k9shield v1.0.3

K9Shield

K9Shield is a comprehensive security middleware for Node.js applications, providing robust protection against various web security threats. It offers advanced features like DDoS protection, rate limiting, IP management, and security headers management.

Updates

Data Protection Enhancements (January 2025)

• Added advanced data loss prevention module
• Implemented sensitive data detection and masking
• Integrated k9crypt for secure data encryption
• Added custom pattern support for sensitive data
• Enhanced data protection with regex-based detection
• Implemented async encryption and decryption methods
• Added comprehensive data masking techniques for various sensitive information types

Usage Example

const shield = new K9Shield();

// Optional: Scan for sensitive data
const sensitiveDataResult = shield.scanForSensitiveData('Credit Card: 4111-1111-1111-1111');
console.log(sensitiveDataResult);
// Output: { hasSensitiveData: true, detectedData: { creditCard: ['4111-1111-1111-1111'] } }

// Optional: Mask sensitive data
const maskedData = shield.maskSensitiveData('Email: john.doe@example.com');
console.log(maskedData);
// Output: 'Email: jo****@example.com'

// Optional: Encrypt sensitive data
const encryptedData = await shield.encryptSensitiveData('Secret Information');
const decryptedData = await shield.decryptSensitiveData(encryptedData);

// Optional: Add custom sensitive pattern
shield.addCustomSensitivePattern('customId', /\bCUST-\d{6}\b/);

Module Status

• Completely Optional: The data loss prevention module is not mandatory
• Can be Disabled: No impact on core security features
• Modular Design: Use only the features you need
• Performance Overhead: Minimal additional processing
• Recommended for: Applications handling sensitive personal or financial data

Note: While optional, this module provides an additional layer of data protection for applications requiring advanced data handling.

Table of Contents

• Features
• Installation
• Quick Start
• Core Components
• Configuration
• Security Features
• API Reference
• Testing
• Examples
• Contributing
• License

Features

Core Security Features

• DDoS Protection

  • Progressive penalty system
  • Connection tracking
  • Burst detection
  • Path-based rate limiting
  • Configurable thresholds and block durations

• Rate Limiting

  • Route-specific limits
  • Flexible time windows
  • Throttling support
  • Ban duration management
  • Distributed system support

• IP Management

  • CIDR notation support
  • IPv6 support with IPv4 mapping
  • Private IP detection
  • Whitelist/Blacklist functionality
  • Proxy support

• Request Validation

  • Method validation
  • Payload size limits
  • Header validation
  • Pattern detection (SQL Injection, XSS, Path Traversal)
  • User Agent and Referer filtering

Advanced Security

• Security Headers

  • Content Security Policy (CSP)
  • Permissions Policy
  • HSTS support
  • XSS protection
  • Frame options
  • Content type options

• Pattern Detection

  • SQL Injection patterns
  • XSS patterns
  • Path traversal attempts
  • Custom pattern support
  • Regular expression based detection

Monitoring & Logging

• Logging System

  • Multiple log levels
  • Automatic rotation
  • Archive management
  • Performance metrics
  • Security event tracking

• Request Tracking

  • IP tracking
  • Request duration
  • Path monitoring
  • Error logging
  • Detailed request information

Installation

npm install k9shield

Quick Start

Basic Express Integration

const express = require('express');
const K9Shield = require('k9shield');

const app = express();
const shield = new K9Shield();

// Protect all routes
app.use(shield.protect());

app.get('/', (req, res) => {
    res.json({ message: 'A secure endpoint' });
});

app.listen(3000, () => {
    console.log('Server running securely');
});

Detailed Security Configuration

const shield = new K9Shield({
    rateLimiting: {
        enabled: true,
        default: {
            maxRequests: 10,     // 10 requests per minute
            timeWindow: 60000,   // 1 minute
            banDuration: 300000  // 5 minutes ban
        },
        routes: {
            '/api/sensitive-endpoint': {
                'POST': {
                    maxRequests: 3,      // Stricter control for sensitive endpoint
                    timeWindow: 60000,   // 1 minute
                    banDuration: 600000  // 10 minutes ban
                }
            }
        }
    },
    security: {
        maxBodySize: 1024 * 100,  // 100KB payload limit
        allowedMethods: ['GET', 'POST', 'PUT', 'DELETE'],
        userAgentBlacklist: ['bad-bot', 'malicious-crawler']
    },
    ddosProtection: {
        enabled: true,
        config: {
            maxConnections: 50,
            blockDuration: 300,
            requestThreshold: 30,
            rateLimitByPath: {
                '/api/*': 20,    // Special limit for API routes
                '*': 50           // General limit for all routes
            }
        }
    }
});

IP Management Examples

// Block a specific IP
shield.blockIP('192.168.1.100');

// Whitelist an IP
shield.whitelistIP('10.0.0.1');

// Unblock a previously blocked IP
shield.unblockIP('192.168.1.100');

// Remove an IP from whitelist
shield.unwhitelistIP('10.0.0.1');

Adding Custom Security Patterns

// Custom patterns for SQL Injection and XSS
shield.addSuspiciousPattern(/SELECT.*FROM/i);
shield.addSuspiciousPattern(/<script>|javascript:/i);

Advanced Error Handling

const shield = new K9Shield({
    errorHandling: {
        includeErrorDetails: true,
        customHandlers: {
            // Custom response for rate limit exceeded
            'rateLimitExceeded': (res, data) => {
                res.status(429).json({
                    message: 'Too many requests',
                    retryAfter: data.retryAfter,
                    limit: data.limit
                });
            },
            // Custom response for DDoS attack
            'ddosAttack': (res) => {
                res.status(403).json({
                    message: 'Suspicious traffic detected',
                    action: 'Access denied'
                });
            }
        }
    }
});

Logging and Monitoring

// Get all log records
const logs = shield.getLogs();

// Get archived log records
const archivedLogs = shield.getArchivedLogs();

// Reset all settings and statistics
shield.reset();

Test Environment Configuration

// More flexible settings for development environment
process.env.NODE_ENV = 'development';

const shield = new K9Shield({
    rateLimiting: { enabled: false },  // Rate limit disabled in development
    ddosProtection: { enabled: false } // DDoS protection disabled
});

Production Environment Configuration

// Strict security settings for production
process.env.NODE_ENV = 'production';

const shield = new K9Shield({
    rateLimiting: {
        enabled: true,
        default: { maxRequests: 100, timeWindow: 60000 }
    },
    security: {
        maxBodySize: 1024 * 1024,  // 1MB
        allowPrivateIPs: false
    },
    ddosProtection: {
        enabled: true,
        config: {
            maxConnections: 200,
            blockDuration: 1800000  // 30 minutes block
        }
    },
    logging: {
        level: 'warning',  // Log only critical warnings
        maxLogSize: 10000  // More log storage
    }
});

Core Components

1. K9Shield Class (src/k9shield.js)

The main class that orchestrates all security features:

const shield = new K9Shield({
    security: {
        trustProxy: true,
        allowPrivateIPs: false,
        maxBodySize: 1024 * 1024 // 1MB
    }
});

2. IP Utils (src/utils/ip.js)

Handles IP address management and validation:

// IP management examples
shield.blockIP('192.168.1.100');
shield.whitelistIP('10.0.0.1');
shield.unblockIP('192.168.1.100');
shield.unwhitelistIP('10.0.0.1');

3. Security Module (src/core/security.js)

Manages security patterns and request validation:

// Add custom security patterns
shield.addSuspiciousPattern(/eval\(/i);
shield.addSuspiciousPattern(/(document|window)\./i);

4. Rate Limiter (src/core/rateLimiter.js)

Controls request rates and implements throttling:

const config = {
    rateLimiting: {
        enabled: true,
        default: {
            maxRequests: 100,
            timeWindow: 60000, // 1 minute
            banDuration: 3600000 // 1 hour
        },
        routes: {
            '/api/data': {
                'POST': { maxRequests: 5, timeWindow: 30000 }
            }
        }
    }
};

5. DDoS Protection (src/core/ddos.js)

Provides DDoS attack prevention:

const config = {
    ddosProtection: {
        enabled: true,
        config: {
            maxConnections: 200,
            timeWindow: 60000,
            blockDuration: 1800000,
            requestThreshold: 500,
            burstThreshold: 50
        }
    }
};

Configuration

Complete Configuration Example

const shield = new K9Shield({
    security: {
        trustProxy: true,
        allowPrivateIPs: false,
        maxBodySize: 1024 * 1024,
        allowedMethods: ['GET', 'POST', 'PUT', 'DELETE'],
        userAgentBlacklist: ['bad-bot', 'malicious-crawler'],
        refererBlacklist: ['malicious.com'],
        securityHeaders: {
            'X-Content-Type-Options': 'nosniff',
            'X-Frame-Options': 'DENY',
            'X-XSS-Protection': '1; mode=block',
            'Strict-Transport-Security': 'max-age=31536000; includeSubDomains'
        },
        csp: {
            'default-src': ["'self'"],
            'script-src': ["'self'", "'unsafe-inline'"],
            'style-src': ["'self'", "'unsafe-inline'"],
            'img-src': ["'self'", 'data:', 'https:']
        },
        permissions: {
            'geolocation': '()',
            'camera': '()',
            'microphone': '()'
        }
    },
    rateLimiting: {
        enabled: true,
        default: {
            maxRequests: 100,
            timeWindow: 60000,
            banDuration: 3600000,
            throttleDuration: 60000,
            throttleDelay: 1000
        },
        routes: {
            '/api/data': {
                'POST': { maxRequests: 5, timeWindow: 30000 }
            }
        }
    },
    ddosProtection: {
        enabled: true,
        config: {
            maxConnections: 200,
            timeWindow: 60000,
            blockDuration: 1800000,
            requestThreshold: 500,
            burstThreshold: 50,
            slowRequestThreshold: 10,
            rateLimitByPath: {
                '/api/*': 100,
                '/auth/*': 20,
                '*': 500
            }
        }
    },
    logging: {
        enable: true,
        level: 'info',
        maxLogSize: 5000,
        archiveLimit: 5
    },
    errorHandling: {
        includeErrorDetails: true,
        customHandlers: {
            'rateLimitExceeded': (res, data) => {
                res.status(429).json({
                    message: 'Too many requests',
                    retryAfter: data.retryAfter,
                    limit: data.limit,
                    windowMs: data.windowMs
                });
            }
        }
    },
    bypassRoutes: ['/health', '/metrics']
});

Security Features

1. Rate Limiting

• Global Limits: Set default limits for all routes
• Route-Specific Limits: Configure different limits for specific routes
• Throttling: Progressive slowdown of requests
• Ban System: Temporary IP bans for limit violations

2. DDoS Protection

• Connection Tracking: Monitor connection counts
• Burst Detection: Identify sudden request spikes
• Progressive Penalties: Increasing restrictions for violations
• Path-Based Limits: Different limits for different paths

3. Security Headers

• CSP: Content Security Policy configuration
• HSTS: HTTP Strict Transport Security
• XSS Protection: Cross-site scripting prevention
• Frame Options: Clickjacking prevention

4. Pattern Detection

• SQL Injection: Detect SQL injection attempts
• XSS: Cross-site scripting pattern detection
• Path Traversal: Directory traversal prevention
• Custom Patterns: Add your own detection patterns

API Reference

Shield Methods

// IP Management
shield.blockIP(ip)
shield.unblockIP(ip)
shield.whitelistIP(ip)
shield.unwhitelistIP(ip)

// Pattern Management
shield.addSuspiciousPattern(pattern)

// Configuration
shield.setConfig(config)

// Logging
shield.getLogs()
shield.getArchivedLogs()

// Reset
shield.reset()

Testing

Run the test server:

node test.js

Test Commands

1. Basic Request Test

curl http://localhost:3000/

2. Rate Limit Test

for i in $(seq 1 10); do
    curl http://localhost:3000/api/test
    echo ""
    sleep 1
done

3. SQL Injection Test

curl -X POST http://localhost:3000/search \
     -H "Content-Type: application/json" \
     -d '{"query": "1 UNION SELECT * FROM users"}'

4. XSS Test

curl -X POST http://localhost:3000/comment \
     -H "Content-Type: application/json" \
     -d '{"comment": "<script>alert(\"XSS\")</script>"}'

5. IP Information

curl http://localhost:3000/ip

6. Bypass Routes Test

curl http://localhost:3000/health
curl http://localhost:3000/metrics

7. DDoS Test

for i in $(seq 1 100); do
    curl http://localhost:3000/ &
done

8. Large Payload Test

curl -X POST http://localhost:3000/comment \
     -H "Content-Type: application/json" \
     -d '{"comment": "A...(100KB+)..."}'

Error Handling

K9Shield provides detailed error responses:

• 403: Access Denied / Suspicious Request
• 405: Method Not Allowed
• 413: Payload Too Large
• 429: Too Many Requests
• 500: Internal Server Error

Each error includes:

• Error message
• Error code
• Timestamp
• Additional details (when enabled)

Best Practices

1. Rate Limiting

   • Set appropriate limits based on your application needs
   • Use route-specific limits for sensitive endpoints
   • Implement proper retry-after headers

2. DDoS Protection

   • Configure thresholds based on your server capacity
   • Monitor and adjust settings based on traffic patterns
   • Use bypass routes for critical endpoints

3. Security Headers

   • Implement strict CSP policies
   • Enable HSTS in production
   • Configure appropriate frame options

4. Logging

   • Set appropriate log levels
   • Implement log rotation
   • Monitor security events regularly

Contributing

We welcome contributions! Please follow these steps:

1. Fork the repository
2. Create your feature branch
3. Commit your changes
4. Push to the branch
5. Create a Pull Request

License

This project is licensed under the MIT License - see the LICENSE file for details.
