFeature becomes a no-op and the injected instance is null.
readOnly	false	Read-only mode for every queue registered through queues or forFeature, unless the queue sets options.readOnlyMode itself.
queues	[]	Queues to register at the root, same shape as forFeature entries.
uiConfig		Merged into boardOptions.uiConfig.
title / logo / theme		Shortcuts for uiConfig.boardTitle, uiConfig.boardLogo, uiConfig.theme.
boardOptions		Options as provided by the Worker Manager package, such as uiBasePath and uiConfig.
middleware		Nest middleware applied to the board route, after auth on Express.

WorkerManagerModule.forRoot({
  route: '/ops/queues',
  title: 'Ops queues',
  readOnly: process.env.NODE_ENV === 'production',
  enabled: process.env.QUEUE_BOARD !== 'off',
  queues: [{ name: 'emails', adapter: BullMQAdapter }],
}),

Async configuration

forRootAsync() accepts useFactory + inject, useClass or useExisting, with imports:

WorkerManagerModule.forRootAsync({
  imports: [ConfigModule],
  inject: [ConfigService],
  useFactory: (config: ConfigService) => ({
    route: '/queues',
    enabled: config.get('QUEUE_BOARD_ENABLED') !== 'false',
    auth: {
      strategy: 'keycloak',
      url: config.getOrThrow('KEYCLOAK_URL'),
      realm: config.getOrThrow('KEYCLOAK_REALM'),
      clientId: config.getOrThrow('KEYCLOAK_CLIENT_ID'),
      clientSecret: config.get('KEYCLOAK_CLIENT_SECRET'),
      requiredRoles: ['wm-admin'],
      cookie: { secret: config.getOrThrow('SESSION_SECRET') },
    },
  }),
}),

@Injectable()
class BoardConfig implements WorkerManagerOptionsFactory {
  constructor(private readonly config: ConfigService) {}

  createWorkerManagerOptions(): WorkerManagerModuleOptions {
    return { auth: { strategy: 'basic', users: [{ username: 'admin', password: this.config.getOrThrow('BOARD_PASSWORD') }] } };
  }
}

WorkerManagerModule.forRootAsync({ imports: [ConfigModule], useClass: BoardConfig }),

Authentication

The auth option protects every board route (page, API, assets) with @worker-manager/auth, on Express and Fastify alike, and honours the Nest global prefix.

Basic

WorkerManagerModule.forRoot({
  auth: {
    strategy: 'basic',
    users: [{ username: 'admin', password: process.env.BOARD_PASSWORD, roles: ['admin'] }],
  },
}),

Keycloak

WorkerManagerModule.forRoot({
  auth: {
    strategy: 'keycloak',
    url: 'https://sso.example.com',
    realm: 'ops',
    clientId: 'worker-manager',
    clientSecret: process.env.KEYCLOAK_CLIENT_SECRET,
    publicUrl: 'https://api.example.com/queues', // the board's external URL, base path included
    requiredRoles: ['wm-admin'],
    cookie: { secret: process.env.SESSION_SECRET },
  },
}),

Browsers are sent through the OIDC authorization code flow (PKCE), API clients may send an Authorization: Bearer access token. Register https://api.example.com/queues/auth/callback as a redirect URI on the Keycloak client. The board serves GET /queues/auth/me (the signed-in user) and GET /queues/auth/logout.

Custom middleware

middleware still takes any Nest middleware, e.g. express-basic-auth. On Express it runs after auth. On Fastify it is applied as Nest middleware to the exact route, before the board's own hooks.

import basicAuth from "express-basic-auth";

WorkerManagerModule.forRoot({
  route: "/queues",
  middleware: basicAuth({
    challenge: true,
    users: { admin: "passwordhere" },
  }),
}),

Register your queues

To register a new queue, you need to register WorkerManagerModule.forFeature in the same module as where your queues are registered.

import { Module } from '@nestjs/common';
import { WorkerManagerModule } from "@worker-manager/nestjs";
import { BullMQAdapter } from "@worker-manager/api/bullMQAdapter";
import { BullModule } from "@nestjs/bullmq";

@Module({
  imports: [
    BullModule.registerQueue(
      {
        name: 'my_awesome_queue'
      }
    ),

    WorkerManagerModule.forFeature({
      name: 'my_awesome_queue',
      adapter: BullMQAdapter, //or use BullAdapter if you're using bull instead of bullMQ
    }),
  ],
})
export class FeatureModule {}

The forFeature method registers the given queues to the Worker Manager instance. The following options are available.

• name the queue name to resolve from the Nest DI container.
• queue a queue instance to register directly, instead of resolving it by name.
• adapter either BullAdapter or BullMQAdapter depending on which package you use.
• options queue adapter options as found in the Worker Manager package, such as readOnlyMode, description etc.

Provide either name or queue.

PostgreSQL-backed queues (BullMQ v6)

A BullMQ v6 queue stored in PostgreSQL has no Redis connection and is usually not in the Nest container, so hand the instance over directly:

import { Queue, createPostgresBackend } from 'bullmq'; // bullmq@6, plus `pg`

const invoices = new Queue('invoices', { connection: process.env.POSTGRES_URL }, createPostgresBackend);

WorkerManagerModule.forRoot({
  queues: [{ queue: invoices, adapter: BullMQAdapter }],
}),

Redis and PostgreSQL queues can share one board.

Registering queue instances directly

@nestjs/bullmq generates the DI token for a queue from its name only, ignoring the prefix. Two queues that share a name but use different prefixes therefore collapse onto a single DI token, and a name-based lookup cannot tell them apart. Pass the queue instances directly via queue to register them as distinct board entries:

@Module({
  imports: [
    WorkerManagerModule.forFeature(
      { queue: emailsTenantA, adapter: BullMQAdapter, options: { prefix: 'tenant-a:' } },
      { queue: emailsTenantB, adapter: BullMQAdapter, options: { prefix: 'tenant-b:' } },
    ),
  ],
})
export class FeatureModule {}

Using the Worker Manager instance in your controllers and/or services.

The created Worker Manager instance is available via the @InjectWorkerManager() decorator. For example in a controller:

import { Controller, Get } from "@nestjs/common";
import { WorkerManagerBoard, InjectWorkerManager } from "@worker-manager/nestjs";

@Controller('my-feature')
export class FeatureController {

  constructor(
    @InjectWorkerManager() private readonly boardInstance: WorkerManagerBoard
  ) {
  }

  //controller methods
}

Usage examples

1. Simple NestJS setup

For more info visit the main README
