jk-assembler v1.2.9
jk-assembler
集成组件系统 集成组件是提供了一个快速集成表格和操作项,可以快速完成一个管理系统的表格
快速使用
- 全局引用注册
import JKAssembler from 'jk-assembler' Vue.use(JKAssembler)
- 按需引用
# developing
集成组件
组件名称 | 组件描述 | 组件使用方式 |
---|---|---|
JkAssembler | 集成表单 | 查看 |
JkAssemblerFilter | 集成表单-搜索组件 | 查看 |
JkAssemblerTable | 集成表单-表格组件 | 查看 |
JkAssemblerForm | 集成表单-表单组件 | 查看 |
JkAssemblerFormPanel | 集成表单-表单组件(弹窗模式) | 查看 |
JkAssemblerPagination | 集成表单-分页组件 | 查看 |
JkAssembler
属性值
属性名称 | 属性描述 | 类型 | 默认值 | 版本支持 |
---|---|---|---|---|
config | 集成注册器的设置项 | Function | 1.0.0 |
config 属性
属性名称 | 属性描述 | 类型 | 默认值 | 版本支持 |
---|---|---|---|---|
__searchList | 检索方法 | Function | 1.0.0 | |
filter | 检索配置 | Object | 1.0.0 | |
table | 表格配置 | Object | 1.0.0 | |
form | 表单配置 | Object | 1.0.0 |
示例代码
function baseAssemblerConfig(Vue) { return { __searchList: (queryParams = {}) => { return TableApi.getList(queryParams) }, filter: { ... }, table: { ... }, form: { ... } } }
### JkAssemblerFilter
#### 属性值
属性名称| 属性描述 | 类型 | 默认值 | 版本支持
-|-|-|-|-
realTimeRemoteSearch| 是否开启实时搜索 | Boolean | false | 1.0.0 |
showSearchButton| 显示搜索按钮 | Boolean, Function | false | 1.0.0 |
filterDefault| 自定义检索条件 | Object | {} | 1.0.0 |
filterOptions| 检索条件 | Array | [] | 1.0.0 |
custemFilterButn| 自定义按钮 | Array | [] | 1.0.0 |
> 示例代码
// 搜索栏配置项 filter: { // 是否开启实时搜索 realTimeRemoteSearch: false, // default false
// 显示搜索按钮 showSearchButton: true, // default true
// 是否显示添加按钮, boolean function 如果是function则会执行此方法 showAddButton: true, // default false
// 自定义检索条件 filterDefault: { key: 'value' },
// 检索条件 filterOptions: [ { label: '测试', prop: 'name', // 绑定key is: 'el-input', // 声明使用组件 // 绑定属性 props: { placeholder: '请输入' } }, { prop: 'status', is: 'select-opt', props: { option: { key: 'UNLOCKED', name: '已解锁' }, { key: 'LOCKED', name: '未解锁' } , optionValue: 'key', optionLabel: 'name', placeholder: '解锁状态' } } ], // 自定义按钮 custemFilterButn: { name: '导出客户', props: { type: 'success', icon: 'el-icon-download' }, event: async() => { console.log('custom butn click') } }, ... }
### JkAssemblerTable
#### 属性值
属性名称| 属性描述 | 类型 | 默认值 | 版本支持
-|-|-|-|-
data| 绑定的数据 | Array | [] | 1.0.0 |
tableProps| 表格中可以bind的所有值 | Object | {} | 1.0.0 |
tableEvents| 表格中可以bind的所有Table Events | Object | {} | 1.0.0 |
tableColumns| 表格列表项声明 | Array | [] | 1.0.0 |
rowOperateList| 表格操作项 -- 按钮组 | Array | [] | 1.0.0 |
> 示例代码
function tableConfig() { return { // 绑定的数据 data: [],
// 表格中可以bind的所有值
tableProps: {},
// 表格中可以bind的所有Table Events
tableEvents: {
'sort-change': ({ column, prop, order }) => {
if (order === 'ascending') {
order = 'asc'
} else if (order === 'descending') {
order = 'desc'
}
const orderObj = { sort: null }
if (order) {
orderObj.sort = `${prop},${order}`
}
Vue.__setFilterListQuery(orderObj)
},
},
// 表格列表项声明
tableColumns: [
// 展示选择按钮
{ type: 'selection' },
// 展示序号
{ type: 'index' },
// 展示为一个可展开的按钮,展开内容为prop绑定的值
{ type: 'expand', prop: 'title' },
// 展示为一个可展开的按钮,展开内容为自定义render
{
type: 'expand',
prop: 'title', // 绑定属性值
render: (h,, { value, record, index }) => <div>{value}</div>
},
// 普通的 table-item
{
prop: 'id',
label: '编号'
},
// 开启sortable, 需配合table-event使用
{
prop: 'title',
label: '直播标题',
sortable: 'custom'
},
// 使用全局组件
{
prop: 'image',
label: '二维码',
component: {
is: 'table-column-images'
}
},
// 使用一个完整并且带配置的组件
{
prop: 'status',
label: '上架状态',
// 设置表单项为一个组件,组件需要全局注册,并且使用双向绑定
component: {
is: 'table-column-status',
props: {
'inactive-value': 'OFFLINE',
'active-value': 'ONLINE'
},
events: function(row) {
return {
change: async(val) => {
console.log(val)
}
}
}
}
},
// 使用自定义render
{
prop: 'startDate',
label: '有效期',
render: (h, { value, record }) =>
<span>{ parseTime(record.startDate) } —— { parseTime(record.endDate) }</span>
},
{
prop: 'status',
label: '状态',
sortable: 'custom',
render: (h, { value, record }) => {
if (value === 'ONLINE') return <el-tag type='success'>使用中</el-tag>
return <el-tag>已失效</el-tag>
}
}
],
// 表格操作项 -- 按钮组
rowOperateList: [
{
key: 'edit', // 使用编辑key
name: '编辑', // 按钮文字
props: {
icon: 'el-icon-edit-outline',
type: 'success',
plain: true
}
},
{
props: {
icon: 'el-icon-document-delete',
type: 'danger',
plain: true
},
event: async(record, index, rows) => {
// console.log('record, index, rows: ', record, index, rows)
await Vue.$confirm('你确定要删除吗', '温馨提示', { type: 'warning' })
const { code } = await TableApi.del(record.id)
if (code === 200) {
Vue.refresh()
Vue.$message.success('删除成功!')
}
}
}
]
} }
### JkAssemblerForm
#### 属性值
属性名称| 属性描述 | 类型 | 默认值 | 版本支持
-|-|-|-|-
fields| 表单项 | Array | [] | 1.0.0 |
formProps| 表单绑定属性值 | Object | {} | 1.0.0 |
tableEveformEventsnts| 表单绑定事件 | Object | {} | 1.0.0 |
submit| 点击确定-回调事件 | Function | ()=>{} | 1.0.0 |
cancel| 点击确定-回调事件 | Function | ()=>{} | 1.0.0 |
#### 事件
事件名称| 事件描述 |回调参数| 版本支持
-|-|-|-
submit| 点击确定-回调事件 |formProps| 1.0.0 |
cancel| 点击确定-回调事件 || 1.0.0 |
> 示例代码
// form configs form: { // 表单项 fields: [ { prop: 'title', rules: { required: true, message: '必填项' }, // form-item props attributes: { label: '标题' }, // form-item使用的组件 component: { is: 'el-input', props: { placeholder: '请输入' }, events: {} } }, { prop: 'image', rules: { required: true, message: '必填项' }, attributes: { label: '封面图' }, component: { is: 'upload-image', props: {}, events: {} } } ],
// 表单绑定属性值 formProps: {},
// 表单绑定事件 formEvents: {},
// 点击确定-回调事件 submit: async(row) => { console.log('form submit event: ', row) },
// 点击取消-回调事件 cancel: (row) => { console.log('form cancel event') } }
### JkAssemblerFormPanel
#### 属性值
属性名称| 属性描述 | 类型 | 默认值 | 版本支持
-|-|-|-|-
data/v-model | 显示弹窗 | Boolean | [] | 1.0.0 |
formModel| 表单绑定的model值 | Object | {} | 1.0.0 |
config| [表单配置项](#JkAssemblerForm) | Object | {} | 1.0.0 |
> 示例代码
{ formModel: {}, show: false, form: { ... } }
### JkAssemblerPagination
#### 属性值
属性名称| 属性描述 | 类型 | 默认值 | 版本支持
-|-|-|-|-
value/v-model | 分页属性 | Object | {currentPage: 1,pageSize: 10} | 1.0.0 |
totalCount| 总页数 | Number | 0 | 1.0.0 |
#### 事件
事件名称| 事件描述 | 回调参数| 版本支持
-|-|-|-
pageSizeChange | 页数size改变 | true | 1.0.0 |
currentPageChange| 当前页码改变 | false | 1.0.0 |
> 示例代码
<jk-assembler-pagination v-model="pageOptions" :totalCount="totalCount" @pageSizeChange="search" @currentPageChange="search" />
## 使用permission
组件提供了一个permission的实现模型
![avatar](https://hxy-web1.oss-cn-hangzhou.aliyuncs.com/prev/perv2.gif)
### 如何使用
#### 集成组件使用
组件注册器或者注册器中 `filter` `table` `form` 组件的`props.PermissionRole` 属性中添加用户拥有的权限数组
import { permission } from 'jk-assembler' Vue.use(permission)
window.PermissionRole = 'a1', 'a2'
## [使用内置全局组件](./GC.md)
# 全局组件
## jkColumnImages
提供给表格中的图片项
#### 属性值
属性名称| 属性描述 | 类型 | 默认值 | 版本支持
-|-|-|-|-
value/v-model | 图片数组 | [String, Array] | ()=>[] | 1.0.1 |
dataKey| 数组中图片key | String | | 1.0.1 |
> 示例代码
// 在集成注册器使用 table: { ... tableColumns: { prop: 'image', label: 'jk-column-images', component: { is: 'jk-column-images' } } , ... }
// 在页面中使用
## JkColumnStatus
该组件提供了一个表格项中的上下架和修改状态的switch
#### 属性值
属性名称| 属性描述 | 类型 | 默认值 | 版本支持
-|-|-|-|-
value/v-model|绑定的状态值| [Boolean, String, Number] | false | 1.0.2 |
activeValue|switch 打开时的值| [Boolean, String, Number] | true | 1.0.2 |
inactiveValue|switch 关闭时的值|[Boolean, String, Number] | false | 1.0.2 |
disabled| 是否禁用 | Boolean | false | 1.0.2 |
props| [其他属性值](https://element.eleme.cn/#/zh-CN/component/switch) | Object | {} | 1.0.2 |
#### 事件
事件名称| 事件描述 | 回调参数| 版本支持
-|-|-|-
change | 开关值改变 | value | 1.0.2 |
> 示例代码
// 在集成注册器使用 table: { ... tableColumns: { prop: 'status', label: '上架状态', component: { is: 'jk-column-status', props: { 'inactive-value': 'OFFLINE', 'active-value': 'ONLINE' }, events: function(row) { return { change: async(val) => { console.log(val) } } } } }, , ... }
## JkColumnSort
这个组件是提供表格中一个改变sort的按钮组
#### 属性值
属性名称| 属性描述 | 类型 | 默认值 | 版本支持
-|-|-|-|-
value/v-model | 图片 | [String, Array] | | 1.0.2 |
scope| table-column属性 | Object | | 1.0.2 |
scope.index| table-column的index | Number | | 1.0.2 |
scope.record| table-column的row值 | Object | | 1.0.2 |
scope.rows| table的data数组值 | Array | | 1.0.2 |
#### 事件
事件名称| 事件描述 | 回调参数| 版本支持
-|-|-|-
up | 点击向上按钮 | 两项的id {id1,id2} | 1.0.0 |
down| 点击向下按钮 | 两项的id {id1,id2} | 1.0.0 |
> 示例代码
// 在集成注册器使用 table: { ... tableColumns: [ { prop: 'id', label: '排序值', component: { is: 'table-column-sort', events: (row) => { return { up: async(val) => { // console.log('val: ', val) await TableApi.sequence(val) await Vue.refresh() }, down: async(val) => { // console.log('val: ', val) await TableApi.sequence(val) await Vue.refresh() } } }
}
}
], ... }
## JkFormSelect
这个组件是提供一个选择器组件,用在集成表单和filter中
#### 属性值
属性名称| 属性描述 | 类型 | 默认值 | 版本支持
-|-|-|-|-
value/v-model | 绑定的属性值 | [String, Number] | '' | 1.0.2 |
option| 选择项数组 | [Function, Array, Promise] | [] | 1.0.2 |
optionValue| 选择项的结果 | [String, Number, Object] | [] | 1.0.2 |
optionLabel| 选择项的展示文本 | String | | 1.0.2 |
optionDefaultItem| 默认选项,需和option数组项一样,默认插入头部 | [String, Object] | | 1.0.2 |
disabled| 是否禁用 | Boolean | false | 1.0.2 |
#### 事件
事件名称| 事件描述 | 回调参数| 版本支持
-|-|-|-
change | 选择值改变 | optionValue | 1.0.2 |
> 示例代码
// 集成组件使用 filter: { { prop: 'status', is: 'jk-form-select', props: { option: { key: 'UNLOCKED', name: '已解锁' }, { key: 'LOCKED', name: '未解锁' } , optionValue: 'key', optionLabel: 'name', placeholder: '解锁状态' } } }
// 使用请求 async function getCourseCategories() { const { data } = await CourseCategories.getList() return data } { prop: 'categoryId', is: 'jk-form-select', props: { option: getCourseCategories(), optionValue: 'id', optionLabel: 'name', placeholder: '选择分类' } },
// 在页面中使用 <jk-form-select v-model="addForm.regionId" :option="regionsOpt" optionValue="id" optionLabel="name"
JkFormCheckbox
这个组件是提供一个checkbox组件,用在集成表单页中
属性值
属性名称 | 属性描述 | 类型 | 默认值 | 版本支持 |
---|---|---|---|---|
value/v-model | 绑定的属性值 | String, Number | '' | 1.0.2 |
option | 选择项数组 | Function, Array, Promise | [] | 1.0.2 |
optionValue | 选择项的结果 | String, Number, Object | [] | 1.0.2 |
optionLabel | 选择项的展示文本 | String | 1.0.2 |
事件
事件名称 | 事件描述 | 回调参数 | 版本支持 |
---|---|---|---|
change | 选择值改变 | optionValue | 1.0.2 |
示例代码
// 集成组件使用 async function getCourseCategories() { const { data } = await CourseCategories.getOnlineList() return data } { prop: 'categories', rules: [{ required: true, message: '请至少选择一项' }], attributes: { label: '适用范围' }, component: { is: 'jk-form-checkbox', props: { option: getCourseCategories(), optionValue: 'id', optionLabel: 'name' } } }
JkFormUploadImage
这个组件是提供一个单图片上传组件
属性值
属性名称 | 属性描述 | 类型 | 默认值 | 版本支持 |
---|---|---|---|---|
image/v-model | 绑定的属性值 | String | '' | 1.0.2 |
request | 图片上传Request | Function | 1.0.2 |
事件
事件名称 | 事件描述 | 回调参数 | 版本支持 |
---|---|---|---|
success | 图片长传成功 | url | 1.0.2 |
示例代码
<jk-form-upload-image v-model="image" :request="request" @success="setUpload"/>
function uploadFile(file) {
const formdata = new FormData()
formdata.append('files', file)
return new Promise((resolve, reject) => {
request({
url: /files
,
headers: {
'Content-Type': 'multipart/form-data;charset=UTF-8'
},
method: 'post',
data: formdata
}).then(res => {
console.log('uploadFile: ', res)
resolve(res.data0.url)
}).catch(err => {
reject(err)
})
})
}
export default { data() { return { image: '', request: uploadFile } }, methods: { setUpload(url) { // this.image = url } } }
## JkFormUploadVideo
这个组件是提供一个单媒体(视频,音频)上传组件
#### 属性值
属性名称| 属性描述 | 类型 | 默认值 | 版本支持
-|-|-|-|-
video/v-model | 绑定的属性值 | String | '' | 1.0.2 |
butnText | 按钮名称 | String | '上传' | 1.0.2 |
times | 媒体事件 | [String, Number] | '' | 1.0.2 |
request| 图片上传Request | Function | | 1.0.2 |
#### 事件
事件名称| 事件描述 | 回调参数| 版本支持
-|-|-|-
success | 长传成功 | url | 1.0.2 |
> 示例代码
<jk-form-upload-video v-model="image" :time="time" :request="request" @success="setUpload"/>
function uploadFile(file) {
const formdata = new FormData()
formdata.append('files', file)
return new Promise((resolve, reject) => {
request({
url: /files
,
headers: {
'Content-Type': 'multipart/form-data;charset=UTF-8'
},
method: 'post',
data: formdata
}).then(res => {
console.log('uploadFile: ', res)
resolve(res.data0.url)
}).catch(err => {
reject(err)
})
})
}
export default { components: { Upload }, data() { return { video: '', time: '', request: uploadFile } }, methods: { setUpload(url) { // this.image = url } } }
## JkPreviewImage
这个组件是提供一个函数调用组件,用来预览图片
#### 属性值
属性名称| 属性描述 | 类型 | 默认值 | 版本支持
-|-|-|-|-
imgList | 图片 | [String, Array] | ()=>[] | 1.0.1 |
index| 第几个图片 | Number | 0 | 1.0.1 |
> 示例代码
<el-button @click="showPrev">点击测试预览图片
const imgList = [] const img = 'https://img10.360buyimg.com/n12/jfs/t23431/303/1885264711/153012/fe4ae9b8/5b6be240N82f3fc92.jpg' const index = 1 showPrev() { this.$previewImage(img) this.$previewImage(imgList) this.$previewImage(imgList, index) }
## Build Setup
``` bash
# install dependencies
npm install
# serve with hot reload at localhost:8080
npm run dev
# build for production with minification
npm run build
# publish npm
npm publish
