OpenDevBrowser

npm version License: MIT TypeScript OpenCode Tool Calls CLI Chrome Extension Test Coverage

Script-first browser automation for AI agents. Snapshot → Refs → Actions.

OpenDevBrowser is an agent-agnostic browser automation runtime for CLI workflows, OpenCode tool calls, and Chrome extension relay sessions. It supports managed launches, direct CDP attach, and extension-backed Ops sessions.

The current public surface includes 77 CLI commands and 70 opendevbrowser_* tools; see docs/CLI.md for the operational command guide. Generated help is the canonical first-contact discovery surface: npx opendevbrowser --help and npx opendevbrowser help now lead with a Find It Fast block that uses the exact lookup terms screencast / browser replay, desktop observation, and computer use / browser-scoped computer use. Shipped builds include Browser replay through screencast-start or screencast-stop and a separate public read-only desktop observation plane through the desktop-* family; those lanes stay explicit, browser-scoped where applicable, and make it clear this is not a desktop agent.

OpenDevBrowser hero image showing AI-assisted annotation and browser automation workflow
AI-assisted annotation and browser automation workflow

Table of Contents
Use It Your Way Features Breaking Changes (latest) Updating
Why OpenDevBrowser? Tool Reference Chrome Extension (Optional) Architecture
Installation Bundled Skills Configuration Development
Quick Start Browser Modes CLI Commands Privacy
Challenge Handling Boundary Relay Channels Security License

Use It Your Way

Interface OpenCode Required Best For
CLI (npx opendevbrowser ...) No Any agent/workflow that can run shell commands
Chrome Extension + Relay No Reusing existing logged-in tabs without launching a new browser
OpenCode Tool Calls Yes Native tool-calling inside OpenCode (opendevbrowser_*)
Frontend Website (private repo) No Product website and generated docs routes

The public repo owns the automation runtime and canonical docs; see docs/SURFACE_REFERENCE.md for the full surface inventory.

Why OpenDevBrowser?

  • Script-first automation model: snapshot → refs → actions, built around accessibility-tree capture instead of brittle selector-first workflows.
  • Stable interaction primitives: refs resolve through backendNodeId, and low-level pointer commands remain available when normal DOM actions are not enough.
  • Flexible session control: run managed sessions, attach through direct CDP, or reuse logged-in tabs through the extension relay and /ops.
  • Design and review workflows: use Inspiredesign harvest, design canvas, shared annotation inbox, and repo-backed code-sync flows without leaving the runtime surface. Pinterest broad-query readiness is driven by byte-backed first-party pin-media-index.json authority; media-analysis.json is advisory and motion-evidence.json is browser replay authority.
  • Diagnostics and bounded challenge handling: start with session-inspector, then drop to console or network polling and unified debug traces when you need channel-level detail.
  • Production guardrails: local-only CDP by default, timing-safe auth, sanitized exports, strict TypeScript, and branch coverage held at 97% or higher.

Installation

Requires Node.js >=18.

For Humans
# Interactive installer (recommended)
npx opendevbrowser

# Or specify location
npx opendevbrowser --global   # ~/.config/opencode/opencode.json
npx opendevbrowser --local    # ./opencode.json

# Full install (config + extension assets)
npx opendevbrowser --full

# Optional: persistent global CLI
npm install -g opendevbrowser
opendevbrowser --version
Local Package Validation

Use this flow to validate first-run onboarding from a source tarball without relying on the published registry package.

cd <public-repo-root>
npm pack

WORKDIR=$(mktemp -d /tmp/opendevbrowser-first-run-XXXXXX)
ISOLATED_ROOT=$(mktemp -d /tmp/opendevbrowser-first-run-isolated-XXXXXX)
export HOME="$ISOLATED_ROOT/home"
export OPENCODE_CONFIG_DIR="$ISOLATED_ROOT/opencode-config"
export OPENCODE_CACHE_DIR="$ISOLATED_ROOT/opencode-cache"
export CODEX_HOME="$ISOLATED_ROOT/codex-home"
export CLAUDECODE_HOME="$ISOLATED_ROOT/claudecode-home"
export AMP_CLI_HOME="$ISOLATED_ROOT/ampcli-home"
cd "$WORKDIR"
npm init -y
npm install <public-repo-root>/opendevbrowser-0.0.39.tgz
npx --no-install opendevbrowser --help
npx --no-install opendevbrowser help

Published npm consumer proof is tracked separately in docs/RELEASE_RUNBOOK.md through scripts/registry-consumer-smoke.mjs.

Set OPDEVBROWSER_SKIP_POSTINSTALL_SKILL_SYNC=1 before npm install only if you need a packaging smoke test that exits the legacy package lifecycle shim before built postinstall code imports. Set OPDEVBROWSER_SKIP_INSTALL_AUTOSTART_RECONCILIATION=1 when you only want to skip install-time daemon auto-start reconciliation.

See docs/FIRST_RUN_ONBOARDING.md for the full onboarding checklist, docs/DEPENDENCIES.md for runtime inventory, and docs/SURFACE_REFERENCE.md for the live CLI and tool surface.

CLI/plugin installs still reconcile daemon auto-start on supported platforms after successful install so the relay is available on login. Raw npm global package postinstall also best-effort reconciles auto-start when npm lifecycle context clearly indicates a global install. Local, ambiguous, conflicting, or non-npm package-manager contexts skip package postinstall auto-start without failing package installation.

Package postinstall auto-start targets the packaged CLI entrypoint dist/cli/index.js, not the lifecycle shim at scripts/postinstall-sync-skills.mjs. src/cli/daemon-autostart.ts owns platform safety and refuses to persist _npx, /tmp, /private/tmp, or onboarding workspace paths before writing LaunchAgent or Task Scheduler state. Package postinstall warnings are non-fatal; repair with opendevbrowser daemon install, inspect with opendevbrowser daemon status, or remove with opendevbrowser daemon uninstall.

Bundled skills sync to OpenCode, Codex, ClaudeCode, AmpCLI, and Agents targets during install. npx opendevbrowser manages global or project-local targets according to the selected skills mode, and package installation (npm install -g, local tarball install, or equivalent) best-effort syncs the canonical bundled packs into the managed global targets during package postinstall. If a global update appears stale, compare command -v opendevbrowser, which -a opendevbrowser, and npm prefix -g; install with the prefix that owns the active binary. See docs/CLI.md for exact target paths.

CLI + Extension (No OpenCode)
# Start relay/daemon runtime
npx opendevbrowser serve

# Launch using extension mode (requires extension popup connected)
npx opendevbrowser launch --extension-only --wait-for-extension

# Or force managed mode without extension
npx opendevbrowser launch --no-extension

Unpacked extension load path after local install:

  • <WORKDIR>/node_modules/opendevbrowser/extension
Frontend Website (Private Repo)
git clone https://github.com/freshtechbro/opendevbrowser-website-deploy.git
cd opendevbrowser-website-deploy/frontend
npm install
npm run dev

Website build/data pipeline lives in the private repo:

  • npm run sync:assets copies mirrored assets into private frontend/public/brand.
  • npm run generate:docs regenerates docs, metrics, and roadmap JSON consumed by /docs.
OpenCode Tool-Call Installation

Use OpenCode only when you want native opendevbrowser_* tool calls; the CLI and extension workflows work without it.

Recommended (CLI, installs plugin + config + bundled skills + extension assets):

npx opendevbrowser --full --global --no-prompt

Explicit flags (config + skills, no prompt):

npx opendevbrowser --global --with-config --skills-global --no-prompt

Manual fallback (edit OpenCode config):

{
  "$schema": "https://opencode.ai/config.json",
  "plugin": ["opendevbrowser"]
}

Config location: ~/.config/opencode/opencode.json

Restart OpenCode, then run opendevbrowser_status to verify the plugin is loaded (daemon status when hub is enabled).

Quick Start

OpenDevBrowser uses the same automation model across plugin tools and CLI commands:

1. Launch a browser session
2. Navigate to a URL
3. Take a review to get target-aware actionables and refs
4. Interact using refs (click, type, select)
5. Re-review or re-snapshot after navigation

Shipping checklist for first-time users (local-package install, daemon, extension, first task, multi-tab auth/cookies):

Parallel execution is target-scoped (ExecutionKey = (sessionId,targetId)): same target is FIFO, different targets can run concurrently up to the governor cap. session-per-worker remains the safest baseline for strict isolation. See docs/CLI.md (Concurrency semantics) and skills/opendevbrowser-best-practices/artifacts/provider-workflows.md (Workflow E).

Core Workflow (Plugin Tools)
Step Tool Purpose
1 opendevbrowser_launch Launch a session (extension relay first; managed fallback is explicit)
2 opendevbrowser_goto Navigate to URL
3 opendevbrowser_review Inspect the active target and capture fresh actionables before acting
4 opendevbrowser_click / opendevbrowser_type Interact with elements
5 opendevbrowser_snapshot Re-capture refs after navigation or DOM changes
6 opendevbrowser_disconnect Clean up session
CLI Automation Quick Start

Run a local daemon for persistent sessions, then drive automation via CLI commands:

# Start daemon
npx opendevbrowser serve

# Preflight daemon-backed workflows
npx opendevbrowser status --daemon --output-format json
# Proceed only when data.fingerprintCurrent === true

# Install auto-start (recommended for resilience)
opendevbrowser daemon install

# Stop/kill the daemon before restarting
npx opendevbrowser serve --stop

# Launch a session
npx opendevbrowser launch --start-url https://example.com

# Review the active target and capture fresh refs
npx opendevbrowser review --session-id <session-id>

# Interact by ref
npx opendevbrowser click --session-id <session-id> --ref r12

opendevbrowser serve includes stale-daemon preflight cleanup by default, so orphan daemon processes are terminated automatically before startup while preserving the active daemon on the requested port. For daemon-backed workflows, run npx opendevbrowser status --daemon --output-format json first and require data.fingerprintCurrent === true before issuing launch, connect, canvas, provider, or release-harness commands.

If protected stop or reuse fails with daemon_fingerprint_mismatch, the running daemon was started by a different OpenDevBrowser build than the current CLI. Use the matching binary for the running daemon, restart it from the current install, or isolate shared environments with OPENCODE_CONFIG_DIR, OPENCODE_CACHE_DIR, and unique daemon or relay ports before retrying.

If you are running from a temporary onboarding workspace, rerun opendevbrowser daemon install from a stable install location before expecting auto-start to survive login. macOS auto-start also writes WorkingDirectory=~/.cache/opendevbrowser so launchd does not start the daemon from /.

For single-shot scripts:

npx opendevbrowser run --script ./script.json --output-format json

Use --output-format json|stream-json for automation-friendly output.

Help-Led Discovery

Start every surface check from generated help when you need the current public lanes. The terminal help now uses these exact phrases so agents can search by intent instead of guessing command names:

  • screencast / browser replay: screencast-start, screencast-stop
  • desktop observation: desktop-status, desktop-windows, desktop-active-window, desktop-capture-desktop, desktop-capture-window, desktop-accessibility-snapshot
  • computer use / browser-scoped computer use: --challenge-automation-mode off|browser|browser_with_helper on research run, shopping run, product-video run, inspiredesign run, and macro-resolve --execute; start with npx opendevbrowser research run --topic "account recovery flow" --sources web,community --challenge-automation-mode browser --mode json --output-format json when you need the first entry point, and use review plus session-inspector as the quickest proof surfaces while the optional helper stays browser-scoped rather than becoming a desktop agent

Challenge Handling Boundary

  • SessionStore remains the blocker FSM source of truth. Managed and /ops-backed responses keep meta.blocker, meta.blockerState, and meta.blockerResolution stable and may append additive meta.challenge plus meta.challengeOrchestration.
  • Direct browser, /ops, and provider fallback paths now share one bounded challenge orchestration plane. It can try auth navigation, legitimate session or cookie reuse, non-secret field fill, and bounded interaction exploration before yielding to a human.
  • Workflow and manager callers can set challengeAutomationMode to off, browser, or browser_with_helper. Effective precedence is run > session > config, and hard gates still apply after resolution.
  • The optional helper bridge is browser-scoped, not a desktop agent. browser forces it to stand down, and browser_with_helper only evaluates it after the existing helper hard gates pass.
  • Shipped builds also expose a public read-only desktop observation plane under separate desktop.* config. It is enabled by default, does not widen /ops or ChallengeRuntimeHandle, and the internal composed path still routes desktop observation back through browser-owned review when challenge automation needs it.
  • Browser fallback returns explicit transport disposition values: completed, challenge_preserved, deferred, or failed. When orchestration runs during fallback, decision evidence is recorded under details.challengeOrchestration.
  • ProviderRegistry is the only durable anti-bot pressure authority. Shared runtime and policy own fallback ordering and resume policy; provider modules only contribute extraction logic and recoveryHints().
  • In scope: preserved sessions, normal browser controls, bounded interaction experimentation, human yield packets for secret or human-authority boundaries, and owned-environment fixtures that use vendor test keys only.
  • Out of scope: hidden bypasses, CAPTCHA-solving services, token harvesting, or autonomous unsandboxed solving of third-party anti-bot systems.

Features

Browser and Session Control
  • Managed, CDP, and extension sessions - Launch fresh browser sessions, attach to existing Chrome CDP endpoints, or reuse logged-in tabs through the extension relay and /ops.
  • Target-aware tab management - List, open, focus, switch, and close targets or named pages while preserving target-scoped FIFO execution for same-tab work.
  • Session diagnostics and cookies - Inspect status, capabilities, relay health, cookies, blocker state, and suggested next actions before running long workflows.
  • Persistent profiles when appropriate - Reuse browser state intentionally through configured profiles, system Chrome cookie import, extension tabs, or explicit provider cookie policy.
Ref-Based Page Interaction and DOM Inspection
  • Snapshot to refs to actions - Capture accessibility-tree snapshots, review actionables, then click, type, select, upload, scroll, press, hover, check, or drag by stable refs.
  • Backend-node resolution - Refs resolve through browser-owned node identity so agents can avoid brittle selector-first automation when the page changes.
  • DOM and state inspection - Read HTML, text, attributes, input values, visibility, enabled state, and checked state for precise automation decisions.
  • Pointer and keyboard escape hatches - Use viewport pointer commands and key presses when a page needs lower-level browser interaction.
Diagnostics, Screenshots, and Browser Replay
  • Console and network polling - Capture console messages, exceptions, request metadata, status codes, and page performance without leaving the runtime.
  • Debug trace snapshots - Combine page, console, network, exception, blocker, and session context into one diagnostic bundle.
  • Screenshots - Capture visible, full-page, or ref-targeted PNG evidence to files or automation-friendly JSON payloads.
  • Screencast / browser replay - Use screencast-start and screencast-stop for browser replay artifacts; these artifacts are separate from annotation storage.
Public Read-Only Desktop Observation and Browser-Scoped Helper Boundary
  • Desktop observation - The desktop-* family exposes public read-only macOS observation for window inventory, active-window context, screenshots, and accessibility snapshots.
  • No desktop agent - Desktop observation does not widen /ops, does not control the desktop, and does not turn OpenDevBrowser into a desktop agent.
  • Browser-scoped computer use - Challenge automation modes stay browser-scoped: off, browser, or browser_with_helper on provider workflows and executable macros.
  • Human-authority boundaries - Secret entry, CAPTCHA solving, token harvesting, and unsandboxed third-party anti-bot bypasses remain out of scope.
Provider Workflows, Macros, and Artifact Bundles
  • Deterministic workflow lanes - Run research, shopping, product-video, and Inspiredesign workflows with JSON, Markdown, compact, path, or context output modes.
  • Artifact-first handoff - Successful artifact-bearing workflows return artifact_path; omitted routine workflow output roots write under .opendevbrowser/<namespace>/<runId>.
  • Provider policy and recovery - Provider registry, challenge orchestration, cookie policy, and fallback ordering preserve blocker truth and recovery hints.
  • Macros - Resolve or execute macro expressions into provider actions with provenance and blocked-run truth preserved in execution reports.
Inspiredesign and Pinterest Readiness Authority
  • Pinterest-ready design research - Inspiredesign harvest can rank references, persist evidence, and produce design handoff artifacts from browser-backed runs.
  • Pin-media-first authority - Pinterest readiness is product-ready only when pin-media-index.json contains byte-backed first-party media evidence for accepted canonical pins.
  • Advisory media analysis - media-analysis.json supplies optional FFmpeg or FFprobe cues but never replaces pin-media authority.
  • Motion authority stays separate - motion-evidence.json is browser replay authority; missing screenshots or motion evidence can be non-blocking only when pin-media authority is complete.
Design Canvas, Workspace, and Code Sync
  • Typed Canvas commands - Use /canvas or opendevbrowser_canvas for design-canvas sessions, imports, reusable inventory, starters, previews, feedback, overlays, and handoff.
  • Workspace orchestration - Canvas coordinates refs-only parent workflows while child sessions own documents, leases, bound sources, previews, and feedback loops.
  • Framework adapter code sync - Built-in lanes include React TSX v2, static HTML, custom elements, Vue SFC, and Svelte SFC bindings with repo-local manifests.
  • Projection boundaries - canvas_html remains the default preview and export contract unless a binding opts into bound_app_runtime after runtime bridge preflight.
Annotation V2 Compact Handoff and Shared Inbox
  • Interactive annotation - Capture annotations through direct CDP or relay transport without coupling annotation storage to screenshots or browser replay.
  • Compact payloads - Annotation V2 stores schemaVersion: 2, screenshot-free compact handoff metadata, redaction metadata, selector bundles, and canvas identity when available.
  • Shared inbox retrieval - Stored annotation retrieval resolves the repo-local shared inbox first, then falls back to extension-local storage when needed.
  • Review-friendly outputs - Delivered and stored annotation outcomes make it clear whether a teammate received the payload or must pull it later.
Skill Packs and Install Targets
  • Canonical bundled packs - Install and update the 10 OpenDevBrowser-specific opendevbrowser-* skill packs for browser automation, design, motion, continuity, login, forms, extraction, research, shopping, and product presentation.
  • Multi-agent target sync - Managed installs sync skills across OpenCode, Codex, ClaudeCode, AmpCLI, and Agents global or project-local targets.
  • Local onboarding helpers - opendevbrowser_prompting_guide, opendevbrowser_skill_list, and opendevbrowser_skill_load work without a browser session, relay, or daemon bootstrap.
  • Ownership-safe lifecycle - Update refreshes CLI-managed canonical packs, adopts matching markerless canonical copies, and uninstall removes only marker- or sentinel-managed canonical packs, leaving unrelated user skill directories untouched.
Security, Challenge, and Reliability Guardrails
  • Secure defaults - Remote CDP is blocked by default, raw CDP is disabled by default, unsafe export is disabled by default, and relay tokens use timing-safe comparison.
  • Origin and pairing controls - Extension, /ops, /canvas, /cdp, /annotation, config, status, and pairing endpoints enforce loopback, origin, token, and rate-limit protections.
  • Sanitized outputs - Exports strip scripts, event handlers, and dangerous CSS, while diagnostics redact tokens, API keys, credentials, and sensitive paths.
  • Reliability gates - Daemon fingerprint preflight, release audits, docs drift checks, strict TypeScript, and 97 percent coverage guard against stale runtime or documentation claims.

Tool Reference

OpenDevBrowser provides 70 tools organized by category: Most runtime actions also have CLI command equivalents (see docs/CLI.md). Complete source-accurate inventory (tools + CLI + /ops + /canvas + /cdp): docs/SURFACE_REFERENCE.md. Terminal help now mirrors the generated public-surface manifest rooted at src/public-surface/source.ts and refreshed by scripts/generate-public-surface-manifest.mjs. npx opendevbrowser --help and npx opendevbrowser help both show every command with its usage and primary flags, every grouped CLI flag, and every bundled opendevbrowser_* tool with its CLI equivalent or tool-only scope. See docs/ASSET_INVENTORY.md for the brand and generated help/public-surface asset inventory used by packaging and website-sync flows.

Session Management
Tool Description
opendevbrowser_launch Launch a session (extension relay first; managed is explicit)
opendevbrowser_connect Connect to existing Chrome CDP endpoint (or relay /ops; legacy /cdp via --extension-legacy)
opendevbrowser_disconnect Disconnect browser session
opendevbrowser_status Get session status and connection info (daemon status in hub mode)
opendevbrowser_status_capabilities Inspect runtime capability discovery for the host and an optional session
opendevbrowser_cookie_import Import validated cookies into the current session
opendevbrowser_cookie_list List session cookies with optional URL filters
opendevbrowser_session_inspector Capture a session-first diagnostic bundle with relay health, trace proof, and a suggested next action
opendevbrowser_session_inspector_plan Inspect browser-scoped computer-use policy, eligibility, and safe suggested steps
opendevbrowser_session_inspector_audit Capture a correlated audit bundle across desktop evidence, browser review, and policy state
Tab/Target Management
Tool Description
opendevbrowser_targets_list List all browser tabs/targets
opendevbrowser_target_use Switch to a specific tab by targetId
opendevbrowser_target_new Open new tab (optionally with URL)
opendevbrowser_target_close Close a tab by targetId
Named Pages
Tool Description
opendevbrowser_page Open or focus a named page (logical tab alias)
opendevbrowser_list List all named pages in session
opendevbrowser_close Close a named page
Navigation & Interaction
Tool Description
opendevbrowser_goto Navigate to URL
opendevbrowser_wait Wait for load state or element
opendevbrowser_snapshot Capture page accessibility tree with refs
opendevbrowser_review Capture target-aware actionables plus status context before acting
opendevbrowser_review_desktop Capture desktop-assisted browser review with read-only desktop evidence and browser-owned verification
opendevbrowser_click Click element by ref
opendevbrowser_hover Hover element by ref
opendevbrowser_press Press a keyboard key (optionally focusing a ref)
opendevbrowser_check Check checkbox/toggle by ref
opendevbrowser_uncheck Uncheck checkbox/toggle by ref
opendevbrowser_type Type text into input by ref
opendevbrowser_select Select dropdown option by ref
opendevbrowser_scroll Scroll page or element
opendevbrowser_scroll_into_view Scroll element into view by ref
opendevbrowser_upload Upload files to a file input or chooser by ref
opendevbrowser_pointer_move Move the pointer to viewport coordinates
opendevbrowser_pointer_down Press a mouse button at viewport coordinates
opendevbrowser_pointer_up Release a mouse button at viewport coordinates
opendevbrowser_pointer_drag Drag between viewport coordinates
opendevbrowser_run Execute multiple actions in sequence
DOM Inspection
Tool Description
opendevbrowser_dom_get_html Get outerHTML of element by ref
opendevbrowser_dom_get_text Get innerText of element by ref
opendevbrowser_get_attr Get attribute value by ref
opendevbrowser_get_value Get input value by ref
opendevbrowser_is_visible Check if element is visible
opendevbrowser_is_enabled Check if element is enabled
opendevbrowser_is_checked Check if element is checked
DevTools & Analysis
Tool Description
opendevbrowser_console_poll Poll console logs since sequence
opendevbrowser_network_poll Poll network requests since sequence
opendevbrowser_debug_trace_snapshot Capture a unified page + console + network + exception diagnostic bundle
opendevbrowser_screenshot Capture page screenshot
opendevbrowser_screencast_start Start a browser replay screencast capture
opendevbrowser_screencast_stop Stop a browser replay screencast capture and return artifact metadata
opendevbrowser_dialog Inspect or handle a JavaScript dialog
opendevbrowser_perf Get page performance metrics
opendevbrowser_prompting_guide Get best-practice prompting guidance
Desktop Observation
Tool Description
opendevbrowser_desktop_status Inspect public read-only desktop observation availability
opendevbrowser_desktop_windows List windows exposed by the public read-only desktop observation plane
opendevbrowser_desktop_active_window Inspect the active window through the public read-only desktop observation plane
opendevbrowser_desktop_capture_desktop Capture the current desktop surface through the public read-only desktop observation plane
opendevbrowser_desktop_capture_window Capture a specific window through the public read-only desktop observation plane
opendevbrowser_desktop_accessibility_snapshot Capture desktop accessibility state through the public read-only desktop observation plane

Desktop observation currently ships as a public read-only macOS surface. Availability, window inventory, and accessibility snapshots rely on the local swift command, while screenshot capture uses the built-in screencapture utility. If desktop-status reports desktop_unsupported on macOS, install Xcode or a Swift toolchain and retry.

Macro Workflows
Tool Description
opendevbrowser_macro_resolve Resolve macro expressions into provider action/provenance (optionally execute)
Annotation
Tool Description
opendevbrowser_annotate Capture interactive annotations via direct (CDP) or relay transport
Design Canvas
Tool Description
opendevbrowser_canvas Execute typed design-canvas session, attach, code-sync, preview, feedback, and overlay commands
Export & Cloning
Tool Description
opendevbrowser_clone_page Export page as React component + CSS
opendevbrowser_clone_component Export element subtree as React component
Skills
Tool Description
opendevbrowser_skill_list List available skills before choosing a local workflow lane
opendevbrowser_skill_load Load a skill by name and topic, especially the bundled quick start

Bundled Skills

OpenDevBrowser includes 10 OpenDevBrowser-specific skill packs. Install, update, and uninstall own the managed skill lifecycle across OpenCode, Codex, ClaudeCode, AmpCLI, and Agents targets:

Skill Purpose
opendevbrowser-best-practices Core prompting patterns and workflow guidance
opendevbrowser-design-agent Contract-first, research-backed frontend and /canvas design execution
opendevbrowser-motion-design Contract-first motion language, pattern selection, reduced-motion, performance, and temporal proof
opendevbrowser-continuity-ledger Long-running task state management
opendevbrowser-login-automation Authentication flow patterns
opendevbrowser-form-testing Form validation and submission workflows
opendevbrowser-data-extraction Structured data scraping patterns
opendevbrowser-research Deterministic multi-source research workflows
opendevbrowser-shopping Deterministic multi-provider deal comparison workflows
opendevbrowser-product-presentation-asset Product screenshot/copy asset collection for presentation pipelines

Installer note:

  • --skills-global and --skills-local sync the 10 canonical opendevbrowser-* packs into managed global or project-local agent directories.
  • Managed installs write a target-level ownership marker, so later update and uninstall only act on CLI-managed skill targets or older config installs that already contain canonical packs.
  • Reinstall and update refresh drifted managed copies, adopt matching markerless canonical copies by writing ownership sentinels, and preserve drifted markerless directories for user review.
  • Uninstall removes marker- or sentinel-managed canonical packs and leaves unrelated directories untouched.

Skills are discovered from (priority order):

  1. .opencode/skill/ (project)
  2. ~/.config/opencode/skill/ (global)
  3. .codex/skills/ (project compatibility)
  4. $CODEX_HOME/skills (global compatibility; fallback ~/.codex/skills)
  5. .claude/skills/ (ClaudeCode project compatibility)
  6. $CLAUDECODE_HOME/skills (ClaudeCode global compatibility; fallback ~/.claude/skills)
  7. .amp/skills/ (AmpCLI project compatibility)
  8. $AMP_CLI_HOME/skills (AmpCLI global compatibility; fallback ~/.amp/skills)
  9. .agents/skills/ (project compatibility)
  10. ~/.agents/skills/ (global compatibility)
  11. Custom paths via skillPaths config
  12. Bundled package fallback: packaged skills/ directory after skillPaths when no installed copy matches

Load a skill: opendevbrowser_skill_load with name and optional topic filter. opendevbrowser_prompting_guide, opendevbrowser_skill_list, and opendevbrowser_skill_load are local onboarding helpers, so they do not require a browser session, relay, or daemon bootstrap.

Browser Modes

Mode Tool Use Case
Managed opendevbrowser_launch Fresh browser, full control, automatic cleanup
CDP Connect opendevbrowser_connect Attach to existing Chrome with --remote-debugging-port
Extension Relay Chrome Extension Attach to logged-in tabs via relay server

Default behavior: opendevbrowser_launch prefers Extension Relay when available. Use --no-extension (and --headless if desired) for managed sessions.

Extension relay relies on flat CDP sessions (Chrome 125+) and uses DebuggerSession sessionId routing for multi-tab and child-target support. When hub mode is enabled, the hub daemon is the sole relay owner and there is no local relay fallback.

Relay ops endpoint: ws://127.0.0.1:<relayPort>/ops. The connect command also accepts base relay WS URLs (ws://127.0.0.1:<relayPort> or ws://localhost:<relayPort>) and normalizes them to /ops. Relay canvas endpoint: ws://127.0.0.1:<relayPort>/canvas for design-canvas editor, session attach/lease flow, code-sync, preview, public feedback pull streams, and overlay flows. Legacy relay /cdp remains available with explicit opt-in (--extension-legacy). When pairing is enabled, /ops, /canvas, and /cdp require a relay token (?token=<relayToken>). Tools and the CLI auto-fetch relay config and tokens.

Relay Channels

Channel What It Does When to Use It
/ops (default) High-level automation protocol with session ownership, event streaming, and multi-client handling Preferred extension relay path for modern workflows
/canvas Typed design-canvas protocol for session handshakes/attach, Figma document import, reusable inventory list/insert, built-in starter list/apply flows, framework-adapter-backed code sync, preview tabs, public feedback pull streams, and overlay selection Use with opendevbrowser_canvas or opendevbrowser canvas during design-canvas workflows
/cdp (legacy) Low-level CDP relay path with compatibility-focused behavior Opt-in compatibility mode (--extension-legacy)
Direct CDP connect Attach to Chrome started with --remote-debugging-port Existing debug/browser setups without extension relay

For full /ops and /canvas command names, /cdp envelope details, and mode/flag matrices, see docs/SURFACE_REFERENCE.md.

Breaking Changes (latest)

  • opendevbrowser_launch now prefers the extension relay by default. Use --no-extension (and --headless if desired) for managed sessions.
  • Relay /ops (default) and legacy /cdp both require a token when pairing is enabled; tools/CLI handle this automatically.

Chrome Extension (Optional)

The extension enables Extension Relay mode - attach to existing logged-in browser tabs without launching a new browser.

Requirements: Chrome 125+ (flat CDP sessions). Older versions will fail fast with a clear error.

Auto-Connect + Auto-Pair

The runtime (plugin or CLI daemon) and extension can automatically pair:

  1. Runtime side: Starts a local relay server and config discovery endpoint
  2. Extension side: Enable "Auto-Pair" toggle and click Connect
  3. Extension fetches relay port from discovery, then fetches token from the relay server
  4. Connection established with color indicator (green = connected)

Auto-connect and Auto-pair are enabled by default for a seamless setup. The extension badge shows a small status dot (green = connected, red = disconnected). If the relay is unavailable, the background worker retries /config + /pair with exponential backoff (using chrome.alarms).

Default Settings (Extension)
Setting Default
Relay port 8787
Auto-connect true
Auto-pair true
Require pairing token true
Pairing token null (fetched on connect)
Connection Flow (Extension Relay)
  1. Extension checks the discovery endpoint at http://127.0.0.1:8787/config by default.
  2. It learns the relay port and whether pairing is required.
  3. If pairing is required and Auto-pair is on, it fetches the token from http://127.0.0.1:<relayPort>/pair.
  4. It connects to ws://127.0.0.1:<relayPort>/extension using the extension origin.

/config and /pair accept loopback requests with no Origin (including Origin: null) to support MV3 + PNA; non-extension origins are still rejected, and preflights include Access-Control-Allow-Private-Network: true.

Troubleshooting: Extension Won't Connect
  • Ensure the active tab is a normal http(s) page (not chrome:// or extension pages).
  • Confirm relayPort and relayToken in ~/.config/opencode/opendevbrowser.jsonc match the popup (Auto-pair should fetch the token).
  • If relayPort is 0, the relay is off.
  • For isolated daemon runs with a custom relay port, set discoveryPort to the same isolated value; keep discoveryPort at 8787 for normal extension discovery.
  • relayToken: false disables relay/hub behavior entirely.
  • relayToken: "" (empty string) keeps relay enabled but disables pairing requirements.
  • Install auto-start with opendevbrowser daemon install from a stable install location so the relay is available on login.
  • Clear extension local data and retry if the token/port seem stuck.
  • If another process owns the relay or discovery port, change the relevant config port or stop it; opencode listening is expected.
Manual Setup
  1. Ensure extension assets exist by running either:
    • npx opendevbrowser --full (installer path), or
    • npm run extension:build (repo/dev path)
  2. Load unpacked from ~/.config/opencode/opendevbrowser/extension (fallback: ~/.cache/opencode/node_modules/opendevbrowser/extension).
  3. Open extension popup
  4. Enter the same relay port and token as the runtime config (if relayToken is missing, either add one to opendevbrowser.jsonc or use Auto-Pair).
  5. Click Connect
Where Extension Assets Live

Extension assets are bundled inside the NPM package and extracted on install/startup:

  • Primary: ~/.config/opencode/opendevbrowser/extension
  • Fallback: ~/.cache/opencode/node_modules/opendevbrowser/extension

Extraction is handled by extractExtension() (see src/extension-extractor.ts).

Configuration

Optional config file: ~/.config/opencode/opendevbrowser.jsonc

{
  // Browser settings
  "headless": false,
  "profile": "default",
  "persistProfile": true,
  "chromePath": "/path/to/chrome",  // Custom Chrome executable
  "flags": ["--disable-extensions"],  // Additional Chrome flags

  // Snapshot limits
  "snapshot": { "maxChars": 16000, "maxNodes": 1000 },

  // Export limits
  "export": { "maxNodes": 1000, "inlineStyles": true },

  // DevTools output
  "devtools": { "showFullUrls": false, "showFullConsole": false },

  // Security (all default false for safety)
  "security": {
    "allowRawCDP": false,
    "allowNonLocalCdp": false,
    "allowUnsafeExport": false
  },

  // Provider workflow cookie defaults (optional)
  "providers": {
    "cookiePolicy": "auto",
    "cookieSource": {
      "type": "file",
      "value": "~/.config/opencode/opendevbrowser.provider-cookies.json"
    },
    "challengeOrchestration": {
      "mode": "browser_with_helper",
      "optionalComputerUseBridge": {
        "enabled": true
      }
    }
  },

  // Public read-only sibling desktop observation runtime (enabled by default; set "off" to opt out)
  // On macOS, availability, window, and accessibility probes require the local swift command.
  "desktop": {
    "permissionLevel": "observe",
    "commandTimeoutMs": 10000,
    "auditArtifactsDir": ".opendevbrowser/desktop-runtime",
    "accessibilityMaxDepth": 2,
    "accessibilityMaxChildren": 25
  },

  // Skills configuration
  "skills": {
    "nudge": {
      "enabled": true,
      "keywords": ["form", "login", "extract", "scrape"],
      "maxAgeMs": 60000
    }
  },
  "skillPaths": ["./custom-skills"],  // Additional skill directories

  // Continuity ledger
  "continuity": {
    "enabled": true,
    "filePath": "opendevbrowser_continuity.md",
    "nudge": {
      "enabled": true,
      "keywords": ["plan", "multi-step", "refactor", "migration"],
      "maxAgeMs": 60000
    }
  },

  // Extension relay
  "relayPort": 8787,
  "discoveryPort": 8787,
  "relayToken": "auto-generated-on-first-run",

  // Hub daemon (relay ownership + FIFO queue)
  "daemonPort": 8788,
  "daemonToken": "auto-generated-on-first-run",

  // Updates
  "checkForUpdates": false
}

All fields are optional. OpenDevBrowser works with sensible defaults.

CLI Commands

The CLI is agent-agnostic and supports the full automation surface (session, navigation, interaction, DOM, browser capture and replay, desktop observation, targets, pages, export, devtools, annotate, and canvas). All commands listed in the CLI reference are implemented and available in the current codebase. See docs/CLI.md for the full command and flag matrix. See docs/SURFACE_REFERENCE.md for the source-accurate inventory matrix (77 CLI commands, 70 tools, /ops, /canvas, and /cdp channel contracts).

CLI Category Matrix (core command groups)
Category Commands
Install/runtime install, update, uninstall, help, version, serve, daemon, native, run
Session/connection launch, connect, disconnect, status, status-capabilities, cookie-import, cookie-list
Navigation goto, wait, snapshot, review, review-desktop
Interaction click, hover, press, check, uncheck, type, select, scroll, scroll-into-view, upload, pointer-move, pointer-down, pointer-up, pointer-drag
Targets/pages targets-list, target-use, target-new, target-close, page, pages, page-close
DOM dom-html, dom-text, dom-attr, dom-value, dom-visible, dom-enabled, dom-checked
Browser capture screenshot, screencast-start, screencast-stop
Desktop observation desktop-status, desktop-windows, desktop-active-window, desktop-capture-desktop, desktop-capture-window, desktop-accessibility-snapshot
Design canvas canvas
Export/diagnostics/macro/annotation/power clone-page, clone-component, perf, dialog, console-poll, network-poll, debug-trace-snapshot, session-inspector, session-inspector-plan, session-inspector-audit, macro-resolve, annotate, rpc
Install/Management
Command Description
npx opendevbrowser Interactive install
npx opendevbrowser --global Install to global config
npx opendevbrowser --local Install to project config
npx opendevbrowser --with-config Also create opendevbrowser.jsonc
npx opendevbrowser --full Full install (config + extension assets)
npm install -g opendevbrowser Install persistent global CLI; npm global postinstall best-effort reconciles daemon auto-start
npx opendevbrowser --update Repair OpenCode package caches and plugin pins
npx opendevbrowser --uninstall Remove from config
npx opendevbrowser --version Show version
Common Automation Commands (Daemon-backed)

Start the daemon with npx opendevbrowser serve, then use:

Command Description
npx opendevbrowser launch Launch session (defaults to extension mode when available)
npx opendevbrowser connect Connect via relay or direct CDP endpoint
npx opendevbrowser disconnect Disconnect session
npx opendevbrowser status Show session status
npx opendevbrowser status-capabilities --session-id <id> Inspect host and session capability discovery before a workflow run
npx opendevbrowser session-inspector --session-id <id> Capture a session-first diagnostic bundle with relay health, trace proof, and a suggested next action
npx opendevbrowser session-inspector-plan --session-id <id> Inspect browser-scoped computer-use policy, eligibility, and safe suggested steps
npx opendevbrowser session-inspector-audit --session-id <id> Capture a correlated audit bundle across desktop evidence, browser review, and policy state
npx opendevbrowser goto Navigate to URL
npx opendevbrowser wait Wait for load or element
npx opendevbrowser snapshot Capture snapshot with refs
npx opendevbrowser review-desktop --session-id <id> --reason "<context>" Capture desktop-assisted browser review with read-only desktop evidence
npx opendevbrowser click Click element by ref
npx opendevbrowser type Type into element by ref
npx opendevbrowser select Select dropdown option by ref
npx opendevbrowser scroll Scroll page or element
npx opendevbrowser run Run a JSON script
npx opendevbrowser canvas --command canvas.session.open --params '{...}' Start or continue a design-canvas workflow through the daemon
npx opendevbrowser macro-resolve --expression '@media.search("youtube transcript parity", "youtube", 5)' --execute --timeout-ms 120000 Execute macro plans with extended timeout for slow runs

Workflow cookie controls (research run, shopping run, product-video run, inspiredesign run):

  • Defaults come from providers.cookiePolicy (off|auto|required) and providers.cookieSource (file|env|inline).
  • Per-run overrides: --use-cookies, --cookie-policy-override (alias --cookie-policy).
  • auto is non-blocking when cookies are unavailable; required fails fast with reasonCode=auth_required.

Workflow challenge controls (research run, shopping run, product-video run, inspiredesign run):

  • Per-run override: --challenge-automation-mode off|browser|browser_with_helper, which maps to challengeAutomationMode.
  • Effective precedence is run > session > config.
  • off keeps detection and reporting active but stands down challenge actions.
  • browser allows browser-native lanes only and keeps the helper bridge disabled.
  • browser_with_helper keeps browser-native lanes first and evaluates the browser-scoped helper bridge second when hard gates pass.
  • The helper bridge remains browser-scoped and is not a desktop agent.

Security

OpenDevBrowser is secure by default with defense-in-depth protections:

Protection Details
CDP Localhost-Only Remote endpoints blocked; hostname normalized to prevent bypass
Timing-Safe Auth crypto.timingSafeEqual() for token comparison
Origin Validation /extension requires chrome-extension:// origin; /ops, /canvas, /cdp, /annotation, and /config//status//pair allow loopback no-Origin requests
PNA Preflights HTTP preflights include Access-Control-Allow-Private-Network: true when requested
Rate Limiting 5 handshake attempts/minute per IP, plus HTTP rate limiting for /config, /status, /pair
Data Redaction Tokens, API keys, sensitive paths auto-redacted
Export Sanitization Scripts, event handlers, dangerous CSS stripped
Atomic Writes Config writes are atomic to prevent corruption
Secure Defaults allowRawCDP, allowNonLocalCdp, allowUnsafeExport all false

Updating

# Repair OpenCode's cached packages, manifest pin, and lockfile, then restart OpenCode
npx opendevbrowser --update

Architecture overview: docs/ARCHITECTURE.md Release checklist: docs/DISTRIBUTION_PLAN.md Documentation index: docs/README.md Frontend docs: docs/FRONTEND.md Dependency inventory: docs/DEPENDENCIES.md Local-only generated artifacts such as prompt-exports/, root artifacts/, coverage/, CONTINUITY*.md, and sub_continuity.md stay uncommitted; .gitignore is authoritative.

Architecture

┌─────────────────────────────────────────────────────────────────┐
│                      Distribution Layer                         │
├──────────────────┬──────────────────┬──────────────────┬──────────────────────────┤
│ OpenCode Tools   │       CLI        │    Hub Daemon    │    Chrome Extension       │
│  (src/index.ts)  │ (src/cli/index)  │ (opendevbrowser  │   (extension/src/)        │
│                  │                  │      serve)     │                           │
└────────┬─────────┴────────┬─────────┴─────────┬────────┴──────────────┬────────────┘
         │                  │                  │                       │
         ▼                  ▼                  ▼                       ▼
┌─────────────────────────────────────────────────────────────────┐
│                    Core Runtime (src/core/)                    │
│  bootstrap.ts → wires managers, sibling desktop runtime,       │
│                   automation coordinator, injects ToolDeps     │
└────────┬────────────────────────────────────────────────────────┘
         │
    ┌────┴────┬─────────────┬──────────────┬──────────────┬──────────────┐
    ▼         ▼             ▼              ▼              ▼              ▼
┌────────┐ ┌────────┐ ┌──────────┐ ┌────────────┐ ┌────────────┐ ┌────────────┐
│Browser │ │Script  │ │Snapshot  │ │ Annotation │ │  Relay     │ │  Skills    │
│Manager │ │Runner  │ │Pipeline  │ │  Manager   │ │  Server    │ │  Loader    │
└───┬────┘ └────────┘ └──────────┘ └────────────┘ └─────┬──────┘ └────────────┘
    │                                                  │
    ▼                                                  ▼
┌────────┐                                        ┌────────────┐
│Target  │                                        │ Extension  │
│Manager │                                        │ (WS relay) │
└────────┘                                        └────────────┘

The simplified map above omits the dedicated Challenge Coordinator, Desktop Runtime, and Automation Coordinator that now sit beside the browser managers; see docs/ARCHITECTURE.md for the full component map and ownership boundaries.

Data Flow
Tool Call → Zod Validation → Manager/Runner → CDP/Playwright → Response
                                   ↓
                            Snapshot (AX-tree → refs)
                                   ↓
                            Action (ref → backendNodeId → DOM)
System Workflow (Happy Path)
  1. launch (extension or managed) -> sessionId
  2. snapshot -> refs
  3. Action commands (click, type, press, hover, check, etc.) -> repeat snapshot
  4. disconnect on completion
Repository Layout
.
├── src/              # Runtime implementation
│   ├── annotate/     # Annotation transports + output shaping
│   ├── automation/    # Automation helpers and coordinator
│   ├── browser/      # Browser sessions, target orchestration, canvas preview/code-sync
│   ├── cache/        # Chrome executable resolution
│   ├── canvas/       # Design-canvas document store, repo IO, code-sync, export helpers
│   ├── challenges/   # Bounded challenge orchestration plane, evidence, recovery lanes
│   ├── cli/          # CLI commands, daemon, installers
│   ├── core/         # Bootstrap, runtime wiring, ToolDeps
│   ├── desktop/      # Read-only desktop observation runtime
│   ├── devtools/     # Console/network trackers with redaction
│   ├── export/       # DOM capture, React emitter, CSS extraction
│   ├── integrations/ # External integration adapters (Figma import, etc.)
│   ├── macros/       # Macro parsing, resolution, provider-action expansion
│   ├── providers/    # Provider runtime, policy, workflows, browser fallback
│   ├── public-surface/ # Generated manifest source, CLI/tool metadata
│   ├── relay/        # Extension relay server, protocol types
│   ├── skills/       # SkillLoader for skill pack discovery
│   ├── snapshot/     # AX-tree snapshots, ref management
│   ├── tools/        # 70 opendevbrowser_* tool definitions
│   └── utils/        # Shared utilities
├── extension/        # Chrome extension (relay client)
├── scripts/          # Operational scripts (build/sync/smoke)
├── skills/           # Bundled skill directories (10 canonical OpenDevBrowser packs)
├── tests/            # Vitest tests (97% coverage required)
└── docs/             # Architecture, CLI, extension, distribution plans

Extension relay uses flat CDP sessions (Chrome 125+) with DebuggerSession sessionId routing for multi-tab support. When hub mode is enabled, the hub daemon is the sole relay owner and enforces a FIFO lease queue for multi-client safety. See docs/ARCHITECTURE.md for the full architecture reference.

Development

npm install
npm run build      # Compile to dist/
npm run test       # Run tests with coverage (97% threshold)
npm run lint       # ESLint checks (strict TypeScript)
npm run extension:build  # Compile extension
npm run version:check    # Verify package/extension version alignment
npm run extension:pack   # Build extension zip for releases
Packaging & Distribution (Public + Private)

Uniform versioning is required (source of truth: package.json):

  1. Bump package.json version.
  2. Run: npm run extension:sync
  3. Run: npm run version:check
  4. Run: npm run test:release-gate
  5. Run: npm run build
  6. Run: npm run extension:build
  7. Run release audits:
    • node scripts/audit-zombie-files.mjs
    • node scripts/docs-drift-check.mjs
    • node scripts/chrome-store-compliance-check.mjs
    • ./skills/opendevbrowser-best-practices/scripts/validate-skill-assets.sh
    • ./skills/opendevbrowser-motion-design/scripts/validate-skill-assets.sh
  8. Run strict live release gates:
    • node scripts/provider-direct-runs.mjs --release-gate --out artifacts/release/vX.Y.Z/provider-direct-runs.json
    • node scripts/live-regression-direct.mjs --release-gate --out artifacts/release/vX.Y.Z/live-regression-direct.json
  9. Run first-time global install dry run checklist from docs/FIRST_RUN_ONBOARDING.md.
  10. Run: npm run extension:pack (outputs ./opendevbrowser-extension.zip)
  11. Run: npm pack
  12. Tag vX.Y.Z and let .github/workflows/release-public.yml publish npm + GitHub release artifacts.
  13. Dispatch website content sync to private repo through .github/workflows/dispatch-private-sync.yml.

Runbooks:

  • docs/DISTRIBUTION_PLAN.md
  • docs/RELEASE_RUNBOOK.md
  • docs/EXTENSION_RELEASE_RUNBOOK.md
  • docs/CUTOVER_CHECKLIST.md

Privacy

See Privacy Policy for data handling details.

License

MIT

Keywords

opencodepluginbrowserautomationcdpplaywrighttestingweb-scrapingchromeannotationdesign-canvasscreencastdesktop-observationbrowser-replaycomputer-usechallenge-automation
