bresenham-zingl

Bresenham rasterisation functions by Alois Zingl

Port of C code by Alois Zingl from this paper

ALOIS ZINGL: "A Rasterizing Algorithm for Drawing Curves", 8 November 2012 (2012-11-08), pages 1 - 81

Install

npm i -S bresenham-zingl

import { line, circle, quadBezier } from "bresenham-zingl";

quadBezier(0, 0, 10, 10, 0, 10, (x, y) => console.log(x, y)); // 0,0, ...

Demo

API

All coordinates are integers. All functions are pure — they only call the supplied callback(s) and have no side effects.

Callback types

Type	Signature	Description
SetPixelFn	(x: number, y: number) => void	Plot a single pixel at (x, y).
SetPixelAlphaFn	(x: number, y: number, alpha: number) => void	Plot a pixel with coverage. alpha is 0 = fully opaque, 255 = fully transparent (Zingl convention).
SetHLineFn	(x0: number, x1: number, y: number) => void	Fill a horizontal span from x0 to x1 (inclusive) on row y. Used by filled shapes.

---

Lines

line(x0, y0, x1, y1, setPixel)

Rasterise a line segment using Bresenham's algorithm.

Parameter	Type	Description
x0, y0	number	Start point.
x1, y1	number	End point.
setPixel	SetPixelFn	Called for every pixel on the line.

lineAA(x0, y0, x1, y1, setPixelAA)

Anti-aliased line using Wu's algorithm.

Parameter	Type	Description
x0, y0	number	Start point.
x1, y1	number	End point.
setPixelAA	SetPixelAlphaFn	Called with coverage for each pixel.

lineWidth(x0, y0, x1, y1, wd, setPixelAA)

Anti-aliased line with a given stroke width.

Parameter	Type	Description
x0, y0	number	Start point.
x1, y1	number	End point.
wd	number	Stroke width in pixels.
setPixelAA	SetPixelAlphaFn	Called with coverage for each pixel.

---

Circles

circle(xm, ym, r, setPixel)

Rasterise a circle outline (Bresenham midpoint algorithm).

Parameter	Type	Description
xm, ym	number	Centre.
r	number	Radius.
setPixel	SetPixelFn	Called for each pixel on the outline.

disc(xm, ym, r, setHLine)

Rasterise a filled circle (disc) using horizontal spans.

Parameter	Type	Description
xm, ym	number	Centre.
r	number	Radius.
setHLine	SetHLineFn	Called once per row to fill a horizontal span.

circleAA(xm, ym, r, setPixelAA)

Anti-aliased circle outline.

Parameter	Type	Description
xm, ym	number	Centre.
r	number	Radius.
setPixelAA	SetPixelAlphaFn	Called with coverage for each pixel.

---

Ellipses

ellipse(xm, ym, a, b, setPixel)

Rasterise an axis-aligned ellipse outline.

Parameter	Type	Description
xm, ym	number	Centre.
a	number	Semi-axis along x.
b	number	Semi-axis along y.
setPixel	SetPixelFn	Called for each pixel on the outline.

ellipseRect(x0, y0, x1, y1, setPixel)

Rasterise an ellipse inscribed in an axis-aligned bounding rectangle (the ellipse touches all four sides). Equivalent to ellipse but specified by corner coordinates instead of centre + radii.

Parameter	Type	Description
x0, y0	number	Top-left corner of the bounding rectangle.
x1, y1	number	Bottom-right corner of the bounding rectangle.
setPixel	SetPixelFn	Called for each pixel on the outline.

rotatedEllipse(x, y, a, b, angle, setPixel)

Rasterise a rotated ellipse given centre, semi-axes, and rotation angle. Internally delegates to rotatedEllipseRect.

Note: Due to floating-point intermediate coordinates, a small line artefact can appear for certain input combinations. Prefer rotatedEllipseRect with hand-crafted integer coordinates when pixel-perfect output is required.

Parameter	Type	Description
x, y	number	Centre.
a	number	Semi-major axis (before rotation).
b	number	Semi-minor axis (before rotation).
angle	number	Rotation angle in radians.
setPixel	SetPixelFn	Called for each pixel on the outline.

rotatedEllipseRect(x0, y0, x1, y1, zd, setPixel)

Rasterise a rotated ellipse specified by its bounding rectangle and a shear parameter. All inputs must be integers for artefact-free output.

zd encodes the rotation: w = (W·H − zd) / (2·W·H) where W = x1−x0, H = y1−y0. Valid range: |zd| ≤ W·H (i.e. w ∈ [0, 1]). zd = 0 produces an ordinary axis-aligned ellipse.

Parameter	Type	Description
x0, y0	number	Top-left corner of the bounding rectangle (integer).
x1, y1	number	Bottom-right corner of the bounding rectangle (integer).
zd	number	Rotation/shear parameter. Must satisfy `
setPixel	SetPixelFn	Called for each pixel on the outline.

---

Quadratic Bézier curves

quadBezier(x0, y0, x1, y1, x2, y2, setPixel)

Rasterise any quadratic Bézier curve. Subdivides at gradient-sign changes and delegates to quadBezierSegment.

Parameter	Type	Description
x0, y0	number	Start point P0.
x1, y1	number	Control point P1.
x2, y2	number	End point P2.
setPixel	SetPixelFn	Called for each pixel on the curve.

quadBezierAA(x0, y0, x1, y1, x2, y2, setPixelAA)

Anti-aliased version of quadBezier.

Parameter	Type	Description
x0, y0	number	Start point P0.
x1, y1	number	Control point P1.
x2, y2	number	End point P2.
setPixelAA	SetPixelAlphaFn	Called with coverage for each pixel.

quadBezierSegment(x0, y0, x1, y1, x2, y2, setPixel) (low-level)

Rasterise a limited quadratic Bézier segment. The segment must satisfy the Zingl slope constraint: the gradient must not change sign between P0→P1 and P1→P2 in either axis. Use quadBezier for arbitrary curves.

Parameter	Type	Description
x0, y0	number	Start point.
x1, y1	number	Control point.
x2, y2	number	End point.
setPixel	SetPixelFn	Called for each pixel on the curve.

quadBezierSegmentAA(x0, y0, x1, y1, x2, y2, setPixelAA) (low-level)

Anti-aliased version of quadBezierSegment.

Parameter	Type	Description
x0, y0	number	Start point.
x1, y1	number	Control point.
x2, y2	number	End point.
setPixelAA	SetPixelAlphaFn	Called with coverage for each pixel.

---

Rational quadratic Bézier curves

quadRationalBezier(x0, y0, x1, y1, x2, y2, w, setPixel)

Rasterise any rational quadratic Bézier curve (conic section). w < 1 gives an elliptic arc, w = 1 a parabola, w > 1 a hyperbolic arc. Subdivides at gradient-sign changes and delegates to quadRationalBezierSegment.

Parameter	Type	Description
x0, y0	number	Start point P0.
x1, y1	number	Control point P1.
x2, y2	number	End point P2.
w	number	Weight (≥ 0). Controls curve type: 0 < w < 1 → elliptic arc, w = 1 → parabola, w > 1 → hyperbolic arc.
setPixel	SetPixelFn	Called for each pixel on the curve.

quadRationalBezierSegment(x0, y0, x1, y1, x2, y2, w, setPixel) (low-level)

Rasterise a limited rational quadratic Bézier segment (squared weight). Inputs must be integer coordinates satisfying the Zingl slope constraint.

Parameter	Type	Description
x0, y0	number	Start point.
x1, y1	number	Control point.
x2, y2	number	End point.
w	number	Squared weight.
setPixel	SetPixelFn	Called for each pixel on the curve.

quadRationalBezierSegmentAA(x0, y0, x1, y1, x2, y2, w, setPixelAA) (low-level)

Anti-aliased version of quadRationalBezierSegment.

Parameter	Type	Description
x0, y0	number	Start point.
x1, y1	number	Control point.
x2, y2	number	End point.
w	number	Squared weight.
setPixelAA	SetPixelAlphaFn	Called with coverage for each pixel.

---

Cubic Bézier curves

cubicBezier(x0, y0, x1, y1, x2, y2, x3, y3, setPixel)

Rasterise any cubic Bézier curve. Subdivides at gradient-sign changes and delegates to cubicBezierSegment.

Parameter	Type	Description
x0, y0	number	Start point P0.
x1, y1	number	Control point P1.
x2, y2	number	Control point P2.
x3, y3	number	End point P3.
setPixel	SetPixelFn	Called for each pixel on the curve.

cubicBezierAA(x0, y0, x1, y1, x2, y2, x3, y3, setPixelAA)

Anti-aliased version of cubicBezier.

Parameter	Type	Description
x0, y0	number	Start point P0.
x1, y1	number	Control point P1.
x2, y2	number	Control point P2.
x3, y3	number	End point P3.
setPixelAA	SetPixelAlphaFn	Called with coverage for each pixel.

cubicBezierSegment(x0, y0, x1, y1, x2, y2, x3, y3, setPixel) (low-level)

Rasterise a limited cubic Bézier segment. The segment must satisfy both Zingl slope constraints:

• (x1−x0)·(x2−x3) ≤ 0 — x-slopes at P0 and P3 point in opposite directions
• (y1−y0)·(y2−y3) ≤ 0 — same for y

Use cubicBezier for arbitrary curves; the higher-level function handles subdivision automatically. Throws if constraints are violated.

Parameter	Type	Description
x0, y0	number	Start point.
x1, y1	number	Control point P1.
x2, y2	number	Control point P2.
x3, y3	number	End point.
setPixel	SetPixelFn	Called for each pixel on the curve.

cubicBezierSegmentAA(x0, y0, x1, y1, x2, y2, x3, y3, setPixelAA) (low-level)

Anti-aliased version of cubicBezierSegment. Same slope constraints apply.

Parameter	Type	Description
x0, y0	number	Start point.
x1, y1	number	Control point P1.
x2, y2	number	Control point P2.
x3, y3	number	End point.
setPixelAA	SetPixelAlphaFn	Called with coverage for each pixel.
