iobroker.mcp

ioBroker.mcp

MCP server for ioBroker

Description

This adapter exposes ioBroker as an MCP (Model Context Protocol) server, so MCP-capable clients (e.g. Claude Desktop) can read and control your installation through a well-defined set of tools.

Features

• MCP server over the Streamable HTTP transport (/mcp endpoint)
• Configurable HTTP/HTTPS web server
• Configurable port and bind address
• Optional authentication
• Optional SSL/TLS support
• Network diagnostics (ICMP ping / TCP probe) to troubleshoot adapter connections
• Adapter repository search to recommend installable adapters

Operating modes

The adapter can run in two ways:

1. Standalone (default) – it starts its own web server on the configured port. The MCP endpoint is http(s)://<host>:<port>/mcp.

2. Web extension – it runs inside an existing web adapter instance and shares its web server (port, authentication, SSL). Select the target web instance in the admin configuration ("Extend WEB adapter"). The MCP endpoint is then served under the web adapter, e.g. http(s)://<host>:8082/mcp/.

   When a web instance is selected, the standalone server settings (port, bind address, authentication, SSL) are hidden because they are inherited from the chosen web instance.

Configuration

The adapter can be configured through the ioBroker admin interface using JSONConfig:

Server Configuration

• Extend WEB adapter: Select a web instance to run as its extension. Leave empty to run standalone.
• Port: The port on which the web server will listen (default: 8093) – standalone only
• Bind Address: IP address to bind the server to (0.0.0.0 for all interfaces) – standalone only

Authentication

• Enable Authentication: Enable ioBroker user authentication for the web server
• Default User: The ioBroker user whose permissions every MCP request runs with (default: admin). All object/state reads and writes performed by the tools are executed in the name of this user, so the user's ACLs are enforced. A plain name like operator is automatically expanded to system.user.operator. When running as a web extension and no user is set here, the host web instance's default user is used.

Permissions

• Allow setting states: Allow MCP clients to write state values (the set_state and set_states tools). Default: on.
• Allow object/file changes: Allow MCP clients to create/modify/delete objects and files (the set_object, delete_object, create_state, create_scene, write_file, delete_file, rename_file and mkdir tools). Default: off. When off, these tools are not exposed at all.

SSL/TLS Configuration

• Enable HTTPS: Enable HTTPS/SSL for secure connections
• Public Certificate: Path to the public certificate file
• Private Key: Path to the private key file
• Chained Certificate: Path to the chained certificate file (optional)

MCP Endpoint

The MCP server is served at POST/GET/DELETE /mcp using the Streamable HTTP transport with per-session state (tracked via the Mcp-Session-Id header). Point your MCP client at:

• standalone: http(s)://<host>:<port>/mcp
• web extension: http(s)://<host>:<webPort>/mcp/

Available tools

Tool	Description
get_states	Retrieve the current value of one or multiple states; IDs may contain wildcards (e.g. hue.0.*.brightness)
get_object	Read a single object by its ID
search_objects	Search objects/states by keyword (matched against ID and name); optional filters for object type, role, room and source adapter instance
list_devices	List detected devices grouped by room (uses the ioBroker type-detector to expose functional devices with named controls); optional language and room filter
list_instances	List adapter instances with their status
list_adapters	List installed adapters with metadata (version, title, description, keywords)
search_adapter_repository	Search the ioBroker adapter repository (all installable adapters, not just installed ones) by keyword; optional type category, onlyNotInstalled and language filters — use it to recommend which adapter to install for a device/service
list_hosts	List ioBroker hosts with their status
list_rooms	List rooms (enum.rooms.*) with localized names and member details; optional language and withIcons
list_functions	List functions (enum.functions.*) with localized names and member details; optional language and withIcons
history_query	Query historical values (requires a history adapter); aggregations: raw, min, max, avg, sum, count, minmax, percentile, quantile, integral
read_file	Read a file from an adapter file storage (optional base64)
list_files	List a directory in an adapter file storage
file_exists	Check whether a file exists in an adapter file storage
get_logs	Retrieve recent ioBroker log lines; optional filters by level (error/warn/info/debug), source adapter and start time (from_ts)
write_log	Write a message to the ioBroker log
system_info	Get system and js-controller information
ping_host	Diagnose connectivity to a network device: ICMP ping to host plus an optional TCP connect to port — useful to investigate adapter ETIMEDOUT/connection errors
set_state	Set the value of a state (value coerced to the state type) — requires Allow setting states
set_states	Set multiple states in one call (for scenes/group actions like "all lights off") — requires Allow setting states
set_object	Create/update an object (merges common/native) — requires Allow object/file changes
delete_object	Delete an object, optionally with all children — requires Allow object/file changes
create_state	Create a new state object with type/role/unit/min/max and optional initial value — requires Allow object/file changes
create_scene	Create or update a scene for the ioBroker scenes adapter (state/value pairs applied together) — requires Allow object/file changes
write_file	Write a file to an adapter file storage — requires Allow object/file changes
delete_file	Delete a file from an adapter file storage — requires Allow object/file changes
rename_file	Rename/move a file within the same adapter file storage — requires Allow object/file changes
mkdir	Create a directory in an adapter file storage — requires Allow object/file changes

All object/state access runs with the permissions of the configured Default User. The write tools are only registered when their respective permission option is enabled.

Resources & live updates (SSE)

States and objects are also exposed as MCP resources using the canonical ioBroker URI scheme, so clients can read and subscribe to them. The server pushes changes over the Streamable HTTP SSE stream (notifications/resources/updated).

• States: iobstate://<id> (e.g. iobstate://javascript.0.temperature) – resources/read returns { id, val, ack, ts, lc, q }.
• Objects: iobobject://<id> (e.g. iobobject://system.adapter.admin.0) – resources/read returns the object.
• Logs: ioblog://all (every source) or ioblog://<source> (e.g. ioblog://admin.0) – resources/read returns the recent log lines ({ source, logs: [{ ts, level, source, message }] }). Subscribing enables log forwarding for the adapter; each new matching line triggers a notifications/resources/updated.
• resources/subscribe subscribes to the underlying ioBroker state/object/log; on every change the client receives a notifications/resources/updated for that URI and re-reads it. resources/unsubscribe stops it.

Subscriptions are tracked per session and ref-counted, so the adapter subscribes to a state/object only once regardless of how many clients/sessions watch it, and unsubscribes when the last one leaves.

(Files use iobfile://<adapter>/<path> in the same scheme; they are available via the read_file/write_file tools rather than as subscribable resources.)

Health endpoints (non-MCP)

• GET / - Basic server information
• GET /status - Server status, uptime and active session count
• GET /api/info - Adapter information

Changelog

1.0.11 (2026-07-02)

• (@GermanBluefox) Default port was changed to 8011
• (@GermanBluefox) Corrected the issue with authentication

1.0.8 (2026-06-18)

• (@GermanBluefox) Used @iobroker/mcp-server package

1.0.5 (2026-06-17)

• (@GermanBluefox) Added debug for ICMP ping and TCP probe in ping_host tool

1.0.2 (2026-06-13)

• (@GermanBluefox) Some repo checker errors were fixed

1.0.0 (2026-06-12)

• (@GermanBluefox) Allowed node 18

0.3.1 (2026-06-11)

• (@GermanBluefox) Added search_adapter_repository tool to search the whole adapter repository (not only installed adapters)
• (@GermanBluefox) Added ping_host tool (ICMP ping + optional TCP probe) for network diagnostics

0.2.5 (2026-06-11)

• (@GermanBluefox) Supported direct import of MCP server

0.2.0 (2026-06-11)

• (@GermanBluefox) Many changes: see the previous changelog entry

0.1.5 (2026-06-11)

• (@GermanBluefox) Added wildcard support to get_states (e.g. hue.0.*.brightness)
• (@GermanBluefox) Added set_states for writing multiple states in one call (scenes/group actions)
• (@GermanBluefox) Added delete_object and create_state tools (gated by Allow object/file changes)
• (@GermanBluefox) Added create_scene tool that creates scenes for the ioBroker scenes adapter
• (@GermanBluefox) Added file management tools: list_files, file_exists, delete_file, rename_file, mkdir
• (@GermanBluefox) Added list_adapters to list installed adapters with metadata
• (@GermanBluefox) Extended search_objects with type and adapter filters; the keyword now also matches object names
• (@GermanBluefox) Extended history_query with the aggregations count, minmax, percentile, quantile and integral

0.1.4 (2026-05-28)

• (@GermanBluefox) Initial development

0.0.1 (2025-01-03)

• Initial release with basic web server functionality *Configurable port, bind address, authentication, and SSL
