ForgeFrame

A TypeScript-first framework for embedding cross-domain iframes and popups with seamless communication. Pass data and callbacks across domains for payment forms, auth widgets, third-party integrations, and micro-frontends. Zero runtime dependencies with an ESM build.

Used By

Terminology

ForgeFrame involves two sides:

Consumer — The outer app that renders the iframe and passes props into it

Host — The inner app running inside the iframe that receives props via window.hostProps

Real-world example

Imagine a payment company (like Stripe) wants to let merchants embed a checkout form:

	Consumer	Host
Who builds it	Merchant (e.g., shop.com)	Payment company (e.g., stripe.com)
What they do	Embeds the checkout, receives onSuccess	Provides the checkout UI, calls onSuccess when paid
Their domain	shop.com	stripe.com

┌─────────────────────────────────────────────────────────────────┐
│  Consumer (merchant's site - shop.com)                          │
│                                                                 │
│  Checkout({ amount: 99, onSuccess: (payment) => {               │
│    // Payment complete! Fulfill the order                       │
│  }}).render('#checkout-container');                             │
│                         │                                       │
│                         ▼                                       │
│      ┌──────────────────────────────────────────────┐           │
│      │  Host (payment form - stripe.com)            │           │
│      │                                              │           │
│      │  const { amount, onSuccess, close }          │           │
│      │    = window.hostProps;                       │           │
│      │                                              │           │
│      │  // User enters card, pays...                │           │
│      │  onSuccess({ paymentId: 'xyz', amount });    │           │
│      │  close();                                    │           │
│      └──────────────────────────────────────────────┘           │
└─────────────────────────────────────────────────────────────────┘

Which side are you building?

If you want to...	You're building the...
Embed someone else's component into your app	Consumer
Build a component/widget for others to embed	Host
Build both sides (e.g., your own micro-frontends)	Both

---

Table of Contents

• Installation
• Start Here (Most Users)
• Quick Start
• Step-by-Step Guide
  • 1. Define a Component
  • 2. Create the Host Page
  • 3. Render the Component
  • 4. Handle Events
• Props System
• Host Window API (hostProps)
• Templates (Advanced)
• React Integration (Optional)
• Advanced Features
• Migrating from 0.0.15 to 0.1.0
• API Reference
• TypeScript
• Browser Support

---

Installation

npm install forgeframe

---

Start Here (Most Users)

Use this path for typical integrations:

1. Follow Quick Start to get a working component.
2. Use Step-by-Step Guide to add typed props and callbacks.
3. Use Props System and Host Window API (hostProps) as your primary references.
4. Treat sections marked Advanced as optional unless you specifically need them.

---

Quick Start

Consumer

import ForgeFrame, { prop } from 'forgeframe';

const PaymentForm = ForgeFrame.create({
  tag: 'payment-form',
  url: 'https://checkout.stripe.com/payment',
  dimensions: { width: 400, height: 300 },
  props: {
    amount: prop.number(),
    onSuccess: prop.function<(txn: { transactionId: string }) => void>(),
  },
});

const payment = PaymentForm({
  amount: 99.99,
  onSuccess: (txn) => console.log('Payment complete:', txn),
});

await payment.render('#payment-container');

Host

import { initHost, prop, type HostProps } from 'forgeframe';

interface PaymentProps {
  amount: number;
  onSuccess: (txn: { transactionId: string }) => void;
}

const paymentProps = {
  amount: prop.number(),
  onSuccess: prop.function<(txn: { transactionId: string }) => void>(),
};

const allowedConsumerDomains = ['https://shop.example.com'];

declare global {
  interface Window {
    hostProps: HostProps<PaymentProps>;
  }
}

initHost(paymentProps, allowedConsumerDomains);
const { amount, onSuccess, close } = window.hostProps;

document.getElementById('total')!.textContent = `$${amount}`;
document.getElementById('pay-btn')!.onclick = async () => {
  await onSuccess({ transactionId: 'TXN_123' });
  await close();
};

That's it! ForgeFrame handles all the cross-domain communication automatically. Before reading window.hostProps directly, call initHost(propDefinitions, allowedConsumerDomains) as shown in Host Init with initHost. For intentionally open widgets, omit allowedConsumerDomains; for payment, auth, or account flows, use an allowlist.

---

Step-by-Step Guide

1. Define a Component

Consumer

Components are defined using ForgeFrame.create(). This creates a reusable component factory.

import ForgeFrame, { prop } from 'forgeframe';

interface LoginProps {
  email?: string;
  onLogin: (user: { id: number; name: string }) => void;
  onCancel?: () => void;
}

const LoginForm = ForgeFrame.create<LoginProps>({
  tag: 'login-form',
  url: 'https://auth.stripe.com/login',
  dimensions: { width: 400, height: 350 },
  props: {
    email: prop.string().optional(),
    onLogin: prop.function<(user: { id: number; name: string }) => void>(),
    onCancel: prop.function().optional(),
  },
});

Explanation

• tag (required): Unique identifier for the component
• url (required): URL of the host page to embed
• dimensions: Width and height of the iframe
• props: Schema definitions for props passed to the host

2. Create the Host Page

Host

The host page runs inside the iframe at the URL you specified. It receives props via window.hostProps.

import { initHost, prop, type HostProps } from 'forgeframe';

interface LoginProps {
  email?: string;
  onLogin: (user: { id: number; name: string }) => void;
  onCancel?: () => void;
}

const loginProps = {
  email: prop.string().optional(),
  onLogin: prop.function<(user: { id: number; name: string }) => void>(),
  onCancel: prop.function().optional(),
};

const allowedConsumerDomains = ['https://app.example.com'];

declare global {
  interface Window {
    hostProps: HostProps<LoginProps>;
  }
}

initHost(loginProps, allowedConsumerDomains);
const { email, onLogin, onCancel, close } = window.hostProps;

if (email) document.getElementById('email')!.value = email;

document.getElementById('login-form')!.onsubmit = async (e) => {
  e.preventDefault();
  await onLogin({
    id: 1,
    name: 'John Doe',
  });
  await close();
};

document.getElementById('cancel')!.onclick = async () => {
  await onCancel?.();
  await close();
};

Explanation

• HostProps<LoginProps>: Combines your props with built-in methods (close, resize, etc.)
• Host init: Call initHost(propDefinitions, allowedConsumerDomains) before the first direct window.hostProps read. Use allowedConsumerDomains for security-sensitive embeds; omit it only for intentionally open widgets. If your host defines a component with ForgeFrame.create(...), that component path still initializes the host runtime automatically.
• window.hostProps: Contains all props passed from the consumer plus built-in methods
• close(): Built-in method to close the iframe/popup

3. Render the Component

Consumer

Back in your consumer app, create an instance with props and render it.

const login = LoginForm({
  email: 'user@example.com',
  onLogin: (user) => console.log('User logged in:', user),
  onCancel: () => console.log('Login cancelled'),
});

await login.render('#login-container');

4. Handle Events

Consumer

Subscribe to lifecycle events for better control.

const instance = LoginForm({ /* props */ });

instance.event.on('rendered', () => console.log('Login form is ready'));
instance.event.on('close', () => console.log('Login form closed'));
instance.event.on('error', (err) => console.error('Error:', err));
instance.event.on('resize', (dimensions) => console.log('New size:', dimensions));

await instance.render('#container');

Available Events:

Event	Description
render	Rendering started
rendered	Fully rendered and initialized
prerender	Prerender (loading) started
prerendered	Prerender complete
display	Component became visible
close	Component is closing
destroy	Component destroyed
error	An error occurred
props	Props were updated
resize	Component was resized
focus	Component received focus

If all you need is embed + typed props + callbacks, you can stop here and use the API reference as needed.

---

Props System

ForgeFrame uses a fluent, Zod-like schema API for defining props. All schemas implement Standard Schema, enabling seamless integration with external validation libraries.

Defining Props

Props define what data can be passed to your component.

import ForgeFrame, { prop } from 'forgeframe';

const MyComponent = ForgeFrame.create({
  tag: 'my-component',
  url: 'https://widgets.stripe.com/component',
  props: {
    name: prop.string(),
    count: prop.number(),
    createdAt: prop.date(),
    enabled: prop.boolean(),
    config: prop.object(),
    items: prop.array(),
    position: prop.tuple(prop.number(), prop.number()),
    onSubmit: prop.function<(data: FormData) => void>(),
    nickname: prop.string().optional(),
    theme: prop.string().default('light'),
    email: prop.string().email(),
    age: prop.number().min(0).max(120),
    username: prop.string().min(3).max(20),
    slug: prop.string().pattern(/^[a-z0-9-]+$/),
    status: prop.enum(['pending', 'active', 'completed']),
    tags: prop.array().of(prop.string()),
    scores: prop.array().of(prop.number().min(0).max(100)),
    metadata: prop.record(prop.string()),
    themeId: prop.union(prop.string(), prop.number()),
    user: prop.object().shape({
      name: prop.string(),
      email: prop.string().email(),
      age: prop.number().optional(),
    }),
  },
});

Explanation

Prop	Description
name, count, enabled, config, items	Basic types: string, number, boolean, object, array
createdAt	prop.date() validates real Date instances
position	prop.tuple(...) validates fixed positional arrays
onSubmit	Functions are automatically serialized for cross-domain calls
nickname	.optional() makes the prop accept undefined
theme	.default('light') provides a fallback value
email	.email() validates email format
age	.min(0).max(120) constrains the range
username	.min(3).max(20) constrains string length
slug	.pattern(/.../) validates against a regex
status	prop.enum([...]) restricts to specific values
tags	.of(prop.string()) validates each array item
scores	Array items can have their own validation chain
metadata	prop.record(...) validates dictionary values by key
themeId	prop.union(...) preserves type-safe multi-type props
user	.shape({...}) defines nested object structure

Prop Schema Methods

All schemas support these base methods:

Method	Description
.optional()	Makes the prop optional (accepts undefined)
.nullable()	Accepts null values
.default(value)	Sets a default value (or factory function)

Schema Types

Type	Factory	Methods
String	prop.string()	.min(), .max(), .length(), .email(), .url(), .uuid(), .pattern(), .trim(), .nonempty()
Number	prop.number()	.min(), .max(), .int(), .positive(), .negative(), .nonnegative()
Date	prop.date()	.min(), .max()
Boolean	prop.boolean()	-
Function	prop.function<T>()	-
Array	prop.array()	.of(schema), .min(), .max(), .nonempty()
Tuple	prop.tuple(...schemas)	-
Object	prop.object()	.shape({...}), .strict()
Record	prop.record(schema)	-
Enum	prop.enum([...])	-
Literal	prop.literal(value)	-
Union	prop.union(...schemas)	-
Any	prop.any()	-

Using Standard Schema Libraries

ForgeFrame accepts any Standard Schema compliant library (Zod, Valibot, ArkType, etc.):

import ForgeFrame from 'forgeframe';
import { z } from 'zod';
import * as v from 'valibot';

const MyComponent = ForgeFrame.create({
  tag: 'my-component',
  url: 'https://widgets.stripe.com/component',
  props: {
    email: z.string().email(),
    user: z.object({ name: z.string(), role: z.enum(['admin', 'user']) }),
    count: v.pipe(v.number(), v.minValue(0)),
  },
});

Note: ForgeFrame runs schema validation synchronously. Schemas with async ~standard.validate are not supported.

Advanced Prop Definitions

Use the object form when a prop needs transport rules in addition to validation.

import ForgeFrame, { prop, PROP_SERIALIZATION } from 'forgeframe';

const SecureWidget = ForgeFrame.create({
  tag: 'secure-widget',
  url: 'https://widgets.example.com/secure',
  props: {
    profile: {
      schema: prop.object(),
      serialization: PROP_SERIALIZATION.DOTIFY,
    },
    secret: {
      schema: prop.string(),
      sameDomain: true,
    },
    auditId: {
      schema: prop.string(),
      queryParam: true,
    },
    internalState: {
      schema: prop.any(),
      sendToHost: false,
    },
  },
});

Option	Description
sendToHost	Skip sending the prop to the host when set to false
sameDomain	Only deliver the prop after the loaded host is verified to be same-origin. It is not included in the initial bootstrap payload
trustedDomains	Only send the prop to matching host domains
serialization	Choose how object props are transferred: JSON (default), BASE64, or DOTIFY
queryParam / bodyParam	Include the prop in the host page's initial HTTP request

• Use sameDomain for values that should never be exposed during cross-origin bootstrap.
• DOTIFY safely preserves nested object keys that contain separators such as ., &, or =.

Passing Props via URL or POST Body (Advanced)

Use prop definition flags to include specific values in the host page's initial HTTP request:

const Checkout = ForgeFrame.create({
  tag: 'checkout',
  url: 'https://payments.example.com/checkout',
  props: {
    checkoutId: { schema: prop.string(), queryParam: true }, // ?checkoutId=...
    requestNonce: { schema: prop.string(), bodyParam: true }, // POST body field
    userId: { schema: prop.string(), bodyParam: 'user_id' }, // custom body field name
  },
});

• queryParam: appends to the URL query string for initial load.
• bodyParam: sends values in a hidden form POST for initial load (iframe and popup).
• bodyParam only affects the initial navigation; later updateProps() uses postMessage.
• Object values are JSON-stringified. Function and undefined values are skipped.
• Never put credentials, bearer tokens, session identifiers, or sensitive personal data in queryParam; URLs commonly leak through browser history, referrers, analytics, and server logs.
• sendToHost, sameDomain, and trustedDomains are enforced for query and body parameters as well as postMessage props. Because same-origin status is not verified until the host loads, sameDomain props are never included in the initial request.
• Most apps do not need this unless the host server requires initial URL/body parameters.

Updating Props

Props can be updated after rendering.

const instance = MyComponent({ name: 'Initial' });
await instance.render('#container');
await instance.updateProps({ name: 'Updated' });

The host receives updates via onProps:

window.hostProps.onProps((newProps) => {
  console.log('Props updated:', newProps);
});

Built-in window.hostProps names are reserved. Consumer props with names such as uid, tag, close, focus, resize, show, hide, onProps, onError, getConsumer, getConsumerDomain, export, consumer, getPeerInstances, and children are kept in hostProps.consumer.props, but they do not override the top-level ForgeFrame methods and metadata exposed on window.hostProps.

---

Host Window API (hostProps)

In host windows, window.hostProps provides access to props and control methods.

When rendering in iframe mode, ForgeFrame applies a default sandbox of allow-scripts allow-same-origin allow-forms allow-popups unless you explicitly set attributes.sandbox on the consumer component. An explicit sandbox value is used as-is.

TypeScript Setup

import { initHost, type HostProps } from 'forgeframe';

interface MyProps {
  email: string;
  onLogin: (user: { id: number }) => void;
}

declare global {
  interface Window {
    hostProps?: HostProps<MyProps>;
  }
}

initHost();
const { email, onLogin, close, resize } = window.hostProps!;

Host Init with initHost

initHost(propDefinitions?, allowedConsumerDomains?) is required when your host bundle reads window.hostProps directly. It consumes the initial ForgeFrame window.name payload, clears that payload after a successful parse, validates props when definitions are provided, and attaches window.hostProps.

Supported host boot patterns:

• Call initHost(propDefinitions, allowedConsumerDomains) during host startup, then read window.hostProps.
• Call initHost(propDefinitions) or initHost() only for hosts that are intentionally embeddable by any consumer origin.
• Define the host with ForgeFrame.create(...) and let component creation initialize the host runtime.

Use initHost() when:

• You read window.hostProps directly.
• Your host boot flow delays the first window.hostProps access (for example: lazy-loaded modules, async startup, or gated initialization).
• You want deterministic init timing in tests or instrumentation.
• You need the host side to enforce which consumer domains may embed or message it.

Available Methods

const props = window.hostProps;

props.email;
props.onLogin(user);
props.uid;
props.tag;

await props.close();
await props.focus();
await props.resize({ width: 500, height: 400 });
await props.show();
await props.hide();

const { cancel } = props.onProps((newProps) => { /* handle updates */ });
await props.onError(new Error('Something failed'));
await props.export({ validate: () => true });

props.getConsumer();
props.getConsumerDomain();
props.consumer.props;
await props.consumer.export(data);

const peers = await props.getPeerInstances();
cancel();

Method Reference

Method	Description
email, onLogin	Your custom props and callbacks
uid, tag	Built-in identifiers
close()	Close the component
focus()	Request focus for iframe/popup
resize()	Resize the component
show(), hide()	Toggle visibility
onProps()	Listen for prop updates (returns { cancel() })
onError()	Report errors to consumer
export()	Export methods/data to consumer
getConsumer()	Get consumer window reference
getConsumerDomain()	Get consumer origin
consumer.props	Access consumer's props
consumer.export()	Send data to consumer from host context
getPeerInstances()	Get peer component instances from the same consumer
children	Nested component factories provided by consumer (if configured)

Exporting Data to Consumer

Host components can export methods/data for the consumer to use.

Host

await window.hostProps.export({
  validate: () => document.getElementById('form').checkValidity(),
  getFormData: () => ({ email: document.getElementById('email').value }),
});

Consumer

const instance = MyComponent({ /* props */ });
await instance.render('#container');

const isValid = await instance.exports.validate();
const data = await instance.exports.getFormData();

---

Templates (Advanced)

Use this section only when you need custom containers/loading UI beyond the default behavior.

Container Template

Customize how the component container is rendered. Perfect for modals.

const ModalComponent = ForgeFrame.create({
  tag: 'modal',
  url: 'https://widgets.stripe.com/modal',
  dimensions: { width: 500, height: 400 },

  containerTemplate: ({ doc, frame, prerenderFrame, close }) => {
    const overlay = doc.createElement('div');
    Object.assign(overlay.style, {
      position: 'fixed',
      inset: '0',
      background: 'rgba(0,0,0,0.5)',
      display: 'flex',
      alignItems: 'center',
      justifyContent: 'center',
      zIndex: '1000',
    });
    overlay.onclick = (e) => { if (e.target === overlay) close(); };

    const modal = doc.createElement('div');
    Object.assign(modal.style, { background: 'white', borderRadius: '8px', overflow: 'hidden' });

    const closeBtn = doc.createElement('button');
    closeBtn.textContent = '×';
    closeBtn.onclick = () => close();
    modal.appendChild(closeBtn);

    const body = doc.createElement('div');
    if (prerenderFrame) body.appendChild(prerenderFrame);
    if (frame) body.appendChild(frame);
    modal.appendChild(body);

    overlay.appendChild(modal);
    return overlay;
  },
});

Prerender Template

Customize the loading state shown while the host loads.

const MyComponent = ForgeFrame.create({
  tag: 'my-component',
  url: 'https://widgets.stripe.com/component',

  prerenderTemplate: ({ doc, dimensions }) => {
    const loader = doc.createElement('div');
    loader.innerHTML = `
      <div style="
        display: flex;
        align-items: center;
        justify-content: center;
        width: ${dimensions.width}px;
        height: ${dimensions.height}px;
        background: #f5f5f5;
      ">
        <span>Loading...</span>
      </div>
    `;
    return loader.firstElementChild as HTMLElement;
  },
});

---

React Integration (Optional)

Basic Usage

import React, { useState } from 'react';
import ForgeFrame, { prop, createReactComponent } from 'forgeframe';

const LoginComponent = ForgeFrame.create({
  tag: 'login',
  url: 'https://auth.stripe.com/login',
  dimensions: { width: 400, height: 350 },
  props: {
    email: prop.string().optional(),
    onLogin: prop.function<(user: { id: number; name: string }) => void>(),
  },
});

const Login = createReactComponent(LoginComponent, { React });

function App() {
  const [user, setUser] = useState(null);

  return (
    <div>
      <h1>My App</h1>
      <Login
        email="user@example.com"
        onLogin={(loggedInUser) => setUser(loggedInUser)}
        onRendered={() => console.log('Ready')}
        onError={(err) => console.error(err)}
        onClose={() => console.log('Closed')}
        className="login-frame"
        style={{ border: '1px solid #ccc' }}
      />
    </div>
  );
}

React Props

The React component accepts all your component props plus:

Prop	Type	Description
onRendered	() => void	Called when component is ready
onError	(err: Error) => void	Called on error
onClose	() => void	Called when closed
context	'iframe' | 'popup'	Render mode
className	string	Container CSS class
style	CSSProperties	Container inline styles

Factory Pattern

For multiple components, use withReactComponent:

import { withReactComponent } from 'forgeframe';

const createComponent = withReactComponent(React);

const LoginReact = createComponent(LoginComponent);
const PaymentReact = createComponent(PaymentComponent);
const ProfileReact = createComponent(ProfileComponent);

---

Advanced Features

Most integrations can skip this section initially and return only when a specific requirement appears.

Popup Windows

Render as a popup instead of iframe.

await instance.render('#container', 'popup');

const PopupComponent = ForgeFrame.create({
  tag: 'popup-component',
  url: 'https://widgets.stripe.com/popup',
  defaultContext: 'popup',
});

Domain Security

Restrict which domains can embed or communicate. String domain patterns support * wildcards (for example, 'https://*.myapp.com'), and arrays can mix strings and RegExp.

• domain is consumer-side trust: it restricts which host origins the consumer will message.
• allowedConsumerDomains is host-side trust: it restricts which consumer origins may embed and initialize the host.
• Use both for payment, auth, account, or other sensitive workflows.

const secureProps = {
  accountId: prop.string(),
  onComplete: prop.function<(result: { ok: true }) => void>(),
};

const SecureComponent = ForgeFrame.create({
  tag: 'secure',
  url: 'https://secure.stripe.com/widget',
  props: secureProps,
  domain: 'https://secure.stripe.com',
  allowedConsumerDomains: [
    'https://myapp.com',
    'https://*.myapp.com',
    /^https:\/\/.*\.trusted\.com$/,
  ],
});

On the host page, pass the same host prop definitions and the consumer allowlist into initHost:

initHost(secureProps, [
  'https://myapp.com',
  'https://*.myapp.com',
  /^https:\/\/.*\.trusted\.com$/,
]);

When allowedConsumerDomains is configured, the host fails closed if the browser does not provide a usable consumer origin. A no-referrer navigation can therefore prevent initialization; do not weaken the allowlist to work around that browser privacy setting.

Public API removals or behavioral changes are documented in GitHub release notes. Pre-1.0 releases may include breaking changes, so pin an exact version for production integrations and review release notes before upgrading.

Eligibility Checks

Conditionally allow rendering.

const FeatureComponent = ForgeFrame.create({
  tag: 'feature',
  url: 'https://widgets.stripe.com/feature',
  eligible: ({ props }) => {
    if (!props.userId) return { eligible: false, reason: 'User must be logged in' };
    return { eligible: true };
  },
});

if (instance.isEligible()) {
  await instance.render('#container');
}

Nested Components

Define nested components that can be rendered from within the host.

Consumer

const ContainerComponent = ForgeFrame.create({
  tag: 'container',
  url: 'https://widgets.stripe.com/container',
  children: () => ({
    CardField: CardFieldComponent,
    CVVField: CVVFieldComponent,
  }),
});

Host

// Import or define the same child factories before initializing hostProps.
// Their schemas remain executable code and are never JSON-serialized.
import { CardFieldComponent, CVVFieldComponent } from './child-components';

initHost(containerPropDefinitions, allowedConsumerDomains);
const { children } = window.hostProps;
children.CardField({ onValid: () => {} }).render('#card-container');

Each child tag must be registered in the host bundle before hostProps is initialized. Current hosts resolve executable validators, defaults, decorators, and regular expressions from that local registry instead of reconstructing them from JSON. Protocol-v1 metadata is still emitted for older hosts during staged upgrades, so nested child URLs must remain static strings.

---

Migrating from 0.0.15 to 0.1.0

Version 0.1.0 keeps ForgeFrame's existing iframe/popup model, but makes several previously permissive or ambiguous behaviors explicit. Ordinary integrations using an HTTP(S) URL, a matching domain policy, standard props, and await instance.render(container) should upgrade without code changes.

Upgrade checklist

Before upgrading, check the integration for these less-common patterns:

• autoResize configuration or an AutoResizeOptions type import.
• render() or renderTo() calls without a container, or updateProps() calls made before rendering finishes.
• Computed component URLs that are not HTTP(S) or do not match domain.
• name, src, or srcdoc inside custom iframe attributes.
• Sensitive or server-required queryParam / bodyParam props whose delivery depends on sendToHost, sameDomain, or trustedDomains.
• Nested components that are not also imported or defined by the host bundle.
• Consumer diagnostics that depend on receiving the host's remote Error.stack.

If none of these apply, the upgrade should be drop-in for the normal create, render, callback, prop-update, export, resize, and close flows.

Area	Change in 0.1.0	Migration action
Component URLs	Only HTTP(S) URLs are accepted, and domain is enforced against the resolved host origin.	Ensure every static or computed URL uses HTTP(S) and matches domain.
Rendering	render() and renderTo() require a container. Concurrent render() calls share one operation, and updateProps() rejects while rendering is in progress.	Always pass a container and await render() before updating props.
Initial query/body props	sendToHost, sameDomain, and trustedDomains now apply to queryParam and bodyParam; sameDomain values are withheld from the initial request.	Check any server bootstrap fields and never place secrets in the URL.
Iframe attributes	ForgeFrame owns name, src, and srcdoc.	Remove those keys from custom attributes; configure navigation with url.
Auto-resize	The unused autoResize option and exported AutoResizeOptions type were removed, along with the internal content-dimension helper.	Remove autoResize and AutoResizeOptions imports; use instance.resize() or host-driven sizing.
Nested components	Hosts resolve child factories from their local component registry so executable schemas are preserved.	Import or define child components in the host bundle before initHost(). Keep child URLs static for protocol-v1 compatibility.
Remote errors	Error messages still cross the bridge, but remote stack traces do not.	Do not depend on a remote Error.stack; collect host-side diagnostics locally.

The wire protocol remains version 1 and retains legacy nested-component metadata for staged upgrades. Upgrade both sides together where practical. If upgrading separately, ensure the host bundle registers every nested child before switching the consumer, and do not rely on newly callable host exports until both sides are current.

---

API Reference

ForgeFrame Object

import ForgeFrame, { prop } from 'forgeframe';

ForgeFrame.create(options)        // Create a component
ForgeFrame.destroy(instance)      // Destroy an instance
ForgeFrame.destroyByTag(tag)      // Destroy all instances of a tag
ForgeFrame.destroyAll()           // Destroy all instances
ForgeFrame.isHost()               // Check if in host context
ForgeFrame.isEmbedded()           // Alias for isHost() - more intuitive naming
ForgeFrame.initHost(props?, allowedConsumerDomains?) // Required before direct window.hostProps access
ForgeFrame.getHostProps()         // Get hostProps in host context
ForgeFrame.isStandardSchema(val)  // Check if value is a Standard Schema

ForgeFrame.prop                   // Prop schema builders (also exported as `prop`)
ForgeFrame.PROP_SERIALIZATION     // Prop serialization constants
ForgeFrame.CONTEXT                // Context constants (IFRAME, POPUP)
ForgeFrame.EVENT                  // Event name constants
ForgeFrame.PopupOpenError         // Popup blocker/open failures
ForgeFrame.VERSION                // Library version

Component Options

interface ComponentOptions<P> {
  tag: string;
  url: string | ((props: P) => string);
  dimensions?: { width?: number | string; height?: number | string } | ((props: P) => { width?: number | string; height?: number | string });
  props?: PropsDefinition<P>;
  defaultContext?: 'iframe' | 'popup';
  containerTemplate?: (ctx: TemplateContext<P>) => HTMLElement | null;
  prerenderTemplate?: (ctx: TemplateContext<P>) => HTMLElement | null;
  domain?: DomainMatcher;                 // Consumer-side trusted host origins
  allowedConsumerDomains?: DomainMatcher; // Host-side allowed consumer origins
  eligible?: (opts: { props: P }) => { eligible: boolean; reason?: string };
  validate?: (opts: { props: P }) => void;
  attributes?: IframeAttributes | ((props: P) => IframeAttributes);
  style?: IframeStyles | ((props: P) => IframeStyles);
  timeout?: number;
  children?: (opts: { props: P }) => Record<string, ForgeFrameComponent>;
}

Instance Methods

const instance = MyComponent(props);

await instance.render(container, context?)   // Render into a container (container is required)
await instance.renderTo(window, container)   // Supports only current window; throws for other windows
await instance.close()                       // Close and destroy
await instance.focus()                       // Focus
await instance.resize({ width, height })     // Resize
await instance.show()                        // Show
await instance.hide()                        // Hide
await instance.updateProps(newProps)         // Update props (normalized + validated)
instance.clone()                             // Clone with same props
instance.isEligible()                        // Check eligibility

instance.uid                                 // Unique ID
instance.event                               // Event emitter
instance.state                               // Mutable state
instance.exports                             // Host exports

---

TypeScript

ForgeFrame is written in TypeScript and exports all types.

import ForgeFrame, {
  prop,
  PropSchema,
  StringSchema,
  NumberSchema,
  BooleanSchema,
  FunctionSchema,
  ArraySchema,
  ObjectSchema,
  createReactComponent,
  withReactComponent,
  type ComponentOptions,
  type ForgeFrameComponent,
  type ForgeFrameComponentInstance,
  type HostProps,
  type StandardSchemaV1,
  type TemplateContext,
  type Dimensions,
  type EventHandler,
  type GetPeerInstancesOptions,
} from 'forgeframe';

Typing Host hostProps

import { initHost, prop, type HostProps } from 'forgeframe';

interface MyProps {
  name: string;
  onSubmit: (data: FormData) => void;
}

const hostProps = {
  name: prop.string(),
  onSubmit: prop.function<(data: FormData) => void>(),
};

const allowedConsumerDomains = ['https://app.example.com'];

declare global {
  interface Window {
    hostProps?: HostProps<MyProps>;
  }
}

initHost(hostProps, allowedConsumerDomains);
window.hostProps!.name;
window.hostProps!.onSubmit;
window.hostProps!.close;
window.hostProps!.resize;

---

Browser Support

ForgeFrame ships ES2022 output. Use modern evergreen browsers or transpile the package for older targets in your consumer build pipeline.

Note: Internet Explorer is not supported. If you require IE-era compatibility, use Zoid.

---

License

MIT
