Visual Web Canvas

Stop describing UI changes to Claude Code. Point at them.

Visual Web Canvas puts a click-to-edit canvas of your website inside VS Code. Select any element, edit copy and styles visually, or leave a comment. Your existing Claude Code conversation receives the exact DOM, source location, React component stack, computed styles, viewport, and a cropped screenshot of what you selected.

No second chat box. No screenshot-and-guess loop. No cloud account or telemetry.

Visual Web Canvas is independent open-source software and is not affiliated with or endorsed by Anthropic.

Install

npx --yes visual-web-canvas@latest install

This installs the extension (from the Marketplace when available, otherwise from the pinned GitHub release) and wires up the Claude Code bridge.

Manual alternative: download the VSIX from the latest release, run Extensions: Install from VSIX… in VS Code, then run Visual Web Canvas: Install/Repair Claude Bridge from the Command Palette.

Requirements:

• VS Code 1.94+ for the complete Claude Code workflow.
• Node.js 20+ for the installer and live React source editor.
• Claude Code for VS Code for seamless chat context.
• Cursor 3.6+ is available as a clearly labeled MCP-based beta.

The Claude workflow

1. Select an element in either canvas mode.
2. Click Comment → Claude and write the visual change you want.
3. Visual Web Canvas captures a cropped screenshot and focuses the existing Claude Code chat.
4. Type naturally. Even do this is enough: on submit, the UserPromptSubmit hook adds the selected element and comment as private context.
5. Claude edits the real source. The canvas refreshes through VS Code or HMR.

The bridge is additive: it preserves every existing Claude hook. Install, repair, diagnose, and remove it with:

visual-web-canvas doctor
visual-web-canvas uninstall --keep-extension

Two canvas modes

Capability	Static HTML	React / Vite / Next.js	Generic dev server
Exact responsive viewport	Yes	Yes	Yes
Element/source context	Exact HTML ranges	React Fiber + source stack	Runtime DOM
Inline copy editing	Yes	Yes, through React Rewrite	Comment to agent
Visual style editing	CSS + responsive overrides	Tailwind 3/4, staged	Preview/comment
Duplicate/delete/reorder	Yes	Yes, staged	Comment to agent
Claude Code context bridge	Yes	Yes	Yes
Comment screenshot	Yes	Yes	Yes

Static HTML

Open any .html file and run Visual Web Canvas: Open HTML Canvas. The preview is generated from the open TextDocument, including unsaved changes.

• Click to select; double-click text to edit it.
• Edit layout, typography, color, radius, and opacity from the inspector.
• Apply styles globally or at desktop, tablet, and mobile breakpoints.
• Duplicate or delete elements with normal VS Code undo support.
• Compare against a simultaneous 390 px mobile canvas.
• Show a 768 px fold guide and inspect/revert the previous document state.

Authored page scripts are disabled in static mode. Source identifiers exist only in the rendered preview and never modify the saved HTML.

React, Vite, and Next.js

Start the app normally, then run Visual Web Canvas: Connect Dev Server and enter its loopback URL.

The extension launches the MIT-licensed React Rewrite bridge behind a second tokenized proxy. This provides staged visual source editing while preserving Vite/Next HMR and Remote SSH forwarding.

• Inspect captures an element for Claude and opens its source location.
• Design enables React Rewrite's text, Tailwind, resize, move, duplicate, delete, multi-select, and change-review tools.
• If React/source resolution is unavailable, the same canvas falls back to safe inspect/comment mode instead of guessing at source writes.

Only localhost, 127.0.0.1, and ::1 dev servers are accepted.

Responsive canvas

Desktop means 1440 CSS pixels even when the editor pane is narrower. The canvas scales visually to fit while keeping the real iframe viewport fixed, so media queries do not accidentally follow the size of the VS Code window.

Presets: responsive, 1440 desktop, 1024 laptop, 768 tablet, and 390 mobile.

Try it in 60 seconds

The examples/ folder ships three ready-to-open playgrounds:

• examples/static-landing-page.html: open it, run Visual Web Canvas: Open HTML Canvas, and start clicking.
• examples/vite-react: npm install && npm run dev, then Connect Dev Server.
• examples/next-app: npm install && npm run dev, then Connect Dev Server.

Cursor beta

npx --yes visual-web-canvas@latest install --cursor

Cursor currently lacks a supported equivalent to Claude Code's dynamic UserPromptSubmit.additionalContext. The beta therefore installs a local MCP server with:

• get_current_selection
• get_pending_comments
• get_screenshot
• mark_comment_resolved

The canvas works inside Cursor, but context retrieval depends on the Cursor agent calling the MCP tool. We do not market this as identical to the Claude Code bridge.

Privacy and security

• No telemetry, account, hosted relay, or remote service.
• Selection state is stored with private permissions under ~/.visual-web-canvas/state/.
• Screenshots are captured only after a visual comment and stored under ~/.visual-web-canvas/screenshots/.
• Closing a canvas removes its active state file.
• Static previews use a restrictive CSP, disable page-authored scripts, block forms and frames, and only serve workspace-local assets.
• Live mode accepts loopback targets only and uses random per-session tokens.
• Source paths must resolve inside the open workspace before they can be opened or edited.

See SECURITY.md for reporting and the complete trust model.

Development

npm install
npm run check
npm run package

The repo includes unit and integration coverage for HTML/source mapping, document edits, Claude hook context, exact viewport math, static preview isolation, live proxy injection, and path traversal.

Read docs/ARCHITECTURE.md, CONTRIBUTING.md, and THIRD_PARTY_NOTICES.md before changing the bridge or source-editing layers.

License

MIT
